Miles Industries Retrofire RF24IDN Installation And Owner's Manual

Direct vent fireplace insert

Advertisement

Quick Links

RF24IDN (NG) & RF24IDP (LPG)
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other
fl ammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light the appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fi re department.
Installation and service must be performed
by a qualifi ed installer, service agency or the
gas supplier.
4002315-10
© 2012 Miles Industries Ltd. All rights reserved.
R
ETROFIRE
Direct Vent Fireplace Insert
Installation and Owner's Manual
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
Manufactured by
MILES INDUSTRIES LTD., British Columbia, Canada
www.valorfi replaces.com
I N S TA LL E R
L ea ve t h i s ma nu al
w i t h t h e a pp l i an ce.
C O N S U M ER
R et ai n t h i s m an ua l
f o r f u t ur e r ef e re nc e.
Please read this manual BEFORE installing
and operating this appliance.
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certifi ed kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Massachusetts: The piping and fi nal
gas connection must be performed by a
licensed plumber or gas fi tter in the State of
Massachusetts.
Ce guide est disponible en français sur demande.
US Patent no. 8,166,965

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Retrofire RF24IDN and is the answer not in the manual?

Questions and answers

Summary of Contents for Miles Industries Retrofire RF24IDN

  • Page 1 fi tter in the State of by a qualifi ed installer, service agency or the Massachusetts. gas supplier. Ce guide est disponible en français sur demande. Manufactured by MILES INDUSTRIES LTD., British Columbia, Canada www.valorfi replaces.com 4002315-10 © 2012 Miles Industries Ltd. All rights reserved.
  • Page 2: Table Of Contents

    Miles Industries Ltd. reserves the right printing. Miles Industries Ltd. reserves the right to change or modify any information or specifi ca- to change or modify any information or specifi...
  • Page 3: Safety Precautions

    Safety Precautions READ and UNDERSTAND all instructions carefully This unit MUST be used with a vent system as before starting the installation. FAILURE TO FOLLOW described in this installation manual. NO OTHER vent these installation instructions may result in possible fi re system or components MAY BE USED.
  • Page 4: Safety And Your Fireplace

    Safety and Your Fireplace Safety and Your Fireplace Please Read and Carefully Follow all Safety Warnings and Operating Instructions Contained in Your Owners Manual (Replacement Manuals are available by contacting our service department at 1-800-468-2567 or visit www.valorfi replaces.com). skills and response refl exes to Please Follow These Important withdraw in the event of accidental Child Safety Precautions and...
  • Page 5: Owner's Information

    Owner’s Information INFORMATION Thank You ... WARNING For purchasing a Valor by Miles Industries. Your new EXTREMELY HOT!!! radiant gas heater is a technical appliance that must be installed by a qualifi ed dealer. Each Valor fi replace • READ the SAFETY information on pages...
  • Page 6 After refi tting the window, apply light hand pressure particular case. against the window frame sides to bed-in the window NOTE: This is a problem beyond Miles Industries’ seal. control and is not covered under warranty. If the Hot Glass Warning plate has been removed •...
  • Page 7 OWNER’S Owner’s Information INFORMATION in the off-season will extend the battery life. Should the Checks batteries loose power, the control may be operated by periodic check of the pilot and burner fl ames should manually turning the control knob at the valve or by be made.
  • Page 8 OWNER’S Owner’s Information INFORMATION Manual ON/OFF Switch: Press the O button. Fireplace Control Devices There are three ways to control your fi replace. 1. Thermostatic Remote Control; 2. Wall Switch (optional); 3. Manual On/Off Switch. The manual On/Off switch must be ON for the fi replace to function.
  • Page 9: Remote Control Operation

