Gravity Vent Fireplace Insert
RF24XBN (NG) & RF24XBP (LPG)
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other
fl ammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light the appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fi re department.
Installation and service must be performed
by a qualifi ed installer, service agency or the
gas supplier.
4002862-05
© 2012 Miles Industries Ltd. All rights reserved.
R
ETROFIRE
Installation and Owner's Manual
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
Manufactured by
MILES INDUSTRIES LTD., British Columbia, Canada
www.valorfi replaces.com
I N S TA L LE R
L eav e t h i s m an u al
w i t h t he ap p l i an ce.
C O N S U M E R
R et ai n t h i s ma n u al
f o r f ut u r e r ef ere nc e.
Please read this manual BEFORE installing
and operating this appliance.
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certifi ed kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Massachusetts: The piping and fi nal
gas connection must be performed by a
licensed plumber or gas fi tter in the State of
Massachusetts.
Ce guide est disponible en français sur demande.
US Patent no. 8,166,965
Advertisement
Table of Contents
Related Manuals for Miles Industries RETROFIRE RF24XBN
Summary of Contents for Miles Industries RETROFIRE RF24XBN
- Page 1 fi tter in the State of by a qualifi ed installer, service agency or the Massachusetts. gas supplier. Ce guide est disponible en français sur demande. Manufactured by MILES INDUSTRIES LTD., British Columbia, Canada www.valorfi replaces.com 4002862-05 © 2012 Miles Industries Ltd. All rights reserved.
-
Page 2: Table Of Contents
Miles Industries Ltd. reserves the right printing. Miles Industries Ltd. reserves the right to change or modify any information or specifi ca- to change or modify any information or specifi... -
Page 3: Safety Precautions
Safety Precautions READ and UNDERSTAND all instructions carefully This unit MUST be used with a vent system as before starting the installation. FAILURE TO FOLLOW described in this installation manual. NO OTHER vent these installation instructions may result in possible fi re system or components MAY BE USED. -
Page 4: Safety And Your Fireplace
Safety and Your Fireplace Safety and Your Fireplace Please Read and Carefully Follow all Safety Warnings and Operating Instructions Contained in Your Owners Manual (Replacement Manuals are available by contacting our service department at 1-800-468-2567 or visit www.valorfi replaces.com). skills and response refl exes to Please Follow These Important withdraw in the event of accidental Child Safety Precautions and... -
Page 5: Owner's Information
Owner’s Information INFORMATION Thank You ... WARNING For purchasing a Valor by Miles Industries. Your new EXTREMELY HOT!!! radiant gas heater is a technical appliance that must be installed by a qualifi ed dealer. Each Valor fi replace • READ the SAFETY information on pages... - Page 6 Dealers have tried various cleaning products with varying results. The following recommendations will not guarantee results in your particular case. NOTE: This is a problem beyond Miles Industries’ control and is not covered under warranty. 1/4 Turn Spring-loaded Fastening Studs (2) •...
-
Page 7: How To Ensure Your Fireplace Cannot Be Turned On Inadvertently
OWNER’S Owner’s Information INFORMATION Checks To replace the batteries in the remote control receiver: periodic check of the pilot and burner fl ames should 1. The receiver is located to the left of the valve and it be made. Check after the fi re has been on for at least is retained to the fi... -
Page 8: Remote Control Operation
This number is on the rating plate, which is located under the burner. Should the safety switch require replacement, only use parts supplied by Miles Industries. The replacement parts are shown at the end of this manual. Please always quote the part number and description when requesting spare parts. - Page 9 OWNER’S Remote Control Operation INFORMATION Setting the temperature Use this setting when you come in and want to enjoy a specifi c temperature. 1. Push the AUTO button until a number and F fl ash. Let go. 2. While it is still fl ashing, push the ▲ and ▼ buttons to the temperature you want. Let go.
