FREESTANDING DIRECT VENTED GAS ROOM HEATER
OPERATION & INSTALLATION
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
WARNING: If the information in these
instructions are not followed exactly, a fi re
or explosion may result causing property
damage, personal injury or loss of life.
—
Do not store or use gasoline or other
fl ammable vapors and liquids in the vicinity
of this or any other appliance.
—
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
•
If you cannot reach your gas supplier, call
the fi re department.
—
Installation and service must be performed
by a qualifi ed installer, service agency or
the gas supplier.
Pour la version française de nos manuels S.V.P. vous référez à notre site web: www.blazeking.com
OM-1606 E V1.03
TORINO II 1606
for use with natural gas or LPG
MANUAL
This appliance may be installed in
an aftermarket, permanently located,
manufactured (mobile) home, where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certifi ed kit is used.
April 2, 2014
Advertisement
Table of Contents
Related Manuals for Blaze King TORINO II 1606
Summary of Contents for Blaze King TORINO II 1606
- Page 1 TORINO II 1606 FREESTANDING DIRECT VENTED GAS ROOM HEATER for use with natural gas or LPG OPERATION & INSTALLATION MANUAL Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference.
-
Page 2: Table Of Contents
________________________________________________________ 43 REPLACEMENT PARTS _________________________________________________________________ 45 WARRANTY ______________________________________________________________________ 49 NOTES Manufactured By Valley Comfort Systems Inc. Blaze King Industries 1290 Commercial Way 146 A Street Penticton, BC V2A 3H5 Walla Walla, WA 99362 CANADA U.S.A. Phone: 250-493-7444 Phone: (509) 522-2730... -
Page 3: Introduction
Disregarding inspection and code requirements may jeopardize your homeowner's insurance. Since some insurance carriers require notifi cation of a stove installation, contact your insurance agent. We want your Blaze King to give you a lifetime of trouble-free operation. -
Page 4: Certification Label
6” (152 mm) Corner to Side Wall 4 3/8” (111 m) Minimum Alcove Height 48” (1219 mm) MANUFACTURE DATE Blaze King Industries Manufactured in U.S.A. by: 146 A Street, Walla Walla, WA JAN FEB MAR APR ... -
Page 5: General Information
CAN/CGA-2.17-M91 Gas-Fired Appliance for Use at High Altitudes • CSA P.4.1-02 Testing Method for Measuring Annual Fireplace Effi ciency Please contact Valley Comfort or Blaze King, if you have any questions regarding the certifi cation of this appliance. • Th e installation must conform with the local codes or, in the absence of local codes, with the current National Fuel Gas Code, ANSI Z223.1/ NFPA 54, in the US or Installation Code, CSA-B149.1, in Canada. - Page 6 TORINO II Freestanding 1606 Page 6 GENERAL INFORMATION cont. CAUTION • Due to high temperatures, the appliance should be located out of traffi c and away from furniture and draperies. • Children and adults should be alerted to the hazards of high surface temperature and stay away to avoid burns or clothing ignition.
-
Page 7: Appliance Dimensions
TORINO II Freestanding 1606 Page 7 APPLIANCE DIMENSIONS OM-1606 E V1.03 April 2, 2014... -
Page 8: Installation Clearances
TORINO II Freestanding 1606 Page 8 INSTALLATION CLEARANCES CLEARANCES TO COMBUSTIBLES Fig.2 MODEL - Torino II Alcove Width min. 46-3/8” (1178 mm) Alcove Height min. 48” (1219 mm) Top of Unit to Alcove Ceiling min. 12-1/2” (318 mm) Side of Unit to Sidewall min. -
Page 9: Assembly Instructions
5. Lift out and remove door glass with the gasket attached. 6. If the glass door is damaged, it must be replaced with another glass door certifi ed with this appliance only 7. Replacement glass doors are available through your Blaze King dealer see “REPLACEMENT PARTS” on page 43 Replacing the Glass Door: 1. - Page 10 TORINO II Freestanding 1606 Page 10 ASSEMBLY INSTRUCTIONS cont. PLACEMENT OF LOGS Step 3: Install pins in holes “arrows” Step 1: Place rear log on log on pins and place fi nal log on pins as shown. near the rear center of the burner. Step 2: Install pins in holes “arrows”...
