Table of Contents

Royal Guardian,
Blaze King,
Model RGT-3001
OWNER'S INSTALLATION AND OPERATION MANUAL
Blaze King
Royal
Guardian
Owner's Installation
and
Operation Manual
Manufactured By
Valley Comfort Systems Inc.
Blaze King Industries
1290 Commercial Way
146 A Street
Penticton, BC V2A 3H5
Walla Walla, WA 99362
CANADA
U.S.A.
Phone: (250) 493-7444
Phone: (509) 522-2730
Fax: (250) 493-5833
Fax: (509) 522-9803
Pour la version française de nos manuels S.V.P. vous référez à notre site web :
www.blazeking.com
Page 1
OM-RGT.PUB
Date Printed: Wednesday, November 07, 2012
Version 1.03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Royal Guardian RGT-3001 and is the answer not in the manual?

Questions and answers

Related Manuals for Blaze King Royal Guardian RGT-3001

Summary of Contents for Blaze King Royal Guardian RGT-3001

  • Page 1 OWNER'S INSTALLATION AND OPERATION MANUAL Blaze King Royal Guardian Owner's Installation Operation Manual Manufactured By Valley Comfort Systems Inc. Blaze King Industries 1290 Commercial Way 146 A Street Penticton, BC V2A 3H5 Walla Walla, WA 99362 CANADA U.S.A. Phone: (250) 493-7444...

  • Page 2: Safety Notice

    Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL SAFETY NOTICE IF THE BLAZE KING, ROYAL GUARDIAN, MODEL RGT-3001, STOVE IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. FOR YOUR SAFETY, FOLLOW THE INSTALLATION DIRECTIONS. CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN YOUR AREA.
  • Page 3 While we have made every effort to make these instructions as complete as possible, some installation or operating conditions may not be covered. If you have any questions that are not answered here, contact you BLAZE KING dealer, Local Building Inspector, Fire Department, or call our customer service department at B.K.I. Inc.in the U.S.A.
  • Page 4 Blaze King and its respective brands extend the following warranty for wood fired appliances purchased from an authorized Blaze King dealer and installed in the United States of America or Canada. Warranty starts with date of purchase by the original owner (End User) except as noted for replacement parts.
  • Page 5 Is covered by the Limited Warranty or b) Can be fixed in your home or does the product need to be returned to Blaze King for repair. 5. If Blaze King determines that the stove needs to be returned to Blaze King for repair, the customer has the responsibility and the expense of removing it from their home and shipping it to Blaze King.
  • Page 6 If you are not satisfied with the service provided by the Blaze King dealer, write to Blaze King at the address listed on the last page of the Owner’s Manual. Include a copy of the original purchase invoice and a description of the problem.
  • Page 7   25. If a defect or problem is determined by Blaze King to be non warrantable, Blaze King is not liable for travel costs for service work. In the event of in-home repair work, the customer will pay any in-home travel fees or service charges required by the Authorized Dealer.
  • Page 8 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL DEFINITIONS CHIMNEY One or more passageways, vertical or nearly so, for sending glue gases (smoke) to the outside atmosphere. 1. Listed Residential Type and Building Heating Appliance Chimney which complies with the...
  • Page 9 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL SAFETY CHIMNEY FIRE In the event of a fire in the chimney: a. Adjust the thermostat to its lowest setting. b. Check the Loading Door to be sure it is tightly closed.
  • Page 10 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL When selecting wood for the Model RGT-3001, it is preferable that you use seasoned wood. Dry, seasoned wood will burn cleaner and produce less creosote. Dry or small pieces of fuel will provide a hotter fire. Larger pieces can be used to provide a longer burn time.

  • Page 11: Specifications

    Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL SPECIFICATIONS FOR MODEL RGT-3001 Heat Output 39,000 Btu/hr. Wood Capacity (Approximate) White Oak ..................30 Lbs. Fir....................20 Lbs. Recommended Wood Length ............16 In./40.6cm Total Weight with Firebrick (approximate)......... 300 Lbs.
  • Page 12 PLEASE READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND USE YOUR NEW STOVE This Blaze King Model RGT-3001 Wood stove is Listed by INTERTEK TESTING SERVICES, ONLY if: it is connected to a suitable masonry chimney, or a 6 Listed Residential Type and Building Heating Appliance Type Chimney System (hereafter referred to as Chimney) and minimum clearances to combustible (burnable) materials are observed.

  • Page 13: Reduced Wall Clearances

    Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL CHIMNEY HEIGHT AFFECTS DRAFT Tall chimneys usually provide a strong, dependable draft. The chimney should be kept warm to enhance the draft. This will also reduce creosote accumulation caused by smoke and condensation of water vapor. A buildup of creosote can reduce the draft and will become a potential fire hazard.
  • Page 14 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL Fig. Air Space Combustible Nail or screw anchor Fig. Wall Min. 24 Gauge Sheet Metal 1 inch non-combustible spacer such as stacked washers, small diameter pipe, tubing, electrical conduit.
  • Page 15 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL GENERAL INSTRUCTION FLOOR PROTECTOR The stove must be placed on a floor protector if the floor is made of wood or other combustible flooring. Floor protection material: Any non-combustible material or Listed floor protector.
  • Page 16 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL CONNECTION TO A MASONRY CHIMNEY If the stove is being connected to a masonry chimney, the chimney should be examined for cracks, loose mortar and signs of deterioration or blockages. The stove should not be installed until it is determined that the chimney is safe for use.
  • Page 17 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL THIMBLE A thimble must be used when the connection from the stove is made through a combustible wall to a masonry chimney. There are several methods to use for connection through a combustible wall, two of which are illustrated in this manual. Local building authorities may be consulted or NFPA 211 and/or CAN-CSA B365 may be used for additional methods of chimney connection.
  • Page 18 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL CONNECTION TO A METAL PREFABRICATED CHIMNEY CHIMNEY One of the following listed chimney connectors (with compatible listed chimney system) can be used with this stove. In the U.S.A.: Duravent Dura Plus HT, AmeriTec HS, Metalbestos HT or Security 103 HT.
  • Page 19 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL REMEMBER: Follow the manufacturer's installation instructions and maintain the manufacturer's specified clearance distances.Install an attic insulation shield to maintain the specified clearance to insulation. Insulation in this air space will cause a heat buildup which may ignite the ceiling joists. This method of installation requires at a minimum a wall pass through device, a wall support package and insulated "T"...
  • Page 20 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL *REQUIRED TO ATTAIN ABOVE CLEARANCES 6" dia. 24/26 MSG Black/Blue steel chimney connector with Listed Residential Type and Building Heating Appliance type chimney. Side Shield with Fan Kit (P/N Z8301A), and 6" dia. 24/26 MSG Black/Blue steel chimney connector with Listed Residential Type and Building Heating Appliance type chimney.

