IES-5000/5005/6000
Integrated Ethernet Switch

Support Notes

July 2008
Edition 3

Advertisement

Table of Contents
loading

Related Manuals for ZyXEL Communications IES-5000

Summary of Contents for ZyXEL Communications IES-5000

  • Page 1: Support Notes

    IES-5000/5005/6000 Integrated Ethernet Switch Support Notes July 2008 Edition 3...

  • Page 2: Table Of Contents

    Ring Topology Application ... 76 IGMP Snooping/IGMP Filtering Application... 82 Limiting Internet access to users on specific DSL ports ... 84 DHCP Relay Option 82 Application... 85 Packet Filtering ... 96 All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes...

  • Page 3: Application Notes

    VDSL is deployed over existing wiring used for POTS (Plain Old Telephone System) and lower-speed DSL connections. The Triple Play solution is equipped with ZyXEL IES-5000 Chassis with VLC1348G-51 card, which is accompanied with P-870H-51 broadband VDSL technology CPE; the total rate can be up to 52Mbps.
  • Page 4 IES-5000/5005/6000 Support Notes Triple Play scenario topology All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 5 2. Connect the VoIP (or SIP server) to the Port5 of the ES-2024A. 3. Connect IPTV (or Multicast Server) to the Port7 of the ES-2024A. 4. Connect Port12 of ES-2024A to the UP1 of the MSC1000G on IES-5000 Chassis. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 6 IES-5000/5005/6000 Support Notes Firmware versions: ES-2024A V3.80(TX.0)C0 IES-5000 MSC1000G: V3.90(LU.1)C0 VLC1348G-51: V3.90(BHB.0)b1 P-870H-51 1.00(AWG.6)G0 All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 7 Press the RESET button on the back-end plane of the housing (you can see it in the following picture). Keep it pressed down for several seconds, until you see that the POWER LED is blinking, which means the factory default setting is being applied to the device. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 8 Configure the IES-5000 1. System login. a. Connect to the IES-5000 via Internet browser. 192.168.1.1 is the default in-band management IP address and 192.168.0.1 is the default out-of-band (management port) IP address. Enter the default username (“admin”) and the password (“1234”) to access the device: b.
  • Page 9 Choose slot 3 and port 1, and click Load to open the page shown below: c. Select the Enable check-box to enable the VDSL port1, click Apply to save the settings. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 10 Click the Setup button in sub-step (1) of the VLAN to open the page relevant for sub-step (2) & (3): Sub-step (1): Open VLAN setup page. Sub-step (2): Join VLAN 100 to VDSL port 1. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 11 IES-5000/5005/6000 Support Notes Sub-step (3): Join VLAN 500 to VDSL port 1. Sub-step (4): Check the final VLAN setup status, you should see two entries as below. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 12 IES-5000/5005/6000 Support Notes Sub-step (5): Set the default PVID/Priority for the VDSL Port1, click Apply to save the changes. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 13 Select VLAN 100 and click Modify, then set the port UP1 as Fix and Tag, then click Apply to save the changes: c. Select VLAN 500 and click Modify, then set the port UP1 as Fix and Tag, then click Apply to save the changes: All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes...
  • Page 14 IES-5000/5005/6000 Support Notes d. Check the final VLAN setup status of the MSC1000G All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 15 MS-DOS, then use Telnet method to login (use the default management IP: 192.168.0.1). After issuing the default ‘admin’ / ’1234’ to login, you can see the page shown below: All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes...
  • Page 16 (1). <rule> is for picking out the traffic by specific parameters, e.g. the vid (802.1q), mac, etype (Ethernet Type), priority (802.1p) etc. (2). <action> can apply actions to the traffics picked out by the <rule>, e.g. rate (limit the rate), rvlan (replace vlan), rpri (replace priority) All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 17 Based on the above settings, all the PPPoE traffics including the Ethernet Type: 0x8863 and 0x8864, upcoming from VDSL port 3-1 will be picked out by ACL rules ‘pppoe1’ and ‘pppoe2’, and then replaced with new VLAN ID/Priority ‘100/0’. All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes...
  • Page 18 Set multicast group range for MVR VLAN 700 //Since we are using 239.255.255.2 as the multicast group IP in this case, we set the group range starting from 224.1.1.1 to 239.255.255.255// d. Enable MVR VLAN 700 All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes...
  • Page 19 // And because all the traffics sending out from the VDSL port 3-1 are untag, we can specify any VLAN joined this port, here we choose the VLAN 500. // All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes...
  • Page 20 IES-5000/5005/6000 Support Notes d. Check the Query VLAN status. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 21 IES-5000/5005/6000 Support Notes 7. Save configuration for the IPDSLAM. (1). Open Config Save, then click the Save button to save all your settings to NVRAM. (2). If setting is successful, result is as below. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 22 Connect to the ES-2024A via Internet browser. 192.168.1.1 is the default in-band management IP address. Enter the default username (“admin”) and the password (“1234”) to access the device: b. The main screen appears after clicking OK. All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes...
  • Page 23 Create VLAN 100 / 500 / 700 for PPPoE / VoIP / IPTV respectively. [Note:] Don’t forget to click the Add button at the bottom of the page. (1). VLAN 100 for PPPoE. All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes...
  • Page 24 IES-5000/5005/6000 Support Notes (2). VLAN 500 for VoIP. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 25 IES-5000/5005/6000 Support Notes (3). VLAN 700 for IPTV. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 26 IES-5000/5005/6000 Support Notes (4). Check final status of the VLAN settings. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 27 (1). Click Advance Application > VLAN, then choose the VLAN Port Setting (2).Set port 1 / 5 / 7’s PVID as 100 / 500 / 700 as below: Don’t forget to click Apply to save the settings. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 28 Set the default 802.1p Priority value for the respective ports in this scenario. (1). Click Basic Setting > Port Setup to call the page below. (2). Click Apply at bottom to save the settings. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 29 (1). Click Management > Maintenance, then choose the Config 1 in Save Configuration. (2). Or you can choose the Save button on the top of the page. If saving was successful, you would see result shown below. All contents copyright (c) 2008 ZyXEL Communications Corporation.

