  • Page 1 IES-1000 Integrated Ethernet Switch Version 1.0 March 2002 User’s Guide...

  • Page 2: Copyright

    ZyXEL Communications Corporation. Published by ZyXEL Communications Corporation. All rights reserved. Disclaimer ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein.

  • Page 3: Interference Statements And Warnings

    IES-1000 User’s Guide Interference Statements and Warnings Interference Statement: This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operations.

  • Page 4: Zyxel Limited Warranty

    IES-1000 User’s Guide ZyXEL Limited Warranty ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or workmanship for a period of up to two years from the date of purchase. During the warranty period, and upon proof...

  • Page 5: Customer Support

    IES-1000 User’s Guide Customer Support Please have the following information ready when you contact customer support. • Product model and serial number. • Warranty information. • Date that you received your device. • Brief description of the problem and the steps you took to solve it.

  • Page 6: Table Of Contents

    ZyXEL Limited Warranty ............................iv Customer Support ..............................v List of Figures ................................x List of Tables................................x Preface ..................................xi Chapter 1 Getting to Know the IES-1000......................1-1 1.1 Features ................................. 1-1 1.2 Physical Specifications..........................1-3 1.2.1 Physical Interfaces..........................1-3 1.2.2 Dimensions............................1-3 1.2.3 Weight ..............................
  • Page 7 IES-1000 User’s Guide 4.5.1 Info Command............................4-3 4.5.2 Set Name Command..........................4-3 4.5.3 Set Contact Command........................... 4-4 4.5.4 Set Location Command......................... 4-4 4.5.5 Set Mode ............................... 4-4 4.6 Secured Host Commands ..........................4-4 4.6.1 Secured Host Command........................4-4 4.6.2 Secured Host Add Command........................ 4-5 4.6.3 Secured Host Delete Command ......................
  • Page 8 IES-1000 User’s Guide 7.1.3 Status Command............................ 7-1 7.3 MACfilter Commands........................... 7-2 7.3.1 MACfilter Command..........................7-2 7.3.2 Macfilter Enable Command ........................7-2 7.3.3 Macfilter Disable Command ......................... 7-2 7.3.4 Macfilter Add Command........................7-2 7.3.5 Macfilter Delete Command ........................7-3 7.4 Filter Commands ............................7-3 7.4.1 Filter Command.............................
  • Page 9 IES-1000 User’s Guide Chapter 11 Remote Management ........................11-1 11.1 Management by Telnet ..........................11-1 11.2 SNMP Management ..........................11-1 11.2.1 Supported MIBs ..........................11-2 11.3 SNMP Access Configuration ........................11-2 11.3.1 SNMP Access Read/Write Command..................... 11-2 11.3.2 SNMP Access Delete Command..................... 11-3 11.3.3...
  • Page 10 Table 5-1 Data Rates of the IES-1000’s SHDSL Ports ..................... 5-1 Table 5-2 List Port Command - <State> Parameter ....................5-4 Table 7-1 Physical Ports, Port Numbers and IES-1000 Default PVID Tags in Fast Mode ........7-9 Table 14-1 Troubleshooting the SHDSL LED(s) ....................14-1 Table 14-2 Troubleshooting Data Transmission......................

  • Page 11: Preface

    About the IES-1000 The IES-1000 is an integrated Ethernet switch that allows you to multiplex up to 16 G.SHDSL lines of traffic to an Ethernet network using existing phone line wiring before it is forwarded to the Internet. When deployed together with ZyXEL’s SHDSL modems and WAN routers, the combination forms an integrated solution for providing...

  • Page 13: Chapter 1 Getting To Know The Ies-1000

    This chapter describes the key features, benefits and applications of your IES-1000. The IES-1000 is an integrated Ethernet switch that allows you to multiplex up to 16 G.SHDSL lines of traffic to an Ethernet network before it is forwarded to the Internet. When deployed together with ZyXEL’s SHDSL modems and WAN routers, the combination forms an integrated solution for providing broadband services to multiple tenant units such as apartments, hotels, offices and campus buildings.

  • Page 14: Ieee 802.1P Priority

    Allow up to ten remote hosts to access your IES-1000 via IP addresses you specify. System Error Logging The system error log will record error logs locally to the IES-1000 memory. These logs may be viewed again after a warm restart.

