785JLN (NG) & 785JLP (LPG)
DANGER
!
A barrier designed to reduce the risk of burns from the hot
viewing glass is provided with this appliance and shall be
installed for the protection of children and other at-risk
individuals.
!
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
— Do not store or use gasoline or other
fl ammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
▪ Do not try to light any appliance.
▪ Do not touch any electrical switch; do
not use any phone in your building.
▪ Leave the building immediately.
▪ Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
▪ If you cannot reach your gas supplier,
call the fi re department.
— Installation and service must be
performed by a qualifi ed installer, service
agency or the gas supplier.
4004285-06
©2016, Miles Industries Ltd.
L
EGEND
Direct Vent Gas Insert
Installation and Owner's Manual
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
G4
L e a v e t h i s m a n u a l
w i t h t h e a p p l i a n c e .
R e t a i n t h i s m a n u a l
f o r f u t u r e r e f e r e n c e .
Please read this manual
BEFORE installing and
operating this appliance.
This manual contains instructions to install the
ENGINE ONLY. A front is also REQUIRED to
complete this installation. A barrier screen is pro-
vided with the front. Refer to the manual sup-
plied with the front for installation.
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certifi ed kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Ce guide est disponible en français sur demande.
Patent Pending
I N S TA L L E R
C O N S U M E R
Advertisement
Table of Contents
Related Manuals for Miles Industries 785JLN (NG)
Summary of Contents for Miles Industries 785JLN (NG)
- Page 1 fi re department. bedroom or bed sitting room. — Installation and service must be Ce guide est disponible en français sur demande. performed by a qualifi ed installer, service agency or the gas supplier. 4004285-06 ©2016, Miles Industries Ltd.
-
Page 2: Table Of Contents
Spare Parts............39 The information contained in this installation manual is believed to be correct at the time of printing. Miles Industries Ltd. reserves the right to change or modify any information or speci- fi cations without notice. Miles Industries Ltd. -
Page 3: Safety Precautions
Safety Precautions READ and UNDERSTAND all instructions carefully Due to the high temperature, the appliance should be before starting the installation. FAILURE TO FOLLOW LOCATED out of traffi c areas and away from furniture these installation instructions may result in possible fi re and draperies. -
Page 4: Safety And Your Fireplace
Safety and Your Fireplace Safety and Your Fireplace Please Read and Carefully Follow all Safety Warnings and Operating Instructions Contained in Your Owner’s Manual (Replacement Manuals are available by contacting our service department at 1-800-468-2567 or visit www.valorfi replaces.com). withdraw in the event of accidental Please Follow These Important contact with a hot surface. -
Page 5: Owner's Information
Owner’s Information INFORMATION Thank You ... WARNING For purchasing a Valor by Miles Industries. Your new EXTREMELY HOT!!! radiant gas heater is a technical appliance that must be installed by a qualifi ed dealer. Each Valor fi replace • READ the SAFETY information on pages... -
Page 6: Cleaning Your Fireplace
3. Find the levers on each particular case. side of the window towards NOTE: This is a problem beyond Miles Industries’ the top. Using your fi nger, control and is not covered under warranty. pull the levers towards you •... -
Page 7: Checking Pilot And Burner Flames
OWNER’S Owner’s Information INFORMATION 2. While you hold 5. If the Hot Glass Warning plate has been removed it, hook the side from the front lower corner of the window, levers into the reinstall it by sliding it between the glass and window tabs. -
Page 8: Replacing Batteries
OWNER’S Owner’s Information INFORMATION The appliance area must always be kept clear and 5. Replace the cover and screw in place. free from combustible materials, gasoline and other 6. Reconnect the battery box. fl ammable vapors and liquids. 7. Put the battery box back in its position. 8. -
Page 9: How To Turn Your Fireplace Off (Including Pilot)
OWNER’S Owner’s Information INFORMATION How to Turn Your Fireplace OFF How to Ensure Your Fireplace Cannot (including pilot) Be Turned ON Inadvertently Familiarize yourself with each of these methods before operating your fi replace. You can use one of the two following methods to ensure that your fi... -
Page 10: Remote Control Operation
OWNER’S Remote Control Operation INFORMATION NOTE: Before using the remote control system for IMPORTANT: BEFORE YOU BEGIN, please note that the fi rst time, the receiver and the handset must be on this system, the settings of time, temperature and synchronized. - Page 11 OWNER’S Remote Control Operation INFORMATION MODES OF OPERATION • Press and hold (small fl ame) button to decrease fl ame height or • Briefl y pressing the SET button to set the appliance at pilot fl ame. changes the mode of operation in •...
- Page 12 OWNER’S Remote Control Operation INFORMATION • - Nighttime Setback T E M P Temperature Mode (Appliance must be in standby mode; pilot ignited) - The room temperature is measured and compared to the Nighttime Setback temperature. The fl ame height is then automati- cally adjusted to achieve the Night- time Setback Temperature.
