- Page 1 Vandal Resistant Fixed Dome Cameras DM/ICEVC-BH39 DM/ICEVS-BH39 DM/ICEVS-OBH39 DM/ICEVC-CMH39 DM/ICEVS-CMH39 DM/ICEVS-OCMH39 DM/ICEVC-CMU39 DM/ICEVS-CMU39 DM/ICEVS-OCMU39 DM/ICEVC-DNU39 DM/ICEVS-DNU39 DM/ICEVS-ODNU39...
-
Page 2: Table Of Contents
Contents Introduction ............3 Important Safeguards........4 Installation ............5 Switch Settings..........8 Appendix ............10 Quickstart ............11 Template............15 Whilst every attempt is made to ensure these manuals are accurate and current, Dedicated Micros reserve the right to alter or modify the specification of the machine described herein without prejudice. Dedicated Micros ©2007... -
Page 3: Introduction
Introduction These instructions cover ICE series fixed dome cameras. Read all of these instructions. Use them to install your camera and have them available for its lifetime. If you have any problems, contact your agent. Models Mono high resolution 570 TVL 0.07 lux at F1.2 Vandal Resistant DM/ICEDVC-BH39... -
Page 4: Important Safeguards
Important Safeguards Product Safety WARNING • Installation and servicing is only to be carried out by suitably qualified and experienced personnel. • Do not remove covers as there is a risk of injury or death by electric shock. • Only power low voltage dome cameras from a class 2 isolated power supply. This camera range is designed for use in general purpose CCTV applications and has no other purpose. -
Page 5: Installation
Installation The ICE fixed dome camera is available in two versions: the ceiling mount version for installation into a ceiling tile of up to 1.5” (38 mm) thickness; and the surface mount version for installation directly onto a hard surface or mounting structure. When installing the outdoor vandal resistant dome you must set the jumpers on the thermostat PCB to the correct supply voltage being used. - Page 6 Note: This dome uses non standard Torx screws for increased security, which can only be unfastened using the provided tool. Surface Mount Installation Refer to the Quickstart section for more information. Video and power cables enter the camera body inside a plastic or metal conduit either from the side or rear of the camera.
-
Page 7: Camera Adjustment
Camera Adjustment Camera Position The camera assembly is adjustable in all three axes. Adjust the camera until it is pointing in the desired direction. FOV & Focus Use the levers on the varifocal lens to adjust the camera’s field of view, and focus. Dedicated Micros ©2007... -
Page 8: Switch Settings
Switch Settings The DIP switches are located on the camera’s circuit board. Backlight Compensation Automatic Gain Control Electronic Iris Colour Burst Default setting White indicates switch position Backlight Compensation The Backlight Compensation (BLC) feature compensates for back-lit scenes by enhancing objects in the centre of the scene which would previously have been in silhouette. -
Page 9: Final Assy
Day/Night (DN Versions only) This switch sets the light level at which the camera automatically switches between day and night operation. Hi sets the camera to switch between day and night mode at higher light level. Lo sets the switching point at a lower light level. The default setting is Lo. When in Night mode, the IR cut filter is removed allowing infra red illumination to be used. -
Page 10: Appendix
Appendix Dimensions VC version 112 mm 160 mm 4.41" 6.30" 160 mm 96 mm 6.30" 3.78" 66 mm 2.60" 104 mm 148 mm 4.09" 5.83" 95 mm 148 mm 3.74" 5.83" 55 mm 2.17" VS version Dedicated Micros ©2007... -
Page 11: Quickstart
Quickstart VS VERSIONS Dedicated Micros ©2007... - Page 12 Dedicated Micros ©2007...
- Page 13 Quickstart VC VERSIONS Dedicated Micros ©2007...
- Page 14 Dedicated Micros ©2007...
-
Page 15: Template
Template Pattern for VC Ceiling Dome 5mm( ”) 16mm( ”) NOT TO SCALE Pattern for VS Ceiling Dome 15mm 57mm ø8mm NOT TO SCALE Dedicated Micros ©2007... - Page 16 1200 Daresbury Park, Daresbury, Cheshire, WA4 4HS, UK Dedicated Micros Europe Dedicated Micros USA. Neckarstrafle 15, 23456 Hawthorne Blvd. 41836 Hückelhoven, Germany Suite 100, Torrance, CA 90505, USA Dedicated Micros France Dedicated Micros, Australia PTY. 9-13 rue du Moulinet 5/3 Packard Avenue, Castle Hill, 75013 Paris, France NSW 2154, Australia Dedicated Micros Slovenia Dedicated Micros, Asia PTY Delavska cesta 26, 16 New Industrial Road, 4208 Sencure, Slovenia...
