Operation - ADJ HEXCON User Instruction

HEXCON
Note: When the power is switched Off and then back On, the
controller will return to the last operating mode.
Color Fade Mode:
1. Press the COLOR FADE button (3) and the corresponding LED
above the button will light.
2. Use faders (16, 17 & 18) to adjust output intensity, fade speed, and
chase speed. Use faders (13 & 14) to adjust the White LEDs
and UV LEDs intensity.
3. Press the STROBE button (6) to activate the strobe function and
use the STROBE SPEED fader (15) to adjust the strobe speed.
Color Macro Mode:
1. Press the COLOR MACRO button (5) and the corresponding LED
above the button will light.
2. You can use the COLORS/CHASE GRID (19) or MEMORY BUT-
TONS (12) to select a desired color. You can use the RED/CHASE
SPEED fader (18) to scroll through the color macros.
3. Use faders (16 & 17) to adjust all LED intensity and fade speed.
Use faders (13 & 14) to adjust the White LEDs and UV LEDs inten-
sity.
4. Press the STROBE button (6) to activate the strobe function and
use the STROBE SPEED fader (15) to adjust the strobe speed.
Auto Mode:
1. Press the AUTO button (7) and the corresponding LED above the
button will light.
2. Use the faders (16, 17 & 18) to adjust output intensity, fade time,
and chase speed. Use faders (13 & 14) to adjust the White LEDs
and UV LEDs intensity.
3. Press the STROBE button (6) to activate the strobe function and
use the STROBE SPEED fader (15) to adjust the strobe speed.
Chase Mode:
1. Press the CHASE button (9) and the corresponding LED above the
button will light.
2. Press 1 of the 24 COLOR buttons (19) located in the Color/Chases
grid, or 1 of the 6 MEMORY BUTTONS (12) to activate a chase.
3. Once your desired chase program has been selected, use the
faders (16, 17 & 18) to adjust output intensity, fade speed, and
ADJ Products, LLC www.adj.com - HEXCON

Operation

HEXCON
4. Press the STROBE button (6) to activate the strobe function and
Manual RGBWA+UV Color Mode:
1. Press the MANUAL button (2) and the corresponding LED above
2. Press any of the COLOR/CHASE BUTTONS (19), MEMORY but-
3. Press the STROBE button (6) to activate the strobe function and
NOTE: When strobe is activated the WHITE ouput will be dis-
abled.
Sound Active Mode:
1. Press the SOUND button (4) and the corresponding LED above the
2. Use the SOUND SENSITIVITY knob located at the rear to adjust
3. Use the faders (16 & 17) to adjust output intensity and fade speed.
4. Press the STROBE button (6) to activate the strobe function and
Strobe:
1. Press the STROBE button (6) and the corresponding LED above
2. Use the STROBE SPEED fader (15) to adjust the strobe speed.
Preset Mode: Using these buttons you are able to save and recall a
chase, fade, or color.
1. To save a chase, fade, or color, press the PRESET button (8) to
2. To recall the saved chase, fade, or color, press the PRESET button
Page 13
chase speed. Use faders (13 & 14) to adjust the White LEDs
and UV LEDs intensity.
use the STROBE SPEED fader (15) to adjust the strobe speed.
the button will light.
tons, or use the RGBWA+UV faders (13, 14, 15, 16, 17, & 18) to
adjust the LED intensities and create your own desired color.
use the STROBE SPEED fader (15) to adjust the strobe speed.
button will light.
the sound sensitivity level.
Use faders (13 & 14) to adjust the White LEDs and UV LEDs inten-
sity.
use the STROBE SPEED fader (15) to adjust the strobe speed.
the button will light.
acitvate. To save the chase, fade, or color, press 1 of the 6
MEMORY/RGBWA+UV buttons (12) for at least 3 seconds. When
all of the LEDs flash 3 times, this informs you that the save was
successful.
ADJ Products, LLC www.adj.com - HEXCON
Operation
Page 14