    OWNER’S Remote Control Operation INFORMATION NOTE: Before using the remote control system for IMPORTANT: BEFORE YOU BEGIN, please note that the fi rst time, the receiver and the handset must be on this system, the settings of time, temperature and synchronized.
  • Page 10 OWNER’S Remote Control Operation INFORMATION • Press and hold (small fl ame) MODES OF OPERATION button to decrease fl ame height or • Briefl y pressing the SET button to set the appliance at pilot fl ame. changes the mode of operation in •...
  • Page 11 OWNER’S Remote Control Operation INFORMATION SETTING THE ON / OFF TEMPERATURES SETTING THE “NIGHTTIME SETBACK” SETTING THE “DAYTIME” TEMPERATURE TEMPERATURE (sun), 23ºC / 74ºF (moon), “ Default Settings: Default Settings: ” (OFF) TEMP T E M P • Briefl y press SET button to scroll to •...
  • Page 12 OWNER’S Remote Control Operation INFORMATION SETTING PROGRAM TIMERS SETTING P1 OFF TIME • You can program two periods of time between 12:00 • Briefl y press SET button to scroll am and 11:50 pm in each 24-hour cycle. to TIMER (moon) while the •...
  • Page 13: Options

    Pipe—generic 3” diameter fl exible aluminum liner RA24PK—to convert from Natural Gas to LPG approved for gas venting Hearth Gate (optional) Termination—Miles Industries’ 559CLT Co-Linear Hearth gates such as Cardinal’s VersaGates are Termination and 559SFK Square Flashing Kit are available at retail stores carrying safety products recommended for terminating existing masonry for children.
  • Page 14: Lighting Instructions

    OWNER’S Lighting Instructions INFORMATION FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING : If you do not follow these instructions exactly a re or ex losion ay result causin ro erty da a e ersonal in ury or loss of life A.
  • Page 15: Specifi Cations

    QUALIFIED Specifi cations INSTALLER This appliance is intended for installation into existing *High Altitude Installations masonry or factory-built, solid-fuel burning Input ratings are shown in BTU per hour and are fi replaces only. certifi ed without deration for elevations up to 4,500 feet (1,370 m) above sea level.
  • Page 16: Dimensions

    QUALIFIED Dimensions INSTALLER 23” 24-1/2” 24-3/8” 17-1/4” 8” 7-5/8” 1225VFB Ventana Fret (Black) 3” dia. 3” dia. RA24TB Fret (Black) Inlet 25-1/2” 27” Gas Inlet 3/8” NPT Female 11” 10” 1-1/2” RA24CV Fret (Vintage Iron) RA24AV Fret (Vintage Iron) Optional Frets Control Valve Location Front Face of...
  • Page 17: Vent Confi Gurations

    QUALIFIED Vent Confi gurations INSTALLER Where possible, avoid joints in fl ex pipe. If joints Allowable Vent Confi gurations are required, use only connectors approved by the The RF24 is certifi ed for use with approved 3” diameter manufacturer of the fl ex pipe. Field fabricated joints fl...
  • Page 18: Vent Termination

    QUALIFIED Vent Termination INSTALLER The RF24 is approved for Vertical Co-Linear Termination Only. Two 10” dia. 3” diameter liners are required from top to bottom. The vent liners must be connected to the proper collars (intake and exhaust) or the unit will not operate properly.
  • Page 19 QUALIFIED Vent Termination INSTALLER Vent Terminal Location The venting system for this appliance is considered to be a Special Venting System. The rule in the Installation Code CAN/CGA–B149 requiring a minimum vent height of 2 feet above any portion of a building within 10 feet does not, therefore, apply.
  • Page 20: Existing Fireplace Preparation

    QUALIFIED Existing Fireplace Preparation INSTALLER A few points must be considered before inserting the Gas Line Routing RF24 into an existing fi replace cavity. Generally, no Plan the routing of the gas line before proceeding. modifi cations are allowed to the existing fi replace that Utilize the existing hole for the gas line.
  • Page 21: Supply Gas Installation

    QUALIFIED Supply Gas Installation INSTALLER • It’s preferable to rough-in the gas line at this point • When testing for leaks: before proceeding with the fi rebox installation. • Make sure that the appliance is turned off. • The gas supply inlet connection is a 3/8” NPT •...
  • Page 22: Vent Liner Rough-In

    QUALIFIED Vent Liner Rough-in INSTALLER Rough-in the two 3” diameter vent liners into existing When connecting the liner in this manner it is best to chimney system being careful not to tear or damage leave the top termination until later so the slack liner the liners in the process.
  • Page 23: Firebox Installation

    QUALIFIED Firebox Installation INSTALLER Connection of liners to fi rebox Trim liners if necessary and connect to the fi rebox either while the fi rebox is on the hearth (Option 1) or with the fi rebox in the cavity (Option 2). Use gear clamps provided to connect the liners to the fi...
  • Page 24: Side View

