CYBEX 770R Cycle Owner's Manual page 54

LED Console
Target Bar
Bar Graph
Data Readouts
Enunciator
E3 View Monitor
When screen option of TV and Data or Data Only is selected, display the workout values such as
Distance, Calories, BPM (Heart rate, if available), MET and RPM (crank RPM in rotations per minute).
Heart rate will be displayed in lieu of MET if a valid heart rate is available from a wireless chest strap
(not included) or by holding the contact heart rate grips.
7. Press the Gear/Power/RPM + – keys to change the Gear/Power/RPM at any time. The display
will show the current gear or watt level. Gear range is 1-21, watt level range is 20-500.
When you adjust Gear/Power/RPM in a workout, the change will affect only the current segment. The
workout control will resume starting with the next segment. To increase or decrease overall intensity,
adjust the Gear, Power, or RPM.
8. Press the STOP key at any time to end workout.
If pause feature is enabled, pause icon
•
If pause feature is disabled, stop icon
•
end workout and enter "Workout review".
Workout Review is shown for approximately 20 seconds, showing each set of information twice
before exiting to Dormant or powering off.
Cybex Owner's Manual
Target row: Displays target RPM for workouts that require a target speed.
RPM row: Display actual crank RPM.
Displays a graphical representation of the relative power (watt) changes,
and if in a workout, will show the relative intensity changes that are
coming up.
Displays the workout values such as Distance, Calories, BPM (Heart
rate, if available), MET and RPM (crank RPM in rotations per minute).
The Enunciator displays the titles of the Data Readouts.
is shown. Tap pause icon once to enter pause mode.
is shown. Tap stop icon or press STOP button once to
54
