SETUP
TITLE
If ON is selected, you can display the camera title on the screen. If enabled,
OFF / ON
manually enter the camera's display name using the joystick controller.
INTERNAL SYNC.
Select whether the camera syncronizes internally or using Line Lock.
INT/
COMMUNICATION
The Communications settings allow you to setup the camera's ID, Baudrate, Protocol,
and UTC.
- CAM ID: Provide an ID number for the camera ( 0 ~ 255 ).
- ID DISP.: Decide to show the ID on screen or not. Select ON & OFF.
- BAUDRATE: 9600bps is default. Select the baudrate from the following options:
2400/4800/9600/57600 and 115200bps.
- PROTOCOL: Set as PELCO-D/ PELCO-P.
- UTC: Automatically set UTC as 15/ 32 BIT.