    QUALIFIED Firebox Installation INSTALLER Leveling the fi rebox in the hearth The backside of each support leg has a leveling bolt. If necessary, adjust the level of the fi rebox in the hearth. Fret bracket Leveling Front Back Leveling bolt bolt Leveling bolt Side View...
  • Page 25: Ceramic Fuel Bed Installation

    QUALIFIED Firebox Installation INSTALLER Top Convection Baffl e Installation Position the fi rebox as far back as possible within the existing fi replace to allow ample space at front for the fret and to allow convection air to fl ow under the smoke curtain of the existing fi replace. Position the top convection baffl...
  • Page 26 QUALIFIED Ceramic Fuel Bed Installation INSTALLER L/H Log Locating Pins Place R/H Cross Log Place Middle Cross Log Onto Locating Pins Across Gap in Front Log Place L/H Cross Log Onto Locating Pins...
  • Page 27: Window Refi Tting And Checking

    QUALIFIED Window Refi tting and Checking INSTALLER 1. Hook the window over the top edge of the fi rebox, Check that Window and fasten the bottom two spring-loaded bolts by Moves Freely After pushing in and turning 90 degrees. Reinstallation IMPORTANT: To ensure a safe operation, verify that the bolts are hooked properly to the window tabs;...
  • Page 28: Operation Check And Aeration Adjustment

    QUALIFIED Operation Check and Aeration Adjustment INSTALLER Turn the fi replace up and down using the remote control to confi rm that the full range of inputs is achieved. Air Shutter Light the fi re and allow to warm up for 10–15 minutes to evaluate the fl...
  • Page 29: Optional Bottom Cover Installation

    QUALIFIED Optional Bottom Cover Installation INSTALLER Important: When the bottom cover is used instead of a fret, An area of 3/4 inch (19 mm) in front of the a space is required in front of the window to allow the window window MUST be kept clear at all times! to move and relieve during a hard start.
  • Page 30: Wiring Diagram

    QUALIFIED Wiring Diagram INSTALLER Optional Wall Switch Kit 1265WSK Connector Yellow GV60 Wiring Diagram...
  • Page 31: Approved Venting Components

    QUALIFIED Approved Venting Components INSTALLER Approved Direct Vent Suppliers for Valor Models 700, 739, 780, 785 and RF24DV Venting Parts Code / availability by Manufacturer Venting Parts Description 4DVC Standard Co-axial 46DVA-VC 4DT-VC TM-4VT — HSDV4658-1313 — 4DH-1313 High Wind Co-axial 46DVA-VCH —...
  • Page 32: Warranty

    1. Extended Warranty Coverage For a period of up to ten (10) years, Miles Industries Ltd., (the “Company”) or its appointed distributor will at its option pay the initial purchaser for the repair of, or will exchange the following parts or components which are found to be defective in material or...
  • Page 33 OWNER’S Spare Parts INFORMATION PART PART DESCRIPTION DESCRIPTION NUMBER NUMBER Firebox Assembly 4000634AH 2-Flame Pilot Hood 4000730 Restrictor (2) 4000767 Electrode 720A543 Convection Baffl e 4000744 Pilot Tube 4000732 Fret Support LH 4002837BY Thermocurrent Interruptor 4001037 Wing Nut (2) 4000741 GV60 Valve Complete NG 4003104 Leg LH...
  • Page 34: Spare Parts

    OWNER’S Spare Parts INFORMATION 50a, 50b 51a, 51b 8a, 8b 14a, 12a, 12b 34a, 29a, 29b 39a, 39b...
  • Page 35: Miles Industries Ltd

    Serial Number: Date Purchase (yyyy-mm-dd): Dealer: Customer Information First Name: Last Name: Contact Information Email: Mailing Address Address: City: Province/State: Postal/Zip Code: Country: Cut out page, fi ll information, and mail to Miles Industries Ltd. Online Warranty registration at www.valorfi replaces.com...
  • Page 36: Miles Industries Ltd

    Tape Shut Fold here Postage needed Miles Industries Ltd. 190 - 2255 Dollarton Highway North Vancouver, BC V7H 3B1 Canada Online Warranty registration at www.valorfi replaces.com Thank you for choosing a Valor Product...
