OSD menu functions

The OSD menu for analogue monitor operation is described below. During
digital operation some functions are not available, as they are not required
due to the digital transmission technology used.

Adjusting the brightness and contrast

Brightness
Contrast
Black level
Auto level
If the contrast is set too high, bright surfaces can no longer be distinguished from very
bright surfaces. If the contrast is set too low, the maximum brightness will not be achieved.

Adjusting the picture size and position

Phase
Clock
H-Position
V-Position
Expansion
26
Call up the Brightness/Contrast setting window
Set the brightness of the display
With this function you change the brightness of the background lighting.
Set the contrast of the display
With this function you modify the contrast of bright colour tones.
Set the brightness of the display
With this function you modify the contrast of dark colour tones.
Adjust the signal level
With this function you can automatically set the contrast.
The function is executed with the
Call the Image adjust setting window
Eliminate picture disturbance
With this function you fine-tune your monitor to eliminate picture disturbance.
Set synchronisation
With this function you adjust the picture width to eliminate vertical picture
disturbances.
Adjust the horizontal position
With this function you move the picture to the left or to the right.
Adjust the vertical position
With this function you move the picture up or down.
Adjust the picture size
Full screen = selection of full screen mode
Keep aspect = maximum picture size without distortion
button.