  • Page 15: Physical Specifications

    A tenant connects a computer to the phone line in a unit using a G.SHDSL modem. The other end of the phone line is connected to a port on the IES-1000. The IES-1000 aggregates the traffic from tenants to the Ethernet port and then forwards it to a router.

  • Page 16: Figure 1-1 Mtu Application

    IES-1000 User’s Guide Figure 1-1 MTU Application Getting to Know the IES-1000...

  • Page 17: Leased Line Application

    IES-1000 User’s Guide 1.3.2 Leased Line Application Figure 1-2 Leased Line Application Getting To Know The IES-1000...

  • Page 19: Chapter 2 Hardware Overview

    9600 bps No parity, 8 data bits, 1 stop bit No flow control Front Panel The following figure shows the front panel of the IES-1000 with two installed SAM1008 network modules. Figure 2-1 Front Panel 2.2.1 SAM1008 Front Panel LEDs The following table describes the LED indicators on the front panel of a SAM1008 network module.

  • Page 20: Front Panel Ports

    SHDSL 1-8 The ports (labeled 1-8) connect to subscriber G.SHDSL equipment. CONSOLE The CONSOLE port is an RJ-11 port used for configuring the IES-1000. This port connects to a local computer. Table 2-3 Front Panel Ports of the IES-1000 PORT...

  • Page 21: Ports 1-8 (G.shdsl Ports)

    POWER Port Connect the female end of the power cord to the power receptacle on the front panel of your IES-1000. Connect the other end of the cord to a power outlet. Make sure that no objects obstruct the airflow of the fans. If you are facing the IES-1000 front panel, the fan vents are located on the left side of the unit.

  • Page 23: Ip Parameters

    IES-1000 User’s Guide Chapter 3 Factory Default Settings This section describes the factory default settings of the IES-1000. IP Parameters • IP address = 192.168.1.1 • Subnet mask = 255.255.255.0 • Default gateway = 192.168.1.254 Console Port • Baud rate = 9600 bps •...

  • Page 24: Ethernet Port

    Minimum upstream/downstream speed: 192 Kbps • Operational mode: auto Ethernet Port The factory default settings for the Ethernet port of the IES-1000 are: Auto-negotiation: ON Speed used with auto-negotiation OFF: 100Mbps Duplex mode used with auto-negotiation OFF: half duplex Other Factory Defaults •...

  • Page 25: Chapter 4 System Commands

    This section describes basic configuration and system-related commands. Command Line Interface (CI) The IES-1000 uses text command lines as the user interface for software configuration. Before discussing the details of configuration, the rules of the commands are listed next. The command keywords are in regular courier font.

  • Page 26: Help Facility

    This command saves all system configurations into nonvolatile memory. You must use this command to save any configurations that you make, otherwise the IES-1000 will return to its default settings when it is restarted. Do not turn of your IES-1000 while saving your configuration.

  • Page 27: Restart Command

    This command displays system related information. 4.5.2 Set Name Command Syntax: 192.168.1.1 sys> set name <name> This command allows you to set the name of your IES-1000. The previous setting will be cleared if the command is entered with the <name> parameter omitted. System Commands...

  • Page 28: Set Contact Command

    Set Contact Command Syntax: 192.168.1.1 sys> set contact [<name>] This command allows you to set the name of the contact person for your IES-1000. The previous setting will be cleared if the command is entered with the name omitted. 4.5.4...

  • Page 29: Secured Host Add Command

    IES-1000 User’s Guide 4.6.2 Secured Host Add Command Syntax: 192.168.1.1 sys> secured host add <host IP> where IP address of a secured host. <host IP> This command adds the IP address of a secured host. You may add up to ten IP addresses.

  • Page 30: Syslog Server Command

    (not be sent). System Error Log Commands The system error log will record error events locally to the IES-1000 memory. You may clear or display these logs using the commands listed in this section. The following lists what logs the system error log can record.

  • Page 31: Saving And Viewing A Previous Error Log

    If you clear a log (using the errlog clear command), you may not view it again. 4.8.3 Saving and Viewing a Previous Error Log You may save and view a previous error log after warm restarting the IES-1000 (refer to Figure 4-1). Log in memory before you restart your IES-1000.