-
Page 10: Options
OWNER’S Remote Control Operation INFORMATION Battery Replacement When your remote control displays BATT, you need to replace the battery with a new 9 volt alkaline battery—6LR61/MN1604. CAUTION DO NOT USE a screwdriver or other metallic object to remove the batteries from the receiver or the handset! This could cause a short circuit to the receiver. -
Page 11: Lighting Instructions
OWNER’S Lighting Instructions INFORMATION FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot, which must be lighted by hand. When lighting the pilot, follow these instructions exactly. -
Page 12: Specifi Cations
QUALIFIED Specifi cations INSTALLER *High Altitude Installations This appliance is intended for installation into existing masonry or factory-built, solid-fuel burning Input ratings are shown in BTU per hour and are fi replaces only. certifi ed without deration for elevations up to 4,500 feet (1,370 m) above sea level. -
Page 13: Dimensions
QUALIFIED Dimensions INSTALLER Dimensions— for Solid-Fuel Burning Fireplace Insert Only See separate framing Dimensions for Zero Clearance applications with the Zero Clearance Kit RA24ZC. 17” 24-1/2” 24-3/8” Stand-offs 8” 7-5/8” 3” dia. Collar 1225VFB Ventana Fret (Black) RA24TB Fret (Black) 25-1/2”... -
Page 14: Vent Confi Gurations
QUALIFIED Dimensions INSTALLER Mantel / Hearth Clearances Combustible Mantel and Hearth Clearances for insert NOTE: The glass front and hearth are very hot. Existing applications must conform to those required for the wire mesh screens or free standing hearth mounted original solid-fuel burning fi... -
Page 15: Existing Fireplace Preparation
QUALIFIED Existing Fireplace Preparation INSTALLER Gas Line Routing A few points must be considered before inserting the RF24 into an existing fi replace cavity. Generally, Plan the routing of the gas line before proceeding. modifi cations to the existing fi replace that will compro- Utilize the existing hole for the gas line. -
Page 16: Supply Gas Installation
QUALIFIED Supply Gas Installation INSTALLER • It’s preferable to rough-in the gas line at this point • When testing for leaks: before proceeding with the fi rebox installation. • Make sure that the appliance is turned off. • The gas supply inlet connection is a 3/8” NPT •... -
Page 17: Vent Liner Rough-In
QUALIFIED Vent Liner Rough-in INSTALLER Rough-in the 3” diameter vent liner into existing hearth—see diagram in Connect Liner to the Firebox chimney system being careful not to tear or damage section. When connecting the liner in this manner, it is the liner in the process. -
Page 18: Firebox Installation
QUALIFIED Firebox Installation INSTALLER Connection of liner to fi rebox Trim Liner and Connect The vent plate will ultimately locate approximately 19” Vent Plate to Liner using Gear Clamp provided above the base of the fi replace once inserted. 1. Trim the liner accordingly so it will not be too long Approx. -
Page 19: Side View
QUALIFIED Firebox Installation INSTALLER Leveling the fi rebox in the hearth The backside of each support leg has a leveling bolt. If necessary, adjust the level of the fi rebox in the hearth. Fret bracket Leveling Front Back Leveling bolt bolt Leveling bolt Side View... - Page 20 QUALIFIED Firebox Installation INSTALLER Top Convection Baffl e Installation Position the fi rebox as far back as possible within the existing fi replace to allow ample space at front for the fret and to allow convection air to fl ow under the smoke curtain of the existing fi...
-
Page 21: Ceramic Logs Installation
QUALIFIED Ceramic Logs Installation INSTALLER Carefully remove the ceramic logs from the packaging Please note that the Rear Log will have a different taking care not to damage them. Install the logs as position depending of the gas type. described below. The position of the logs is critical to insure the good performance of the appliance. -
Page 22: Window Refi Tting And Checking
QUALIFIED Window Refi tting and Checking INSTALLER Hook the window over the top edge of the fi rebox, and fasten the bottom two spring loaded bolts by pushing in and turning 90 degrees. If the Hot Glass Warning plate has been removed from the front lower corner of the window, reinstall it by sliding it between the glass and the frame as indicated. -
Page 23: Operation Check And Aeration Adjustment
QUALIFIED Operation Check and Aeration Adjustment INSTALLER Turn the fi replace up and down using the remote control to confi rm that the full range of inputs is achieved. Air Shutter Light the fi re and allow to warm up for 10–15 minutes to evaluate the fl... -
Page 24: Optional Cast Iron Fret Installation
QUALIFIED Optional Cast Iron Fret Installation INSTALLER Important: The fret retainer brackets are designed to maintain the required space in front of the window to allow the window to move and relieve during a hard start. It is very important to ensure this area in front of the window is kept clear at all times. -
Page 25: Warranty
1. Extended Warranty Coverage For a period of up to ten (10) years, Miles Industries Ltd., (the “Company”) or its appointed distributor will at its option pay the initial purchaser for the repair of, or will exchange the following parts or components which are found to be defective in material or... -
Page 26: Spare Parts
OWNER’S Spare Parts INFORMATION PART PART DESCRIPTION DESCRIPTION NUMBER NUMBER Firebox Assembly 4000634AH Pilot Tube 4000732 Vent Plate 4001010 GV34 Complete Valve NG 4003103 Convection Baffl e 4001009 GV34 Complete Valve LPG 4003116 LH Fret Support 4002837BY Remote Control Kit 4000099 Wing Nuts (2) 4000741... - Page 27 OWNER’S Spare Parts INFORMATION 39a, 39b...
-
Page 29: Miles Industries Ltd
Serial Number: Date Purchase (yyyy-mm-dd): Dealer: Customer Information First Name: Last Name: Contact Information Email: Mailing Address Address: City: Province/State: Postal/Zip Code: Country: Cut out page, fi ll information, and mail to Miles Industries Ltd. Online Warranty registration at www.valorfi replaces.com... -
Page 30: Miles Industries Ltd
Tape Shut Fold here Postage needed Miles Industries Ltd. 190 - 2255 Dollarton Highway North Vancouver, BC V7H 3B1 Canada Online Warranty registration at www.valorfi replaces.com Thank you for choosing a Valor Product...