-
Page 11: Installation Instructions
TORINO II Freestanding 1606 Page 11 INSTALLATION INSTRUCTIONS PRECAUTIONS • Th is appliance must be installed by a qualifi ed gas installer and the installation conform to the installation codes. • Th is appliance needs fresh air for safe operation and must be installed so there are provisions for adequate ventilation air. - Page 12 TORINO II Freestanding 1606 Page 12 INSTALLATION INSTRUCTIONS cont. GAS CONNECTIONS Have your gas supplier or a qualifi ed gas fi tter run a gas supply line into the gas fi replace. Th e line must be properly sized and fi tted according to the installation codes. Upstream of the supply connection, the fi tter shall provide a manual shut-off valve.
- Page 13 TORINO II Freestanding 1606 Page 13 INSTALLATION INSTRUCTIONS cont. WARNING: A minimum clearance of 1” to combustibles must be maintained on vertical pipe runs and 2” for horizontal pipe runs (sides and bottom 1”) Th e rigid vent systems use twist lock connections. Th e adaptor attached to the unit connects to the approved venting system.
- Page 14 TORINO II Freestanding 1606 Page 14 INSTALLATION INSTRUCTIONS cont. Vertical Installations Always maintain the 1” clearance around the vent pipe (vertical), when passing through ceilings, walls, roofs, enclosures, attic raft ers or any combustible surfaces. DO NOT PACK AIR SPACES WITH INSULATION. Refer to the vent chart for maximum allowable vertical and horizontal installations.
- Page 15 TORINO II Freestanding 1606 Page 15 INSTALLATION INSTRUCTIONS cont. Th rough Roof Framing Termination Above Roof Maintain 10” opening relative to the Consult local codes for minimum vent pitch of the roof. cap height above the roof, vent must be a minimum 2’...
- Page 16 TORINO II Freestanding 1606 Page 16 INSTALLATION INSTRUCTIONS cont. VENTING Th is appliance will not function without being connected to a proper venting system. Th is unit can be used with Selkirk (Direct-Temp), American Metal, Security Chimneys or Simpson Duravent 4” x 6-5/8” venting. Read the manufacturer’s installation instructions before installing the venting system.
- Page 17 TORINO II Freestanding 1606 Page 17 INSTALLATION INSTRUCTIONS cont. VERTICAL VENTING Example 1 V Value = 3A (12’) + 1C (3’) = 15’ H Value = 2B (4’) =4’ V Value = Total length of all vertical sections in feet. H Value = Total length of all horizontal sections in feet.
- Page 18 TORINO II Freestanding 1606 Page 18 INSTALLATION INSTRUCTIONS cont. Vent Restrictor (P/N 1851) Due to the extra fl ow produced by certain venting confi gurations a vent restrictor must be placed in the vent to maintain performance. All top vent installations over 20’ require the use of a 60% restrictor. Th e restrictor is installed in the exhaust of the appliance as shown in Figure’s 4, 5, and 6.
- Page 19 TORINO II Freestanding 1606 Page 19 INSTALLATION INSTRUCTIONS cont. CHART IV Typical vent Installation High Wind Vertical Termination Cap Flashing Alternate 45° pipe requiring strap support Twist Lock Joints Wall Thimble or Fire-S top OM-1606 E V1.03 April 2, 2014...
-
Page 20: Rigid Venting Parts List
TORINO II Freestanding 1606 Page 20 SIMPSON DURAVENT DIRECTVENT PRO / GS SYSTEM PARTS LIST RIGID VENTING PARTS LIST Description Part # Old Part # Horizontal Termination Kit - In Canada—Mandatory to add a wall thimble (46DVA- 46DVA-KHA KHC.) Vertical Termination Kit 6”... - Page 21 TORINO II Freestanding 1606 Page 21 SELKIRK PARTS LIST PART NUMBER DESCRIPTION 4" x 6 5/8" LENGTHS 1604006 4DT- 6 DIRECT-TEMP 6" PIPE LENGTH 1604006B 4DT- 6B DIRECT-TEMP 6" PIPE LENGTH BLACK 1604009 4DT- 9 DIRECT-TEMP 9" PIPE LENGTH 1604009B 4DT- 9B DIRECT-TEMP 9"...