  • Page 33: Chapter 5 G.shdsl Commands

    The G.SHDSL (G.991.2 Single-pair High-speed Digital Subscriber Line) subsystem allows you to configure and monitor G.SHDSL ports. G.SHDSL Standards The IES-1000 supports both G.991.2 and the G.hs standards. Table 5-1 Data Rates of the IES-1000’s SHDSL Ports STANDARD MAXIMUM UPSTREAM AND...

  • Page 34: Disable Port Command

    This command saves the G.SHDSL configuration into nonvolatile memory. You must use this command to save any configurations that you make, otherwise the IES-1000 will return to its default settings when it is restarted. Do not turn of your IES-1000 while saving your configuration.

  • Page 35: Lineperf Command

    IES-1000 User’s Guide An example is shown next. 192.168.1.1 gshdsl> lineinfo 2 2=Down Sp=0 Tx=0 Tr=0 Rx=0 Rr=0 NM=0 T=000:00:00 where the port number and whether the port is down/up (respectively). <2=Down> = the line rate. <Sp> the number of frames transmitted.

  • Page 36: List Port Command

    IES-1000 User’s Guide 5.2.8 List Port Command Syntax: 192.168.1.1 gshdsl> list port <port #> where port number, from 1 to 8 <port #> = This command displays information about your line speed, mode state and the line rate parameter of a G.SHDSL port.

  • Page 37: Speed Configuration

    IES-1000 User’s Guide = Configured maximum speed in Kbps. <Cmax> Configure <mode> or <Cmin>. <mode | Cmin> = Operational mode. Choose from “auto” or “fixed”. <mode> When <mode> is set to “auto”, the SAM1008 will attempt to transfer data at or below the configured <Cmax>.

  • Page 38: 5.2.13 Set Pvcs Command

    IES-1000 User’s Guide port number, from 1 to 8. <port #> either “llc” or “vc" <multiplexing mode> = the VPI setting of the G.SHDSL port for use with a TX based network. <tx vpi> the VCI setting for the G.SHDSL port for use with a TX based network.

  • Page 39: 5.2.16 Display All G.shdsl Line Information

    IES-1000 User’s Guide 5.2.16 Display All G.SHDSL Line Information Syntax: 192.168.1.1 gshdsl> monitor This command displays all G.SHDSL line information. Information is updated every five seconds. Press any key and then press [ENTER] to stop updating information. G.SHDSL Commands...

  • Page 41: Chapter 6 10/100M Fast Ethernet Port Commands

    When auto-negotiation is turned on, the Ethernet port of the IES-1000 negotiates with the peer Ethernet port on the Ethernet cable automatically to determine the optimal connection speed and duplex mode. If the peer Ethernet port does not support auto-negotiation or turns off this feature, the IES-1000 determines the connection speed by detecting the signal on the cable and using half duplex mode.

  • Page 42: Status Command

    IES-1000 User’s Guide where <speed> = 10 or 100 This command sets the connection speed used when auto-negotiation is turned off. 10 stands for 10Mbps and 100 stands for 100Mbps. 6.2.4 Status Command Syntax: 192.168.1.1 ethernet> status This command shows the current status of the Ethernet port.

  • Page 43: Chapter 7 Bridge Commands

    This command saves the bridge configuration into nonvolatile memory. You must use this command to save any configurations that you make, otherwise the IES-1000 will return to its default settings when it is restarted. Do not turn off your IES-1000 while saving your configuration.

  • Page 44: Macfilter Commands

    Use MACfilter commands to filter incoming packets based on MAC (Media Access Control) address(es) that you specify. If you do not use this command, your IES-1000 will not filter packets. MACfilter commands are listed next. You may specify up to five MAC addresses per port.

  • Page 45: Macfilter Delete Command

    Syntax: 192.168.1.1 bridge> mfilter This command displays the multicast filtering database. The mfilter command is what allows you to monitor the IES-1000’s IGMP snooping activities. The following is an example of a multicast filtering database. 192.168.1.1 bridge> mfilter Member Ports 239.255.255.250...

  • Page 46: Filterage Command

    3=SHDSL port 2 and so on. The version of IGMP being used in the network. IGMP version The number of query packets received by the IES-1000. Query Received The longest period of time used to respond to a query packet, measured in tenths of a Max Response Time second.