  • Page 30: Triple Play Application (With Alc/Slc Line Card)

    This helps eliminate congestion and to allow smooth transmission of real time data (such as audio and video). In this application, we will show you how to set up multiple PVCs using the IES-5000. The following figure shows a network example where the computers want to get different services (data service for Internet access and video service) from two networks.
  • Page 31 IES-5000/5005/6000 Support Notes In this network application, we will use an IES-5000, a ZyXEL ES-2024 VLAN-aware switch and Prestige 660R-61 CPE (you may also use P791 if you have the SLC-1248G line card installed on the IES). 1. IES-5000 Settings 1.1 VLAN setup...
  • Page 32 Edit ATM Options field and press [ENTER] to enter menu 11.6. 2.2 Menu11.6: Remote Node ATM Layer Options Make sure the VPI and VCI settings are the same as on the IES-5000 (the default is 0 and 34 respectively).
  • Page 33 Click Static VLAN to display the Static VLAN screen. Create a VLAN with VID of 10. Assign ports 1 and 10 to be members of VLAN10. Select the Tx Tagging option to enable egress tagging on port 10. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 34 IES-5000/5005/6000 Support Notes Create a VLAN with VID of 20. Assign ports 2 and 10 to be members of VLAN20. Select the Tx Tagging option to enable egress tagging on port 10. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 35 Click Advanced Application and VLAN in navigation panel to display the configuration screen as shown. Click VLAN Port Setting to show VLAN Port Setting screen. Set the PVIDs on port 1 and 2 to 10 and 20 respectively. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 36 0/33 channel and the data traffic will go through the 0/34 channel. Since the 0/33 channel has a higher priority, video traffic will get processed and sent first if both traffic types arrive at the same time. All contents copyright (c) 2008 ZyXEL Communications Corporation.

