Whirlpool WHES60 Installation And Operation Manual page 21

Key
Part No.
No.
Tank Neck Clamp Kit
– 7331177
(includes 2 ea. of Key Nos. 1 & 2)
1 Clamp Section (2 req.)
2 Retainer Clip (2 req.)
Distributor O-Ring Kit
– 7112963
(includes Key Nos. 3-5)
3 O-Ring, 2-7/8" x 3-1/4"
4 O-Ring, 13/16" x 1-1/16"
5 O-Ring, 2-3/4" x 3"
6 7077870 Top Distributor
7 7105047 Repl. Bottom Distributor
8 0502272 Resin, 1 cu. ft.
Resin Tank & Foot Assembly
– 7348077
(includes Key Nos. 9 & 10)
9 Resin Tank, 12" x 54"
10 Foot, Tank
11 7204689 Cap, Tank
12 7348085 Shroud, Tank
13 7189449 Bottom Cover
14 7174868 Faceplate Cover (order decal below)
7345710 Faceplate Decal
Repl. Electronic Control Board
15 7282996
(PWA)
To order repair parts call toll free 1-866-986-3223, Monday - Friday, 8 am - 7 pm EST.
Questions? Call Toll Free 1-866-986-3223
When you call, please be prepared to provide the model and serial number,
found on the rating decal, located on the back of the controller's top cover.
Softener Parts List
Description
Manufactured and warranted by
Ecodyne Water Systems
1890 Woodlane Drive
Woodbury, MN 55125
or visit www.whirlpoolwatersofteners.com
Key
Part No.
No.
16 7337482
17 7180437
7345786
18 7155115
19 7109871
– 7331648
20
21
22 7112612
– 7331258
23
24
25
26 7310210
27 7327568
28 7214383
29 7139999
7345760
Not illustrated.
Monday- Friday, 8 AM - 7 PM EST
21
Description
Power Supply, 28V DC
Salt Cover (order decal below)
Instruction Decal
Cover, Brinewell
Brinewell
Brinewell Mounting Hardware Kit
(includes Key Nos. 20 & 21)
Wing Nut, 1/4-20
Screw, 1/4-20 x 5/8"
Repl. Brine Tank
(includes Key Nos. 19-21)
Overflow Hose Adaptor Kit
(includes Key Nos. 23-25)
Adaptor Elbow
Grommet
Hose Clamp
Repl. Brine Valve Assembly
Float, Stem & Guide Assembly
Bypass Valve Assembly, 1",
including 2 ea. Clips & O-Rings
(See Key Nos. 121 & 123)
Drain Hose, 20 ft.
Owner's Manual