  • Page 47: Port-Based Vlan Commands

    IES-1000 User’s Guide Port-Based VLAN Commands The IES-1000 VLAN (Virtual Local Area Network) mechanism can be used to limit the broadcast domain to the members of a VLAN group only. In this way, VLAN increases network performance by limiting broadcasts to a smaller and more manageable logical broadcast domain.

  • Page 48: Portfilter Command

    IES-1000 User’s Guide 7.5.1 Portfilter Command Syntax: 192.168.1.1 bridge> portfilter [<source port> all|<dest ports>] where an incoming bridge port number. <source port> = all bridge ports are allowed outgoing ports. the outgoing bridge ports. Separate by a space if there is more than one port.

  • Page 49: Figure 7-2 Example Of Modified Vlan Port 2

    IES-1000 User’s Guide Port 8 (gshdsl7): Port 9 (gshdsl8): The following figures illustrate the above example. Notice that ports 2 (SHDSL port 1) and 3 (SHDSL port 2) are able to communicate with each other, as well as with the Ethernet. All of the other ports will only be able to communicate with the Ethernet port.

  • Page 50: Tagged Ethernet Frames Commands (Fast Mode)

    The IEEE 802.1Q standard uses an explicit tag in the header to specify the VLAN ID (VID) of an Ethernet frame. In this way, the VLAN membership of a frame can be carried across switches." The following table displays the physical port and corresponding default PVID tag on the IES-1000. Bridge Commands...

  • Page 51: Table 7-1 Physical Ports, Port Numbers And Ies-1000 Default Pvid Tags In Fast Mode

    IES-1000 User’s Guide Table 7-1 Physical Ports, Port Numbers and IES-1000 Default PVID Tags in Fast Mode PHYSICAL PORT DEFAULT PVID PORT NUMBER CPU (Central Processing Unit) SAM1008 LAN Port (Ethernet) SHDSL Port 1 SHDSL Port 2 SHDSL Port 3...

  • Page 53: Chapter 8 Ieee 802.1Q Tagged Vlan Commands

    IES-1000 User’s Guide Chapter 8 IEEE 802.1Q Tagged VLAN Commands This chapter generally describes the IEEE 802.1Q Tagged VLAN and associated CI Commands. Introduction The IEEE 802.1Q Tagged VLAN allows your SAM1008 to deliver tagged/untagged packets to and from its ports.

  • Page 54: Dynamic Entries (Dvlan Table)

    IES-1000 User’s Guide 8.4.2 Dynamic Entries (DVLAN Table) Dynamic entries are learned by the bridge and cannot be created or updated by management. The bridge learns this information by observing what port, source address and VLAN ID (or VID) is associated with a packet. Entries are added and deleted using GARP VLAN Registration Protocol (GVRP), where GARP is the Generic Attribute Registration Protocol.

  • Page 55: Svlan Cpu Command

    IES-1000 User’s Guide pvid port# ----- ----- 192.168.1.1 vlan1q> Figure 8-1 Example: PVID Command Display 8.5.4 SVLAN CPU Command Syntax: 192.168.1.1 vlan1q> svlan cpu [<vid>] where VLAN ID. Valid parameter range = [1 – 4094]. <vid> This command registers your CPU as a port member of the static VLAN with <vid>. To display the CPU static VLAN identification, simply enter this command without parameters, as shown next.

  • Page 56: Svlan Setentry Command

    IES-1000 User’s Guide 8.5.6 SVLAN Setentry Command Syntax: 192.168.1.1 vlan1q> svlan setentry <vid> <port#> <ad_control> <tag_control> where VLAN ID. Valid parameter range = [1 – 4094]. <vid> bridge port number. <port#> Valid parameter range = [1 – 9]. Registrar administration control flag.

  • Page 57: Svlan Getentry Command

    IES-1000 User’s Guide 8.5.7 SVLAN Getentry Command Syntax: 192.168.1.1 vlan1q> svlan getentry <vid> where VLAN ID. Valid parameter range = [1 – 4094]. <vid> This command displays an entry with a specified VLAN ID in the static VLAN table. Display a Static VLAN Table Entry Example The following figure is an example display of the following command.

  • Page 58: 8.5.10 Dvlan Getentry Command

    IES-1000 User’s Guide In the figure above, “||” denotes “filter” and “>>” denotes “forward”. 8.5.10 DVLAN Getentry Command Syntax: 192.168.1.1 vlan1q> dvlan getentry <vid> where VLAN ID. Valid parameter range = [1 – 4094]. <vid> This command displays an entry with a specified VLAN ID in dynamic GVRP table.

