Bellfires View Bell Vertical 3 LF Installation Manual

Direct vent gas fireplace
Hide thumbs Also See for View Bell Vertical 3 LF:
Table of Contents

Advertisement

Quick Links

Download this manual
View Bell Vertical 3 LF
Direct Vent Gas Fireplace
Installation manual
WARNING
A barrier designed to reduce the risk of burns from the
hot viewing glass is provided with this appliance and
shall be installed for the protection of children and other
at-risk individuals.
WARNING:
followed exactly, a fi re or explosion may result causing property damage,
personal injury or loss of life.
- Do not store or use gasoline or other fl ammable vapors and liquids in
the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use any phone in your
building.
•
Immediately call your gas supplier from a neighbor's phone.
Follow the gas supplier's instructions.
•
If you cannot reach your gas supplier, call the fi re department.
- Installation and service must be performed by a qualifi ed installer,
service agency or the gas supplier.
This appliance may be installed in an aftermarket, permanently located,
manufactured home (USA only) or mobile home, where not prohibited by
local codes. This appliance is only for use with the types of gas indicated
on the rating plate. A conversion kit is supplied with the appliance.
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
WARNINGS
If the information in these instructions are not
INSTALLER:
Leave this manual with
the appliance.
CONSUMER:
Retain this manual for
future reference.
