- Page 1 Black Glass Fire Pit Table Installation Instructions GLASS-42 P a g e...
- Page 2 Included Allen (x1) (x3) (x4) (x7) Wrenches M8X35 M8X16 M6X16 M6X12 Glass Top Hose clamp Hose Clamp Control Panel Lower Ring Upper Ring Legs Screw Caps (Simply press over any visible screw 42424 Rev A-8/18/2011 P a g e heads after installation)
- Page 3 Step 1 Attach Legs Step 2 Fasten Lower Ring First 3 legs only P a g e...
- Page 4 Step 3 Control Panel Assembly Step 4 Mount Control Panel Table shown in inverted position P a g e...
- Page 5 Step 5 Secure Gas Line Table shown in inverted position Gas line may pass through bracket “G” in whichever direction suits tank location best. P a g e...
- Page 6 IMPORTANT Please consult your Crystal Fire instruction manual for detailed instructions and important information Step 6 related to hooking up your CF-20 burner, including Insert CF-20 Burner safety information, proper tightening of connections with two wrenches and full burner setup and lighting instructions.
- Page 7 THIS PAGE INTENTIONALLY LEFT AWESOME. Warranty: Fire Pit is covered under a 1-year manufacturer’s warranty. Please visit http://www.outdoorrooms.com/warranty-form to register your product. 2015 Silver Bell Road • Suite 195 • Toll Free: 1-866-303-4028 P a g e...
- Page 8 © 2011 The Outdoor GreatRoom Company P a g e...