- Page 22 TORINO II Freestanding 1606 Page 22 AMERICAN METAL PRODUCTS COMPONENTS LIST Description Part # 7” Pipe Length 12” Pipe Length 4D12 2’ Pipe Length 3’ Pipe Length 4’ Pipe Length 4” - 10” Adjustable Length 4D12A 45° Elbow 4D45L 90° Elbow 4D90L Vertical Termination 4DVC...
-
Page 23: Intermittent Pilot & Valve
TORINO II Freestanding 1606 Page 23 INTERMITTENT PILOT & VALVE SIT 885 Profl ame Valve Outlet pressure tap Stepper motor Pilot Connection (green) Inlet pressure tap Pilot Flame adjustment Main valve Connection (red) Ground connection OM-1606 E V1.03 April 2, 2014... - Page 24 TORINO II Freestanding 1606 Page 24 INTERMITTENT PILOT & VALVE cont. Optional Wall thermostat (interrupt green wir e) OM-1606 E V1.03 April 2, 2014...
-
Page 25: Wiring Diagram
TORINO II Freestanding 1606 Page 25 WIRING DIAGRAM WARNING Electrical Grounding Instructions This appliance is equipped with a three prong (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three prong receptacle . Do not cut or remove the grounding prong from this plug. The Appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1. -
Page 26: Lighting Instructions
TORINO II Freestanding 1606 Page 26 LIGHTING INSTRUCTIONS OM-1606 E V1.03 April 2, 2014... -
Page 27: Thermostat Remote Control
TORINO II Freestanding 1606 Page 27 THERMOSTAT REMOTE CONTROL OPERATING PROCEDURE Initializing the System for the fi rst time Install the 4 AA batteries into the receiver battery bay. Note the polarity of battery and insert into the battery bay as indicated on the Battery cover (+/-). - Page 28 TORINO II Freestanding 1606 Page 28 THERMOSTAT REMOTE CONTROL cont. Remote Flame Control Th e profl ame GTMF has six (6) fl ame levels. With the system on, and the fl ame level at the maximum in the appliance, pressing the Down Arrow Key once will reduce the fl ame height by one step until the fl ame is turned off .
- Page 29 TORINO II Freestanding 1606 Page 29 THERMOSTAT REMOTE CONTROL cont. Smart Th ermostat (Transmitter Operation) Th e Smart Th ermostat function adjusts the fl ame height in accordance to the diff erence between the set point temperature and the actual room temperatures. As the room temperature gets closer to the set point the Smart Function will modulate the fl ame down.
- Page 30 TORINO II Freestanding 1606 Page 30 THERMOSTAT REMOTE CONTROL cont. Remote Actuated 120V Auxiliary Outlet Th e auxiliary function controls the AUX power outlet on the Fan Control Module. To activate this function use the Mode Key (Fig. 1) to index to AUX Icon (Fig. 16 & 17). Pressing the Up Arrow Key will activate the outlet.
- Page 31 TORINO II Freestanding 1606 Page 31 THERMOSTAT REMOTE CONTROL cont. MANUAL BYPASS OF THE REMOTE SYSTEM If the batteries of the Receiver or Transmitter are low or depleted, the appliance can be turned on manually by sliding the three position slider switch on the Receiver to the ON position. Th is will bypass the remote control feature of the system and the appliance main burner will come on if the gas valve is in the “On”...
-
Page 32: Maintenance
Th is appliance is supplied with high temperature 5mm high temperature ceramic glass that will easily withstand the heat your unit was designed to produce. In the event the glass breaks, contact your dealer or BLAZE KING to arrange for your glass to be replaced / repaired. OM-1606 E V1.03... - Page 33 POLISH PLUS by KEL KEM c) COOK TOP CLEAN CREME by ELCO d) WHITE OFF by RUTLAND NOTE: This is a problem beyond Blaze King’s control and is not covered under warranty. NOTICE: COLD WEATHER OPERATION When using any gas appliance (LPG or NAT Gas) water is a by product of the combustion process. Under normal conditions this moisture is expelled through the vent into the atmosphere and does not cause any harm.
-
Page 34: Servicing
SERVICING UNDER WARRANTY Before servicing, read the terms and conditions of the Blaze King warranty at the back of this manual. Contact the Blaze King authorized dealer which you purchased the appliance from and provide him with details of the problem and the installation information which the installer fi lled out at the back of the manual. -
Page 35: Fuel Conversion
TORINO II Freestanding 1606 Page 35 FUEL CONVERSION WARNING: This conversion kit shall be installed by a qualifi ed service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fi... - Page 36 TORINO II Freestanding 1606 Page 36 FUEL CONVERSION cont. OM-1606 E V1.03 April 2, 2014...
