- Page 1 Pneumatic Flux Chipper #505820, JAT-820 Operation & Parts Manual M-505820 Edition 1 02/2015 427 New Sanford Road LaVergne, TN 37086 Ph.: 800-274-6848 www.jettools.com Copyright © 2015 JET...
-
Page 2: Warranty And Service
Accessories; Shop Tools; Warehouse & Dock products; Hand Tools NOTE: JET is a division of JPW Industries, Inc. References in this document to JET also apply to JPW Industries, Inc., or any of its successors in interest to the JET brand. -
Page 3: Safety Warnings
10. The air tool must be properly lubricated before operating. Do not use this tool for other than its intended use. If used for other purposes, JET disclaims 11. Never start a percussion type air tool (chipper, any real or implied warranty and holds itself breaker, buster, etc.) without securing the... - Page 4 22. Shut off air supply and discharge any residual 33. Do not lubricate the tool with combustible pressure from tool before removing hose, liquids, such as kerosene, diesel or jet fuel. making adjustments, changing accessories, 34. Do not dispose of this tool with normal or storing tool.
-
Page 5: About This Manual
As with any tool operation, safety of operator and bystanders should be first priority. If there are questions or comments, please contact your local supplier or JET. JET can also be reached at our web site: www.jettools.com. -
Page 6: Tool Specifications
Specifications were current at time of publication, but because of our policy of continuous improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring obligations. -
Page 7: Setup And Assembly
Any missing parts or damage should be reported Press throttle lever. Pressure against throttle ® immediately to your JET distributor. Do not use a lever determines speed of tool. Do not exert damaged tool. Read this instruction manual excessive pressure against work surface –... - Page 8 (See also “Troubleshooting” Use a light oil containing rust inhibitors, such as section.) SAE #10. Many JET air tools have integral oil • reservoirs, which should be kept filled when in-line Contaminated air such as a dirty air system oilers are not used.
- Page 9 Figure 2 Recommended arrangement of air piping and air line system ...
- Page 10 Troubleshooting JAT-820 Flux Chipper Any disassembly of the tool should be done by qualified service personnel. For problems not addressed below, contact JET technical service at 800-274-6846. Problem Possible cause Remedy Tool will not start. Air valve closed or obstructed.
- Page 11 #505820, JAT-820, Flux Chipper – parts breakdown Index Part No. Description Index Part No. Description F25-01 Cylinder cap 13 F25-11 Pin 2.8x11 F25-02 Throttle bushing 14 F25-14 Piston F25-03 Throttle rod 15 JAT820-15 Cylinder F25-04 O-Ring 3.8x1.9 16 F25-16 Piston sleeve...
-
Page 12: Replacement Parts
5:00 p.m. CST. Please have the stock number and serial number of your tool available when you call, so that we may serve you quickly and accurately. 427 New Sanford Road LaVergne, Tennessee 37086 Phone: 800-274-6848 www.jettools.com JAT-820 Pneumatic Flux Chipper ...