  • Page 37: Vdsl2 To Adsl2+ Fallback

    This allows a longer connection distance. You can also specify ADSL2+ as the only protocol that can be used on the port connected to an ADSL2+ CPE. IES‐5000 Slot 3: VLC1348G‐51 All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes [PORT 1] P‐660H‐61 ADSL2+ CPE...
  • Page 38 In Windows, click Start (usually in the bottom left corner), Run and then type “telnet 192.168.1.1” (the default IP address) and click OK. b. Enter “1234” in the Password field. c. After entering the password you will see the main menu. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 39 Enter 1 in the Main Menu to open Menu 1 – General Setup. b. Type a name in the System Name field. c. Select No in the Route IP field. d. Select Yes in the Bridge field. e. Press ENTER to confirm your changes. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 40 IES-5000/5005/6000 Support Notes 3. Remote Node Setup a. Enter 11 in the Main Menu to open Menu 11 – Remote Node Setup. b. Enter 1 to configure the remote node of MyISP (ISP, SUA). All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 41 Select None in the Route field. h. Select Yes in the Bridge field. Select Yes in the Edit ATM Options field and press ENTER to display Menu 11.6 – Remote Node ATM Layer Options. All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes...
  • Page 42 Specify VPI and VCI. In this case, we type 8 in the VPI # field and 35 in the VCI # field. Press ENTER to confirm your changes. All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes...
  • Page 43 Configure the VLC1348G-51 1. Login a. Connect to the IES-5000 via Internet browser. 192.168.1.1 is the default in-band management IP address and 192.168.0.1 is the default out-of-band (management port) IP address. Enter the default username (“admin”) and the password (“1234”) to access the device: First web configurator screen appears.
  • Page 44 IES-5000/5005/6000 Support Notes All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 45 Select slot 3 and port 1, and click Load to display the settings as shown in this screen. c. Select Enable. d. Select auto from the second VDSL Profile drop-down list box to automatically detect the protocol used on the connected line. e. Click Apply. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 46 Select slot 3 and port 1, and click Load to display the settings as shown in this screen. c. Select index 1, and click Delete to delete the default PVC (0/33). d. Type 8/35 in the VPI/VCI field. e. Click Apply to create the PVC. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 47 IES-5000/5005/6000 Support Notes 4. Config save a. Click Config Save on the navigation panel. b. Click the Save button to save your configuration to nonvolatile memory. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 48 Click Diagnostic > Loopback. d. Select port 1. e. Type 8 in VPI and 35 in VCI. Click the Test button to perform an OAM F5 loopback test on port 1. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 49 IES-5000/5005/6000 Support Notes All contents copyright (c) 2008 ZyXEL Communications Corporation.

  • Page 50: Impulse Noise Protection (Inp)

    AWGN shall be generated with crest-factor of 5 and flat PSD up to 12 MHz, and further continuously declined with a roll-off equal to or steeper than 12 dB per octave. The PSD of the AWGN shall be variable in the range from –70 dBm/Hz to –140 dBm/Hz. All contents copyright (c) 2008 ZyXEL Communications Corporation.

  • Page 51: Upstream Power Back-Off (Upbo)

    Enable UPBO to allow the system to adjust the transmit PSD of all lines based on a reference line length so that the PSD at the receiving end is the same. All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes...
  • Page 52 NEG: Requires exact knowledge of the noise environment. The UPBO needs to be updated for any change in FEXT and non-FEXT (the worst case solutions for both usually brings rather poor results). All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes...
  • Page 53 Compatibility of different methods should be taken in account. The following PBO methods are widely discussed: • Reference PSD • Reference Length • Multiple Reference Length • Equalized FEXT • Reference Frequency • Reference Noise All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes...

