4 Operating the Data II

4.1 Selecting the location

•
The location in which the DATA II is to be operated must be dry.
•
Free from dusty or polluted air.
•
Free from vibrations.
•
Located on an non-flammable place or surface.
•
Well-ventilated with fog-free air keeping the ambient operating temperature between 5° C and
45° C and the relative air humidity below 80%.
4.2

Changing the fluid container

•
Disconnect the fluid tube from the lid by retracting the brass collar and removing the coupling .
•
Remove the container from the tank housing of the DATA II
•
Unscrew the lid of the empty container and screw it onto the new container.
•
Place the full container into the tank housing.
•
Push the brass coupling into the brass collar until you hear a click.The brass collar is now
locked firmly.

4.3 Fog fluids

The DATA II has been designed to be used with SMOKE FACTORY fog fluids.
•
FAST-FOG
•
SUPER-FOG
•
HEAVY-FOG
•
DESIGNER-FOG
Use only original SMOKE FACTORY fog fluids. Other Fluids can cause considerable
damage to the unit and void the warranty. You can get more general information about
fog fluids from your dealer or SMOKE FACTORY directly.
SMOKE FACTORY fog fluids is an enviromentally safe product and it can be recycled
biologically.

4.4 Putting into operation

After a warm up time of approx. seven minutes the DATA II is ready to start. The green Ready-Led
blinks if the working temperature is reached. As soon as the final temperature is reached, the LED
llumates permanently. Adjust the required output via the control panel and press the Enter-button
( see 5.1) once to start and once to end the fogging process.
SMOKE FACTORY
FOG GENERATORS NEBELMASCHINEN
SMOKE-FACTORY –
DATA II Operating Instructions
Thick fog, very quickly dispersing.
Medium thick standard fog, long lasting.
Thick fog, very long lasting.
Transparent fog, very long lasting, high light reflexion grade.
Connect to the mains supply. Make sure the correct voltage is
selected (230 V/50 Hz).
A „P" and two figures appear on the display like P 15.
issue 1.0 Page: 6 of. 15