  • Page 59: Chapter 9 Ieee 802.1P Priority Commands

    IES-1000 User’s Guide Chapter 9 IEEE 802.1p Priority Commands This chapter explains IEEE 802.1p Priority CI Commands. Introduction IEEE 802.1p Priority CI Commands provide priority changes for ports. IEEE 802.1p defines up to eight priorities (0-7) by inserting a tag into a MAC-layer frame that contains bits to define priority of service.
  • Page 60 IES-1000 User’s Guide priority and 7 is the highest priority. This command sets the mapping of incoming user priority to a regenerated user priority for an ingress port. To display the regeneration table, simply use the Regen Port command without parameters, as shown next.

  • Page 61: Chapter 10 Ip Commands

    This chapter shows you how to configure the IP (Internet Protocol) parameters. The IP host implementation in the IES-1000 allows you to manage it over the network. More often than not, you have more than one IES-1000 for a particular installation. Before you start configuring the IES-1000s, make sure that you 1.

  • Page 62: General Ip Commands

    Line 2 clears the old parameters of the IES-1000. Line 3 allows you to add a new IP address for the IES-1000. The MAC address of the IES-1000 is displayed in the command prompt. The system will automatically compute the subnet mask when the system is restarted. If you want to specify a subnet manually, add the following two commands before line 4: 192.168.1.1 ip>...

  • Page 63: 10.3.1 Config Command

    IES-1000 User’s Guide 10.3.1 Config Command Syntax: 192.168.1.1> config [save] This command shows the IP configuration. The save option saves the configuration to the nonvolatile memory. 10.3.2 Version Command 192.168.1.1> version This command shows the firmware version and date on the SAM1008.

  • Page 65: Chapter 11 Remote Management

    Management by Telnet After you have set up the IP parameters and connected the IES-1000 to the network, you can manage it remotely with telnet. You can use any telnet client that you find convenient. The configuration procedures with telnet are exactly the same as those using the direct connection via the console port.

  • Page 66: 11.2.1 Supported Mibs

    IES-1000 User’s Guide An agent is a management software module that resides in a managed device (the IES-1000). An agent translates the local management information from the managed device into a form compatible with SNMP. The manager is the station through which network administrators perform network management functions. It executes operations that control and monitor the managed devices.

  • Page 67: 11.3.2 Snmp Access Delete Command

    IES-1000 User’s Guide This command allows read-only or read-write access. If the IP address is specified, access is allowed for the manager station with that address only. 11.3.2 SNMP Access Delete Command Syntax: access delete <community> [<IP addr>] This command revokes SNMP access by the specified community (password). If the IP address is specified, access is denied for that manager station only.

  • Page 68: 11.4.2 Trap Add Command

    IES-1000 User’s Guide ♦ overheatOver Trap (defined in ZYXEL-MIB) : This trap is sent periodically when the SAM1008 is no longer overheated. 11.4.2 Trap Add Command Syntax: trap add <community> <IP addr> [<port>] where The password used by the SAM1008 to authenticate itself to the trap server.

  • Page 69: Chapter 12 Configuration Backup/Restore

    IES-1000 User’s Guide Chapter 12 Configuration Backup/Restore This chapter describes the process for backing up your user settings (configuration) from the SAM1008 onto your computer and how to restore them to the SAM1008. The SAM1008 uses FTP for configuration backup/restore through its built-in FTP server. You can use any FTP client (for example, ftp.exe...
  • Page 70 IES-1000 User’s Guide Connect to the SAM1008 with your favorite FTP client. The command is generally Step 1. C:\> ftp <SAM1008 IP address> at the computer command prompt. Enter the User name (just press [ENTER]). Step 2. User: <ENTER> Enter the management password (1234 by default).

  • Page 71: Chapter 13 Firmware Upload And Recovery

    IES-1000 User’s Guide Chapter 13 Firmware Upload and Recovery ZyXEL periodically releases new firmware for the SAM1008 for bug fixes and enhancements. Please check the web site at www.zyxel.com every now and then for the latest firmware release. The SAM1008 uses FTP to upload firmware and no longer supports TFTP uploads. If the firmware in non-volatile memory is damaged, the SAM1008 uses BOOTP/TFTP to recover the firmware.