  • Page 54: Ag Cfm

    Provide detects failure: diagnose and isolate the failure, report to operators • Operator detects failure: diagnose and find out root causes • MS: Management System All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes Operator B Operator C Provider...
  • Page 55 An MEP port has the ability to send and reply the CCMs, LBMs and LTMs. It also gets other MEP port information from neighbor switches’ CCMs in an MA. CCM—Continuity Check Message All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes Customer...
  • Page 56 Maintenance endpoints reside at the edge of a maintenance domain, whereas maintenance intermediate points are internal to the domain. Each maintenance endpoint is assigned an unique id within its domain. All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes Operator B...
  • Page 57 CFM Enable: Select or deselect the check box and click Apply to turn the CFM feature on or off. MD Name: Type a name (up to 31 printable ACSII characters) for this MD. This is for the purpose of identification. Level: Type a level number (0~7) for this MD. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 58 Add MEP ID: Enter a remote MEP ID (1~8191) associated to this MA and allowed to be used in the CFM test. Add VLAN ID: Enter a VLAN ID (1~4094) associated to this MA All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 59 Reset Time: This is the number of seconds the ZyXEL Device waits to cancel a local alarm after a CFM_ERROR event has been resolved and no other alarms occurred. Mac Address: Enter the CFM en point’s MAC address. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 60 Target: Specify the destination of the link you are checking. You can select MEPID and enter a remote MEP’s ID or select MAC and enter a remote MEP port’s MAC address. Test: Click this to start the loopback connectivity test. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 61 • Create a MIP MSC1000G> switch cfmmip set <md-name><ma-name><giga-port>|<slot-port> • Delete a MIP MSC1000G> switch cfmmip delete <md-name><ma-name><giga-port>|<slot-port> • Execute Loopback MSC1000G> diagnostic cfm loopback <md-name><ma-name><ep-id><remote-ep-id>|<mac> • Execute Linktrace All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes...
  • Page 62 IES-5000/5005/6000 Support Notes MSC1000G> diagnostic cfmlinktrace set <md-name><ma-name><ep-id><remote-ep-id>|<mac><ttl> All contents copyright (c) 2008 ZyXEL Communications Corporation.

  • Page 63: Setting Up Different Dsl Port Speeds To Different Subscribers

    2M/512K Configuring and applying the profiles to subscriber ports For this example, we will use configure the profile on an IES-5000 that connects to ADSL CPEs (ZyXEL Prestige 660R-61). 1. IES-5000 1.1 Profile Setup Configure a profile to set low line speed. Enter a descriptive name for this profile (for example, “Profile_LowSpeed”) and set the maximum upstream and downstream rates...
  • Page 64 Next configure the CPE device. Set the Prestige 660R-61 to work in bridge mode using the VPI/VCI settings of 0/33 (the default on IES-5000). Since the Prestige 660R-61 has a built-in telnet server, you can telnet and log into the management interface.
  • Page 65 For bridge mode, select RFC 1483 in the Encapsulation field with LLC-based multiplexing. Also set the Prestige to use the same VPI and VCI settings as the IES-5000 (the default is 0 and 33 respectively). 2.3 Menu11.1: Remote Node Profile In menu 11.1, select Yes in the Active field to activate this remote node profile.
  • Page 66 IES-5000/5005/6000 Support Notes 2.4 Menu11.6: Remote Node ATM Layer Options Make sure the VPI and VCI settings are the same as on the IES-5000 (the default is 0 and 33 respectively). All contents copyright (c) 2008 ZyXEL Communications Corporation.

