- Page 1 Pneumatic Ratchet Wrench #505320, JAT-320 #505321, JAT-321 Operation & Parts Manual M-505320 Edition 1 02/2015 427 New Sanford Road LaVergne, TN 37086 Ph.: 800-274-6848 www.jettools.com Copyright © 2015 JET...
-
Page 2: Warranty And Service
Accessories; Shop Tools; Warehouse & Dock products; Hand Tools NOTE: JET is a division of JPW Industries, Inc. References in this document to JET also apply to JPW Industries, Inc., or any of its successors in interest to the JET brand. -
Page 3: Safety Warnings
10. The air tool must be properly lubricated before operating. Do not use this tool for other than its intended use. If used for other purposes, JET disclaims 11. Never start a percussion type air tool (chipper, any real or implied warranty and holds itself breaker, buster, etc.) without securing the... - Page 4 33. Do not lubricate the tool with combustible or storing tool. liquids, such as kerosene, diesel or jet fuel. 23. Make sure tool is switched off, and your finger 34. Do not dispose of this tool with normal off the trigger, before connecting to air supply.
-
Page 5: About This Manual
As with any tool operation, safety of operator and bystanders should be first priority. If there are questions or comments, please contact your local supplier or JET. JET can also be reached at our web site: www.jettools.com. -
Page 6: Tool Specifications
Specifications were current at time of publication, but because of our policy of continuous improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring obligations. -
Page 7: Setup And Assembly
Setup and Assembly reverse (R) rotation. Any missing parts or damage should be reported ® immediately to your JET distributor. Do not use a Make sure nut or bolt can damaged tool. Read this instruction manual withstand rated torque of ratchet wrench. -
Page 8: Maintenance
Tool Pressure mechanisms. Always oil the tool and disconnect air hose before storage. JET Air Tools operate on 70-to-100 psi (pounds per square inch) air pressure measured at the tool Air system requirements when the tool is operating. Set tool to 90 psi unless indicated otherwise. - Page 9 Use a light oil containing rust inhibitors, such as directly, rather than with quick connect fittings SAE #10. Many JET air tools have integral oil which may cause pressure drops and tool power reservoirs, which should be kept filled when in-line reduction.
- Page 10 Troubleshooting JAT-320/321 Ratchet Wrenches Any disassembly of the tool should be done by qualified service personnel. For problems not addressed below, contact JET technical service at 800-274-6846. Problem Possible cause Remedy Tool will not start. Air valve closed or obstructed.
-
Page 11: Replacement Parts
Replacement parts Service parts are listed on the following pages. To order parts or reach our service department, call 1-800- 274-6848 Monday through Friday, 8:00 a.m. to 5:00 p.m. CST. Please have the stock number and serial number of your tool available when you call, so that we may serve you quickly and accurately. ... - Page 12 #505320, JAT-320, 1/4-inch Ratchet Wrench – exploded view 4 3 4 2 4 1 JAT-320,321 Ratchet Wrenches ...
- Page 13 #505320, JAT-320, 1/4-inch Ratchet Wrench – parts list Index Part No. Description Index Part No. Description JAT320-01 Air inlet JAT320-30 Ratchet housing assembly JAT320-02 Motor housing JAT320-32 Drive bushing JAT320-03 Throttle valve JAT320-33 Ratchet yoke JAT320-04 Spring JAT320-34 Ratchet housing cover O-Ring P8 NBR A70±5...
- Page 14 #505321, JAT-321, 3/8-inch Ratchet Wrench – exploded view 4 3 4 2 4 1 JAT-320,321 Ratchet Wrenches ...
- Page 15 #505321, JAT-321, 3/8-inch Ratchet Wrench – parts list Index Part No. Description Index Part No. Description JAT320-01 Air inlet JAT320-30 Ratchet housing assembly JAT320-02 Motor housing JAT320-32 Drive bushing JAT320-03 Throttle valve JAT320-33 Ratchet yoke JAT320-04 Spring JAT320-34 Ratchet housing cover O-Ring P8 NBR A70±5 JAT321-35 Direction switch JAT320-05...
- Page 16 427 New Sanford Road LaVergne, Tennessee 37086 Phone: 800-274-6848 www.jettools.com...
