User Guide SoundPoint IP 560 Phone
1 - 4
AC Power
To connect the AC power:
1.
Connect the supplied network cable between the LAN jack on the phone
and the LAN port on the wall or hub/switch device port.
Connect the DC plug on the power adapter to the DC 48V jack marked on
2.
the phone.
Connect the country-specific AC cord to the power adapter.
3.
Power
Adapter
(48V DC)
Network
Port
Power over Ethernet
Using a regular CAT5 cable (optional accessory from Polycom), the phone can
be powered from a PoE (IEEE 802.3af) compliant switch or hub.
PC Connection
(optional)