- Page 13 OWNER’S Remote Control Operation INFORMATION SETTING THE “NIGHTTIME SETBACK” TEMPERA- SETTING THE ON / OFF TEMPERATURES TURE SETTING THE “DAYTIME” TEMPERATURE Default Settings: (moon), “ ” (OFF) T E M P Default Settings: (sun), 23ºC / 74ºF TEMP • Briefl y press SET button to scroll to •...
- Page 14 OWNER’S Remote Control Operation INFORMATION SETTING P1 OFF TIME SETTING PROGRAM TIMERS • You can program two periods of time between 12:00 • Briefl y press SET button to scroll am and 11:50 pm in each 24-hour cycle. to TIMER (moon) while the •...
-
Page 15: Options
OWNER’S Remote Control Operation INFORMATION Timer Programming Example (default temperatures shown) 4:00 p.m.— 6:00 a.m.— 8:00 a.m.— 10:00 p.m.— ☼ 6:00 a.m.— ☼ ☼ ☽ ☽ Start time Start time End time End time Start time ☼ ☼ ☽ ☽ Set temp 40˚F Set temp... -
Page 16: Lighting Instructions
OWNER’S Lighting Instructions INFORMATION FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING : If you do not follow these instructions exactly A. This appliance has a pilot which must be lighted by hand or by remote control. Follow these instructions exactly. To save gas, turn the pilot off when not using the appliance for a prolonged period of time. -
Page 17: Specifi Cations
QUALIFIED Specifi cations INSTALLER Approval & Codes *High Altitude Installations This appliance is certifi ed to ANSI Z21.88-2014 / CSA I nput ratings are shown in BTU per hour and are 2.33-2014 American National Standard / CSA Standard certifi ed without deration for elevations up to 4,500 feet for Vented Gas Fireplace Heaters for use in Canada (1,370 m) above sea level. -
Page 18: Overview
QUALIFIED Overview INSTALLER This appliance may ONLY be installed in an existing unaltered, functioning solid-fuel burning fi replace with a working fl ue and constructed of non-combustible material. DO NOT install into combustible construction. This appliance is NOT APPROVED for installation with a zero clearance kit. WARNING WARNING Chimney Terminal Cap... -
Page 19: Dimensions
QUALIFIED Dimensions INSTALLER 33” (838 mm) 24” (610 mm) 3” 6’ (1.9 m) Fan power cord (76 mm) Optional fan 3” 3” 15” (76 mm) (76 mm) (381 mm) 15” Trim 4” (381 mm) (sold separately) (102 mm) 10” Gas line approx. 24“ (610 mm) of flex protruding from (254 mm) sheet metal box... -
Page 20: Clearances
QUALIFIED Clearances INSTALLER WARNING WARNING Some materials or items, although safe, may discolor, shrink, warp, crack, peel, and so on because of the heat produced by the fi replace. Avoid placing candles, paintings, photos, and other items sensitive to heat around the fi replace. Combustible Mantel Clearances Mantel Pro- 1”... -
Page 21: Venting
QUALIFIED Venting INSTALLER Typical Vent Installation See list of approved venting accessories on page 36 of this manual. NOTE: Flexible co-linear vent pipes may only be installed into existing non-combustible solid-fuel burning fi replaces Terminal Cap and chimneys. Vent Location The vent terminal must be located through the roof. -
Page 22: Installation Planning
QUALIFIED Installation Planning INSTALLER Only qualifi ed licensed or trained personnel should install this appliance. Installer—READ THIS FIRST 1. YOU NEED TO KNOW FROM THE 13. Refi t window. HOMEOWNER what accessories (surround, 14. Reinstall the hot glass warning plate if it has been screen, fan/blower, etc.) will be installed with removed. -
Page 23: Installation
QUALIFIED Existing Fireplace Preparation INSTALLER Gas Line Routing Combustible Mantels Plan the routing of the gas line before proceeding. Combustible mantel clearances must conform to those Utilize the existing hole for the gas line of the factory- required for the original solid-fuel fi replace into which built fi... -
Page 24: Remove Window
QUALIFIED Installation INSTALLER Remove Window The window is held in place by a spring-loaded lever on each side. 1. To remove the window, locate the levers on each side of the window towards the top. Using your fi nger, pull the lever towards you and unhook it from the window frame bracket. -
Page 25: Connect Venting
QUALIFIED Installation INSTALLER Connect Venting IMPORTANT: This appliance’s venting system is room sealed and therefore, does not require room air to be used in the combustion process. 1. Rough-in two 3” diameter vent liners into the existing chimney system from the roof. Be careful not to tear or damage the liners in the process. -
Page 26: Connect Gas Supply
QUALIFIED Installation INSTALLER Connect Gas Supply Pressure Test Points The gas supply inlet connection is a 1/2” NPT female. The minimum supply pressure is given in the section Gas shut-off valve supplied on the end of stainless Specifi cations of this manual—page 17. steel fl... - Page 27 QUALIFIED Installation INSTALLER Alternate Inlet Connection Use common elbow and fi ttings (not supplied) to redirect the position of In cases where local codes do not permit the fl ex the fl ex connector. NOTE: the fl ex connector to be used inside the appliance case, connector bend radius must be no reconnect the fl...