  • Page 67: Configuring 802.1Q Vlan

    VLAN10 Setting up a VLAN For this application, we will use an IES-5000 and Prestige ADSL 660R-61 CPE (any DSL CPE or P791 if you have the SLC-1248G line card installed on the IES). Since the two ports belonging to different VLANs need Internet access via the Uplink port All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 68 IES-5000/5005/6000 Support Notes on the IES-5000, another VLAN (to which the two ports are a member of) need to be configured. 1. IES-5000 Settings 1.1 VLAN settings Create a VLAN group with VID 10 and set Port 1, ENET1 and ENET2 to be members of this VLAN.

  • Page 69: Application

    TGE1> port pvc set 7-1-0/33 DEFVAL llc 10 0 TGE1> port pvc set 7-2-0/33 DEFVAL llc 20 0 1.3 Port Isolation On the IES-5000, you can isolate ports without configuring VLAN groups in the CLI. CI command: TGE1> switch isolation enable 2.
  • Page 70 Enable 802.1x Authentication and specify the RADIUS server IP address, UDP port and shared Secret on the IES-5000. Make sure you enter the same UDP port and and shared Secret on the IES-5000. Make sure you enter the same UDP port and shared secret as the RADIUS server.
  • Page 71 You can use existing user accounts or create a new one by clicking the Add New User button. Clients must enter the correct user name and password to log into the network. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 72 EAP type field. When the 802.1x authentication process starts, a message displays in the system tray prompting you to enter the account user name and password. The following figure shows an example. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 73 Click on the message balloon to display the login screen where you can enter your account user name and password. After entering the required information, click OK to continue. Once the authentication process is successful, client setup is complete. All contents copyright (c) 2008 ZyXEL Communications Corporation.

  • Page 74: Syslog Server Application

    (such as Syslodd in Unix and Kiwi Syslog Daemon ( http://www.kiwisyslog.com/ When the DSL or Ethernet connections are up or down, the IES-5000 sends a log record to the syslog server. You must install the syslog server on the network that the IES-5000 can access.
  • Page 75 Network Uplink Setting up a Syslog server In this section, we will show you how to configure the IES-5000 and Kiwi Syslog server. The subsequent sections describe the detailed configuration steps. . Installing and Running Kiwi’s Syslog Server Download the Kiwi syslog daemon installation file f the file to start the installation process.
  • Page 76 TGE1> sys syslog facility 1 TGE1> config save hen the DSL connection is up or down, the IES-5000 sends a log record to the syslog server. You can see the new entry in the syslog server. The following shows an example.

  • Page 77: Ring Topology Application

    Setting up a Ring Environment This section shows you how to set up a ring network using an IES-5000, IES-2000 and an ES-4024 switch. The computers should be able to connect to each other even though an uplink connection is down. The following sections describes the configuration steps in detail.
  • Page 78 , click Port Setup in the navigation panel to display the configuration screen a s shown. Click msc to display the configuration screen for the Ethernet ports on the MSC line card. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 79 IES-5000/5005/6000 Support Notes Click Uplink2 to configure this port. Select Rapid Spanning Tree Protocol to enable it on the port. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 80 IES-5000/5005/6000 Support Notes Follow the same procedure to activate STP on uplink port 1. The following figure shows an example. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 81 Tree Protocol in the navigation panel. The main Spanning Tree Protocol Status screen Click Configuration to configure spanning tree protocol settings. displays. Select Active to enable Spanning Tree Protocol on the system and then enable STP on All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 82 2 becomes BLOCKING. To test the RSTP/STP mechanism, disconnect the Ethernet cable between uplink port 1 on the IES-5000 and port 1 on the ES-4024. The computers can still access the network through the CPE devices since traffic now goes through IES-2000.

  • Page 83: Igmp Snooping/Igmp Filtering Application

    IGMP groups. This feature is useful for video service providers as they only need to allow certain, but not all, channels (or multicast groups) on specific ports. Video Server IES-5000(ALC/SLC) Port 1 Video Client All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes Internet IGMP Ethernet Port Router ADSL/SHDSL...
  • Page 84 On the IES-5000, create an IGMP filter profile (Subscriber1) and apply the profile to port 1. Then apply the profile to the subscriber port (7-1). Save the settings to make it take effect.

