Specifications - Smoke Factory Data ll Operating Instructions Manual

8 Specifications

Procedure:
Power requirement:
Voltage:
Warm up time:
Fluid consumption:
Fluid tank capacity:
Fog output:
Fogging time:
eternal Fan:
Air quantity:
Control:
Temperature control:
Overheating protection:
Fuse external fan:
Dimension (L x B x H ):
Weight without Fluid:
Options:
SMOKE FACTORY
FOG GENERATORS NEBELMASCHINEN
SMOKE-FACTORY –
DATA II Operating Instructions
vaporizing fog generator
2600 Watt
230 V/ 50 Hz
approx. 7 min.
at max. output 240 ml/min
at cont. output 120 ml/min
5 Liter
adjustable in steps à 1% ( 0-99)
at 100% output approx. 40 sec.
at < 50% output continuous output
max. 800 Watt, fan with one phase
adjustable fron 0-99%
DMX 512
0 - 10 V analog
internal Timer
Stand alone mode
Radio remote (Option)
Microprocessor controlled
Heater block/Thermostat
Pump/Thermal switch
5 Ampere slow blow
55 x 32 x 47 cm
20 kg
Cable remote
Radio remote
Tube
issue 1.0 Page: 14 of. 15