-
Page 28: Install Liner Panels
QUALIFIED Installation INSTALLER Remove and re-install burner (if necessary) 2. Place the rear panel against the back of the fi rebox, on the ledge at bottom, behind the burner. The ceramic panels can be installed without removing the burner. However, you can remove the burner for additional space if desired. -
Page 29: Install Ceramic Logs
QUALIFIED Installation INSTALLER Install Ceramic Logs Unpack the ceramic logs very carefully to avoid damaging them. Install the logs as shown below. Please note that the position of the logs is critical to insure proper performance of the appliance. When placing the base and middle logs, rotate them a little bit to anchor them into position. 1. - Page 30 QUALIFIED Installation INSTALLER 4. Place the center base log locating its notch on the key in the ember bed as indicated. The darkened part of this log should be on the left side. 5. Place the right-hand base log locating its notch on the key in the ember bed as indicated. 6.
- Page 31 QUALIFIED Installation INSTALLER 8. Place the right-hand cross log locating its notch on the key on the top of the rear log as indicated. Rest the front end of the log centered on top of the center base log. Ensure the logs do not cover the burner holes indicated here...
-
Page 32: Refi T And Check Window
QUALIFIED Installation INSTALLER Refi t and Check Window DANGER 1. Place the window in its bottom railing and push its The window unit must be correctly installed, top against the fi rebox. Ensure to remove any fastened and sealed after servicing or serious particles in the railing before installing the bodily injury and/or damage to the appliance window. -
Page 33: Synchronize Remote Control
QUALIFIED Installation INSTALLER Synchronize Remote Control 5. With a sharp object, press and hold the receiver’s reset button until you hear one short and one long The receiver and the handset of the remote control beeps. Release the reset button after the second system must be initially synchronized before the fi... -
Page 34: Check Operation
QUALIFIED Installation INSTALLER Check Operation In a few unusual installations, the fl ame picture may be improved by adjusting the aeration. The need for Turn the fi replace fl ame up and down using the adjustment should be determined only by operating the remote control to confi... -
Page 35: Install Side Shrouds
QUALIFIED Installation INSTALLER Install Side Shrouds Door hinge tabs The side shrouds are required to install the front on should face inwards the appliance. They are supplied with the engine. Fit them to the appliance outer case as indicated (2 screws/side). See instructions supplied with the front trim for installation of trim. -
Page 36: Wiring Diagram
QUALIFIED Wiring Diagram INSTALLER Optional Wall Switch Kit 1265WSK Connector Yellow Optional Fan Remote 795CFKV2 Battery Box Control Module 4 AA Batteries GV60 Wiring Diagram... -
Page 37: Approved Venting Components
QUALIFIED Approved Venting Components INSTALLER Approved Direct Vent Suppliers for Valor Models 700, 739 , 780, 785 and RF24DV Venting Parts Code / availability by Manufacturer Venting Parts Description 4DVC 940264 HSDV4658- Standard Co-axial 46DVA-VC 4DT-VC TM-4VT — 4DH-1313 — 940364 1313 940206LP... -
Page 38: Warranty
1. Extended Warranty Coverage For a period of up to ten (10) years, Miles Industries Ltd., (the “Company”) or its appointed distributor will at its option pay the initial owner for the repair of, or will exchange the following parts or components which are found to be defective in material or workmanship... -
Page 39: Spare Parts
OWNER’S Spare Parts INFORMATION Part Part Code Description Code Description Number Number Exhaust Slide Assembly 4002287 Injector elbow #1000 NG 4003985 Exhaust Slide Gasket 4000176 Injector elbow #360 LPG 4001494 Restrictor enclosure 4002330 Auxiliary battery holder 4002249 Metal strip 4002329 Ignition Cable 4001039 Restrictor assembly... - Page 40 OWNER’S Spare Parts INFORMATION Part Code Description Number Right side panel Ledgestone 4002366 Refl ective glass 4004709 Ceramic fl uted black 4002378 Valor red brick 4002383 Hot glass warning plate 4003093...
- Page 41 OWNER’S Spare Parts INFORMATION 3–7 27a, 27b 32 – 38...
-
Page 43: Miles Industries Ltd
Serial Number: Date Purchase (yyyy-mm-dd): Dealer: Customer Information First Name: Last Name: Contact Information Email: Mailing Address Address: City: Province/State: Postal/Zip Code: Country: Cut out page, fi ll information, and mail to Miles Industries Ltd. Online Warranty registration at www.valorfi replaces.com... -
Page 44: Miles Industries Ltd
Tape Shut Fold here Postage needed Miles Industries Ltd. 190 - 2255 Dollarton Highway North Vancouver, BC V7H 3B1 Canada Online Warranty registration at www.valorfi replaces.com Thank you for choosing a Valor Product...
