Film Loading

1. While pushing the Back Cover
Lock Release Button 8 downward,
press the Back Cover Opening But-
ton @;:, and the Back Cover will open.
2. While squeezing in on both sides
of the Release Latch CQ, pull the Roll
Film Insert out of the camera body. At
that time, move the empty spool in
the upper part down to the lower
spool compartment
When you load film for the first
time, remove and discard the
protective paper cover which is
attached to the film rails in the
roll film holder.
3. Align the right-hand side of this
empty spool with the lower Spool
Stud '8 (convex). Slide the spool into
position making sure that the left-
side of the spool is properly held by
the Spool Clip.
