LIABILITY RELEASE In that Mountain Models has no control over the final assembly or material used for final assembly, no liability shall be assumed or accepted for any damage resulting from the use by the user of the final user- assembled product.
Page 2
09/13/2010 1.1 Production Release Thank you for purchasing the Mountain Models Taylorcraft. The Taylorcraft is a super lightweight, easy to fly, but fun to toss around Depron plane. High quality laser cut Depron and plywood parts make the assembly of this laser cut model airplane kit a breeze! We think you’ll find this plane to be a lot of fun, being able to be flown indoors and...
Parts List Number in Kit Description of Part 1 Set 3mm Depron Parts 1/64” Plywood LE & TE Reinforcements 1/16” Plywood Firewall 1/32” Plywood Sheet 1/32” Balsa Sheet 3/32” Balsa Sheet 0.032” x 12” Wire 0.045” x 12” Wire Bagged Parts Wheels DuBro Wheel Keepers 1/64”...
Page 4
Step 1: Glue the 1/64" plywood leading and trailing edge reinforcements in place on the wing, as shown. Use a slower setting foam safe CA or 10 minute epoxy (sparingly). Make sure the wing is flat and that the plywood is fully seated against the foam.
Page 5
If you are using a slower setting glue, you can assemble/glue up the entire fuselage at once. Step 4: Glue the formers in place on the crutch, as shown in the image. MAKE SURE that the plywood firewall is glued so the engraved text faces FORWARD.
Page 6
Step 7: Step 8: Bend the Glue the 1/32" landing gear wires, as balsa landing gear mount shown in the wire drawing together, using thick CA, sheet on the last page of this with the landing gear wire manual. in between. Step 9: Glue the landing gear fairings onto the...
Page 7
Step 14: Glue the stabilizer and vertical fin in place, as shown. MAKE SURE that the stabilizer is horizontal and that the vertical fin is at a 90 degree angle to the stabilizer. Step 15: Bevel the hinge side Step 16: Glue the 1/64"...
Page 8
Step 18: Slide the elevator and rudder pushrods into the fuselage, as shown in the drawing. The adjustment "V" bends go inside the fuselage. Step 19: Slide the elevator onto the elevator pushrod and use tape to hinge the elevator to the stabilizer.
Page 9
Step 25: Hook up your radio and make sure everything works, the servos are centered, the rudder and elevator are centered, and your controls are moving the right direction. Step 27: Set your control throws to: LOW RAETS: Rudder: 3/8" each way Elevator: 5/16"...
