- Page 1 SMOKE FACTORY FOG & HAZE GENERATORS ENTERPRISE TC4 SERVICE MANUAL ATTENTION Testing under 110-230V can be a danger for life. The testing person should be a technical skilled person to avoid injuries!
- Page 2 FOG & HAZE GENERATORS Introduction General This document should be used if ENTERPRISE TC4 is not working properly. With this document it should be possible to find the fault/ not working device and change this device without the direct help of the manufacturer.
-
Page 3: Circuit Boards
SMOKE FACTORY FOG & HAZE GENERATORS Circuit Boards There are two boards: the PCB ENTERPRISE TC4 and the PCB Remote (DMX and analogue). 2.3.1 PCB ENTERPRISE TC4 (part number 39003) Power Connector for terminal for thermocouple the fan Terminal block Picture 2.3.1a: PCB ENTERPRISE TC4 –... - Page 4 SMOKE FACTORY FOG & HAZE GENERATORS Fuse holder IP67 (part number 40056) Fuse holder Connector for external fan Picture 2.4: Fuse holder (40056) Diagrams Part list ENTERPRISE TC4 ENTERPRISE TC4 – SERVICE MANUAL...
- Page 5 SMOKE FACTORY FOG & HAZE GENERATORS ENTERPRISE TC4 ENTERPRISE TC4 – SERVICE MANUAL...
- Page 6 SMOKE FACTORY FOG & HAZE GENERATORS ENTERPRISE TC4 – SERVICE MANUAL...
- Page 7 SMOKE FACTORY FOG & HAZE GENERATORS ENTERPRISE TC4 – SERVICE MANUAL...
- Page 8 The fog fluid is coming from the fluid bottle [1]. It is flowing to the two pumps [2]. Coming out of the pumps the fluid is flowing via the pressure pipes to the HE. There it will be heated up and leaves the exit as fog [4]. ENTERPRISE TC4 – SERVICE MANUAL...
- Page 9 SMOKE FACTORY FOG & HAZE GENERATORS ENTERPRISE TC4 – SERVICE MANUAL...
- Page 10 At P99 you can measure about 170VAC. Solution: If there is no power check the PCB ENTERPRISE TC4 for function. If there is power and the pump does work test the HE 2400 Heat Exchanger.
- Page 11 2.2b) between the red and the yellow/white cable, when the machine is heating up. Solution: If there is no power, check the PCB ENTERPRISE TC4 for function. If there is power, the pump does work properly and there is still no fog the HE 2400 Heat Exchanger must be broken. Change the device.
- Page 12 Do this two or three times to make sure all the residues are gone. Replacement/Mounting/Demounting Disconnect the ENTERPRISE TC4 unit from main supply (pull the plug out the socket). Screw off the two screws of the handle on the top. Go on screwing off the six screws at the bottom of the unit.
- Page 13 5x8mm. Reconnect all cables (take care of the polarity of the thermocouple wires)and tubes as described in 3.2 wire plan and 3.3 fluid circuit. Picture 5.2a: Rivets for heat exchanger ENTERPRISE TC4 – SERVICE MANUAL...
- Page 14 Picture 5d: Thermocouple terminal block Disconnect the power cables for the fan. It is just necessary to pull out the red crimps, see picture 5e. Power connection of the external fan Picture 5e: Power connection of the fan ENTERPRISE TC4 – SERVICE MANUAL...
- Page 15 Disconnect the flat cable from the board (see picture 5f). Drill the rivets. Take the board out and put a new one in. Tied it via screws to the lid again. Reconnect the flat cable. ENTERPRISE TC4 – SERVICE MANUAL...
-
Page 16: Function Test
FOG & HAZE GENERATORS Testing after exchange Before closing the ENTERPRISE TC4 unit do the function test. After closing the lid do the final test. 5.4.1 Function test 1. Test the ENTERPRISE TC4 unit via display (up/down of Pxx) by pressing the button 2.