  • Page 72: Bootp/Tftp Firmware Recovery Of The Sam1008

    Quit FTP. For example, ftp> quit Wait for the update to finish. The SAM1008 restarts automatically. Do not turn off the IES-1000 during the updating process, as it may corrupt the firmware and make your unit unusable. 13.2 BOOTP/TFTP Firmware Recovery of the SAM1008 The SAM1008 uses BOOTP/TFTP for firmware recovery through its built-in BOOTP/TFTP client when the SAM1008 is restarted.

  • Page 73: Figure 13-1 Bootp/Tftp Server

    IES-1000 User’s Guide Figure 13-1 BOOTP/TFTP Server The Input Box window will pop up as shown next. Type the MAC address of the SAM1008 and then click OK. You can find the MAC address of the SAM1008 on its boot console.

  • Page 74: Figure 13-3 Database Edit Dialog

    IES-1000 User’s Guide Figure 13-3 Database Edit Dialog Select Normal Bootp to enable normal BOOTP/TFTP functions. Figure 13-4 Enable BOOTP/TFTP Restart the SAM1008 and press any key within three seconds to get the following screen. SDRAM Testing ... Mac address 00:A0:C5:12:34:56 Press any key within 3 seconds to enter debug mode ......
  • Page 75 IES-1000 User’s Guide Use the following command sequence on the SAM1008 to write new firmware to flash memory. 192.168.1.1> flashfs 192.168.1.1 flashfs> wipe 192.168.1.1 flashfs> update Wait for the update to complete and then restart the SAM1008. Firmware Upload and Recovery...

  • Page 77: Chapter 14 Troubleshooting

    IES-1000 User’s Guide Chapter 14 Troubleshooting This chapter covers potential problems and possible remedies. After each problem description, some steps are provided to help you to diagnose and to solve the problem. 14.1 SHDSL LED(s) An SHDSL LED is not on.

  • Page 78: Shdsl Led(S) Turn On And Off

    IES-1000 User’s Guide 14.3 SHDSL LED(s) Turn On and Off An SHDSL LED turns on and off intermittently. Table 14-3 Troubleshooting a Non-Constant SHDSL LED STEPS CORRECTIVE ACTION Connect the G.SHDSL modem or router directly to the SHDSL port of the SAM1008 using a different telephone wire.

  • Page 79: Password

    STEPS CORRECTIVE ACTION Refer to section 14.2 to make sure that the user is able to transmit to the IES-1000. Make sure the gateway’s IP address is the same as the one configured in the user’s computer. Check the VLAN configuration of the Ethernet port on the SAM1008 (refer to Chapter 7 ).

  • Page 80: Telnet

    IES-1000 User’s Guide 14.9 Telnet I can not telnet into the SAM1008. Table 14-9 Troubleshooting Telnet STEPS CORRECTIVE ACTION Make sure that a telnet session is not already operating. The SAM1008 will only accept one Telnet session at a time.

  • Page 81: Index

    Firmware Upload CE Mark Warning ............ iii File Types............13-1 Chassis ..............1-1 FTP ..............13-1 CI Commands............4-1 Impact to the IES-1000........13-1 Command Line Interface........4-1 Protocols............13-1 Command Structure ..........4-1 Timing .............. 13-1 Community............11-2 Flush Command ............. 7-4 Config Command ..........
  • Page 82 IES-1000 User’s Guide IEEE 802.1p Priority ..........9-1 Passwd Command ..........4-3 Commands ............9-1 Password .............. 11-2 IEEE 802.1Q Tagged VLAN ...1-1, 4-4, 7-8, 8-1 Physical Interfaces ..........1-3 Commands ............8-1 Physical Specifications........... 1-3 Default ..............3-2 Ping Command............. 10-3 Introduction ............8-1 Port-Based VLAN..........
  • Page 83 IES-1000 User’s Guide Status Command ..........6-2, 7-1 Enable/Disable Logs........... 4-5 Straight-through Category 5 UTP (Unshielded Logs Lost............4-5 Twisted Pair) Cable ..........2-2 Logs Sent............4-5 Supported Traps ........... 11-3 Upload Firmware SVLAN Table ............8-1 File Types............13-1 Syntax Conventions ..........xi Protocols............
