Assembly and Installation instructions for Natural Gas DIY-38, DIY-2032, DIY-2049
Thank you for purchasing a Do-It-Yourself gas fire pit kit from The Outdoor GreatRoom Company. Please read through all

Included in your DIY kit

DIY-2032 (Rectangular)
 Burner
 Electronic igniter
 Metal flex hose
 4-piece DIY burner support
 (8) Nut, bolt , lock washer
 (2) Black #6 – 5/8" screws
 #31 Orifice (NG)
 #43 Orifice (LP)
 Control panel with mounting
bracket and optional filler.
 Grounding wire
 Sparker extension wire

Recommended tools and supplies

2 adjustable wrenches for tightening gas connections
7/16" wrench for assembling burner support
Power drill with Phillips bit
AAA Battery for igniter (not included)
Lava rock or other decorative media* (sold separately)
Masonry block
Outdoor-rated construction adhesive for securing block and control panel (if desired)
Leveling device for placing block
Concrete chisel
¼" concrete anchors (optional for attaching control panel bracket to block)
Hammer drill (for drilling holes for concrete anchors)
*lava rock, heat-tempered glass, or other decorative fire-safe medium MUST be used to ensure proper
burner operation. Do not burn without covering burner with lava rock or similar.
Dimensions for recommended
fire pit sizing located on page 5
DIY Gas Fire Pits
instruction steps and warnings before assembling your fire pit.
NOTE: If using a 20lb propane tank, an LP kit is available for purchase
on page 5 of this instruction booklet.
DIY-2049 (Long Rectangular)
 Burner
 Electronic igniter
 Metal flex hose
 6-piece DIY burner support
 (12) Nut, bolt , lock washer
 (2) Black #6 – 5/8" screws
 #21 Orifice (NG)
 #31 Orifice
 Control panel with mounting
bracket and optional filler.
 Grounding wire
 Sparker extension wire
(LP Over 100lb tank)
Consult your Crystal Fire Owner's manual included in
this kit for important safety and other information
before operating this burner.
GAS-FIRED
DIY-38 (Round)
 Burner
 Electronic igniter
 Metal flex hose
 4-piece DIY burner support
 (8) Nut, bolt , lock washer
 (2) Black #6 – 5/8" screws
 #17 Orifice (NG)
#36 Orifice
(LP over 100lb tank)
 Control panel with mounting
bracket and optional filler.
 Grounding wire
 Sparker extension wire
90246 REV C 6/10/13 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIY-2032 and is the answer not in the manual?

Questions and answers

Summary of Contents for Outdoor GreatRoom Company DIY-2032

  • Page 1 GAS-FIRED Assembly and Installation instructions for Natural Gas DIY-38, DIY-2032, DIY-2049 Thank you for purchasing a Do-It-Yourself gas fire pit kit from The Outdoor GreatRoom Company. Please read through all instruction steps and warnings before assembling your fire pit. NOTE: If using a 20lb propane tank, an LP kit is available for purchase Included in your DIY kit on page 5 of this instruction booklet.
  • Page 2 Step 1: Assembling the burner support DIY-38 DIY-2032 DIY-2049 Step 2: Installing the Control Panel (suggested method for common cases) Insert AAA battery (not included) Control panel front can be removed in the Filler (optional) for taller future for access to gas valve and maintenance.
  • Page 3 Step 3: Placing the control panel (suggested method for common cases) While the control panel included in your kit is meant to work universally for most fire pit block sizes, for extreme cases, blocks may need to be cut to ensure a perfect fit. See below for installation methods. Option 1: Option 2: For smaller block sizes...
  • Page 4 Step 4: Making Connections Follow the steps below for making proper grounding, ignition, and gas line connections.  Connect grounding wire to sparker box as shown. Note: Some burner models may include a second (orange) wire. This is not used for this installation Not used ...
  • Page 5 Decorative gas log sets and high-temperature glass fire gems can also be purchased from The Outdoor GreatRoom Company at OutdoorRooms.com Fire Pit Dimension Ranges (dimensions given refer to range of interior dimensions that can be used to create a fire pit.
  • Page 6 #43 LP Orifice, 10ft Propane hose with regulator Heat tempered glass fire gems CFG-D One 4lb bag of glass fire gems (8 bags recommended for DIY-2032, 13 bags for DIY-2049, 14 bags for DIY-38) Black Lava rock LAV-BK .5 cubic foot bag of black natural lava rock...
  • Page 7 The Outdoor GreatRoom Company; and/or (6) modification of the Product not expressly authorized and approved in writing by The Outdoor GreatRoom Company. Any of the circumstances described in the previous sentence voids this warranty. This warranty is void if the Product or any component has been removed, repaired, or replaced before The Outdoor GreatRoom Company has been afforded a reasonable opportunity to inspect the Product.