-
Page 37: Burner Tray Removal And Installation
TORINO II Freestanding 1606 Page 37 BURNER TRAY REMOVAL AND INSTALLATION To remove the burner tray from the fi rebox, follow these steps: 1. Disconnect the gas and electricity to the appliance. 2. Open door. 3. Take out logs and brick panels. 4. -
Page 38: Valve Removal And Installation
TORINO II Freestanding 1606 Page 38 VALVE REMOVAL AND INSTALLATION TO BE DONE BY QUALIFIED PERSONNEL ONLY 1. Disconnect the gas and electricity to the appliance. 2. Remove pedestal front cover and rear cover (4 screws) including fan (fi g. 20c). 3. -
Page 39: Fan Removal And Installation
TORINO II Freestanding 1606 Page 39 FAN REMOVAL AND INSTALLATION To remove the fan, for maintenance or replacement, is easily accomplished by the following steps: 1. Turn off gas. 2. Disconnect electrical power to the appliance. 3. Remove the 4 screws holding the rear pedestal fan bracket to the appliance. (Fig. 21) 4. -
Page 40: Allowable Termination Locations
TORINO II Freestanding 1606 Page 40 ALLOWABLE TERMINATION LOCATIONS ____________________________________________________________________________________________________ A= Clearance above grade, veranda *(min. 12”/30 cm) *(min. 12”/30 cm) porch, deck or balcony ____________________________________________________________________________________________________ B= Clearance to w indow or door *(min. 12”/30 cm) *(min. 12”/30 cm) that may be opened ____________________________________________________________________________________________________ C= Clearance to permanently closed *(min. -
Page 41: Troubleshooting
TORINO II Freestanding 1606 Page 41 TROUBLESHOOTING Please check to make sure the instructions are followed exactly before attempting trouble shooting of the appliance. WARNING: Troubleshooting and servicing of gas and electrical devices of the appliance should only be conducted by a qualifi ed service technician. SYMPTOM ACTION The pilot will not stay lit. - Page 42 TORINO II Freestanding 1606 Page 42 TROUBLESHOOTING cont. SYMPTOM ACTION Sooty deposits on the glass door. If the fl ame is yellow and lazy, check for lint etc. around primary air shutter. Increase primary air by opening the primary air shutter if necessary, see “SERVICING”...
-
Page 43: Replacement Parts
TORINO II Freestanding 1606 Page 43 REPLACEMENT PARTS Expl. Item # Description Unit View OM1606 OWNERS MANUAL, TORINO II Freestanding 1606 Z0712 CONVERSION KIT-NATURAL GAS to PROPANE 0-4,500ft Z0713 CONVERSION KIT-NATURAL GAS to PROPANE 4,500-6,500ft Z0714 CONVERSION KIT-PROPANE to NATURAL GAS 0-4,500ft Z0715 CONVERSION KIT-PROPANE to NATURAL GAS 4,500-6,500ft 6065... - Page 44 TORINO II Freestanding 1606 Page 44 REPLACEMENT PARTS cont. OM-1606 E V1.03 April 2, 2014...
-
Page 45: Warranty
Blaze King and its respective brands extend the following warranty for gas appliances purchased from an authorized Blaze King dealer and installed in the United States of America or Canada. Warranty starts with date of purchase by the original owner (End User) except as noted for replacement parts. - Page 46 Blaze King is the manufacturer of the Blaze King line of heating products. At Blaze King, our commitment to the highest level of quality and customer service is the most important thing we do. Each Blaze King stove is built on a tradition of using only the fi...
- Page 47 WARRANTY cont. If you are not satisfi ed with the service provided by the Blaze King dealer, write to Blaze King at the address listed on the last page of the Owner’s Manual. Include a copy of the original purchase invoice and a description of the problem.
- Page 48 Labor rates are set per component and as such total labor costs may not be covered. 26. If a defect or problem is determined by Blaze King to be non warrantable, Blaze King will not be liable for travel costs for service work.
-
Page 49: Notes
TORINO II Freestanding 1606 Page 49 NOTES OM-1606 E V1.03 April 2, 2014...