  • Page 85: Limiting Internet Access To Users On Specific Dsl Ports

    PC 2 PC 3 Setting up MAC Filter/Port Security In this section, we will show you how to configure the IES-5000 to allow only computers with the specified MAC addresses to access the Internet through port 3. 1. IES-5000 settings 1.1 Configuring MAC filter...

  • Page 86: Dhcp Relay Option 82 Application

    To set up this flexible client IP address assignment scheme, configure the They DHCP Relay Option 82 feature and set up a DHCP server that supports the Option 82 function. The following figure shows a network example. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 87 TGE1> ip dhcprelay relayinfo add 5000 All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes Network IES-5000(ALC/SLC) ADSL/SHDSL CPE ow you how to configure the IES-5000 to puter is connected to DSL port 25 with an 68.1.99 ort,...
  • Page 88 Display the IP Commander s creen and right-click on IP Commander and then click Connect New Server”. Enter the IP address (for example, 192.168.1.99) or domain name of the DHCP server and click OK. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 89 IES-5000/5005/6000 Support Notes Enter the login user name and password. The default user name is “administrator” and the password is “incognito”. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 90 A screen displays as shown. Make sure that the status of your DHCP is online. Then click Wizards > Rule Wizard in the tool bar. Enter a name and description for the new rule. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 91 IES-5000/5005/6000 Support Notes Assign one or a range of IP addresses for this rule. For this example, set the client IP pool in the 192.168.1.201 ~ 192.168.1.203 range. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 92 For port 25, VLAN 1, option string “5000”, enter “0019000131323438” as the key value and click OK. Note that the first two bytes define the port number, the second two bytes define the VLAN ID and the subsequent bytes indicate the Option82 string. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 93 IES-5000/5005/6000 Support Notes After you have finished the rule wizard settings, the following screen displays. Click Next to continue. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 94 In the next wizard screen, click Next to continue. In next screen, you may specify a DHCP template (with the gateway and DNS settings) to use. Here we will create a new template. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 95 IES-5000/5005/6000 Support Notes For this template, we enter “192.168.1.1” as the gateway IP address for the DHCP client. All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 96 IES-5000/5005/6000 Support Notes In the next screen, you may choose whether to apply automatic DDNS service on the DHCP server or not. Click Finish to complete the wizard setup. All contents copyright (c) 2008 ZyXEL Communications Corporation.

  • Page 97: Packet Filtering

    DHCP server once the computer is connected to the network. Packet Filtering The packet filtering feature on the IES-5000 allows ISPs to block certain packet types (such as IP, ARP, DHCP, EAPoL, PPPoE, NETBIOS and IGMP). All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 98 ----- ---------- --------------------------- 7- 1 netbios 7- 2 accept-a 7- 3 accept-all All contents copyright (c) 2008 ZyXEL Communications Corporation. IES-5000/5005/6000 Support Notes Network IES-5000(ALC/SLC) ADSL/SHDSL Specific Protocol Packet. Ex. NetBIOS u how to configure the IES-5000 to block NETBIOS...
  • Page 99 7-26 accept-all 7-27 accept-all 7-28 accept-all 7-29 accept-all 7-30 accept-all 7-31 accept-all 7-32 accept-all 7-33 accept-all 7-34 accept-all 7-35 accept-all 7-36 accept-all 7-37 accept-all 7-38 accept-all 7-39 accept-all 7-40 accept-all 7-41 accept-all All contents copyright (c) 2008 ZyXEL Communications Corporation.
  • Page 100 IES-5000/5005/6000 Support Notes 7-42 accept-all 7-43 accept-all 7-44 accept-all 7-45 accept-all 7-46 accept-all 7-47 accept-all 7-48 accept-all TGE1> All contents copyright (c) 2008 ZyXEL Communications Corporation.
