  • Page 1 Vi-GSUB Manual 1.1 en...
  • Page 2 General information Vi-GSUB Manual Version: 1.1 en, 08/2015, D2725.EN .01 Copyright © 2015 by d&b audiotechnik GmbH; all rights reserved. Keep this manual with the product or in a safe place so that it is available for future reference. When reselling this product, hand over this manual to the new owner.
  • Page 3 Vi-GSUB loudspeaker............. 5 2.1. Product description..............5 2.2. Connections................5 2.3. Operation................7 2.3.1. Controller settings..............8 2.4. Technical specifications............8 Manufacturer's declarations........10 3.1. EU conformity of loudspeakers (CE symbol)....... 10 3.1.1. WEEE Declaration (Disposal)........... 10 d&b Vi-GSUB Manual 1.1 en...

  • Page 4: Safety Precautions

    Generally speaking, a distance of 0.5 m (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient; a distance of more than 1 m (3 ft) may be necessary with computer and video monitors. d&b Vi-GSUB Manual 1.1 en...

  • Page 5: Vi-Gsub Loudspeaker

    The Vi-GSUB is a compact high performance cardioid subwoofer for use with d&b V-Point cabinets. The Vi-GSUB houses two long excursion neodymium drivers in an integrated cardioid setup: an 18“ driver in a bass-reflex design facing to the front and a 12” driver in a two chamber bandpass design radiating to the rear.
  • Page 6 Fixed cable connection The Vi-GSUB loudspeaker is supplied with a cover plate [1] and a rubber grommet feed through [2]. For indoor operation, these items can be used to hide the connector panel, if required. For unprotected outdoor operation, the connector panel must be covered, i.e.

  • Page 7: Operation

    Application Setup Cabinets per channel Vi-GSUB V-GSUB Within applicable d&b amplifiers (except for the D6 amplifier), the controller setup is available in Dual Channel or Mix TOP/SUB mode. d&b Vi-GSUB Manual 1.1 en...

  • Page 8: Controller Settings

    It can be used when actively driven Vi-GSUBs are used to supplement V-Point cabinets operated in full range mode. The 100 Hz mode can also be used to compensate for the effect of close coupling between the Vi-GSUB and V-Point cabinets operated in CUT mode. 2.4. Technical specifications Vi-GSUB system data Frequency response (–5 dB standard)
  • Page 9 Vi-GSUB cabinet dimensions in mm [inch] d&b Vi-GSUB Manual 1.1 en...

  • Page 10: Manufacturer's Declarations

    Please dispose of this product according to the respective national regulations or contractual agreements. If there are any further questions concerning the disposal of this product, please contact d&b audiotechnik. d&b Vi-GSUB Manual 1.1 en...