  • Page 21: Installation Instructions

    Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL INSTALLATION INSTRUCTIONS A. RESIDENTIAL STANDARD AND REDUCED CLEARANCE CEILING EXIT INSTALLATION INSTRUCTIONS USING A PREFABRICATED CHIMNEY. Refer to Page 20, Fig. 21-23. Set floor protector and stove in location for marking holes in accordance with the label and figures of these instructions (page 20, Fig.
  • Page 22 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL RESIDENTIAL STANDARD AND REDUCED CLEARANCE WALL EXIT WITH PREFABRICATED CHIMNEY Refer to Page 20, Figures 24-25-26. Set floor protector and stove in location for marking holes in accordance with the label and figures of these instructions (Page 20, Fig.
  • Page 23 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL RESIDENTIAL STANDARD AND REDUCED CLEARANCE WALL EXIT WITH EXTERIOR MASONRY CHIMNEY Refer to Page 20, Fig. 24-25-26. Set floor protector and stove in location for marking holes in accordance with the label and figures of these instructions (Page 20, Fig.
  • Page 24 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL D. MOBILE HOME (FIG. 23,30), MOBILE HOME ALCOVE (FIG. 22), MOBILE HOME CORNER (FIG. 21), AND RESIDENTIAL ALCOVE (FIG. 22), INSTALLATIONS USING PREFABRICATED CHIMNEY. Refer to Page 20, Fig. 21, 22, 23, and Fig. 30 below.
  • Page 25 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL SIDE - SHIELD & FAN KIT P/N Z8301A Standard RGT Fan Assembly - Uppco, Model 50-T with insulated spade type connectors. Alternate RGT Fan Assembly - T30max Model 904-4999 with "push-in" connectors on the motor coil.

  • Page 26: Outside Air Kit

    Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL Rear Shield Wooden INSTALL SCREW INSTALL SCREW Handle NOTCH Control Assembly Firebox Mounting Holes For Rear Shield Side Shield Power Cord Fan Assembly with two 105 CFM INSTALL SCREW...
  • Page 27 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL OPERATION Your stove's performance (including its efficiency, pollutant emission level and service lifetime) depends largely on how it is operated. You are the most important factor affecting your stoves performance. Read these operation instructions carefully.
  • Page 28 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL COMBUSTION AIR CONTROL OPTIMUM SETTING AFTER LOADING OR RELOADING 1.Position: Leave the combustion air-control in the Medium to High position for at least fifteen minutes before making further adjustments 2.Temperature Adjustments:...

  • Page 29: Disposal Of Ashes

    Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL DISPOSAL OF ASHES WARNING NEVER STORE HOT ASHES IN A GARAGE OR BASEMENT. HOT ASHES WILL GENERATE CARBON MONOXIDE AND/OR FLAMMABLE GASES. THESE GASES MAY CAUSE SUFFOCATION. Disposal of ashes: Ashes should be placed in a sealed non combustible container until they are thoroughly cooled.
  • Page 30 REPLACING THE DOOR GASKET If the door gasket is to be replaced, be sure you have a replacement part ready to reinstall. See your Blaze King dealer. Be sure the fire is out, and the stove has cooled down. The door does not have to be removed from the stove.
  • Page 31 OWNER'S INSTALLATION AND OPERATION MANUAL LOADING DOOR GLASS REPLACEMENT Your BLAZE KING Model 3001 is equipped with a strong, heat-resistant ceramic glass intended to withstand extremely high temperatures and tested for continuous use above 1200 degrees Fahrenheit. However, this glass can be broken through improper use.

  • Page 32: Troubleshooting

    TROUBLESHOOTING Your Blaze King, Model RGT-3001 is designed to allow a wide selection of heat output levels. If you begin to lose control of the amount of heat the stove is emitting, determine the problem early so that major problems can be avoided.
  • Page 33 31 Measure draft with Manometer SEE DRAFTS, Pg. 31 Some chimneys may need to be relined. Consult your Blaze King Dealer or a chimney sweep. Strong, gusting winds causing down draft in Install wind-resistant chimney cap.

  • Page 34: Replacement Parts

    Listed below are some of the more commonly needed replacement parts. ITEM: PART#: NOTES: Damper Handle 0131A Door Handle 0121AA Spray Paint Contact your Blaze King dealer . (Specify Color) Door Gasket Gasket 6’x 7/8” Rheostat Knob O137 Door Glass Replacement Asmb. Contact your Blaze King dealer...
  • Page 35 Canadian stoves require high temperature pipe meeting S629M requirements and listed double wall pipe. Replace glass only with ceramic glass available from your Blaze King Dealer. Operate with doors closed only. Electrical rating: 115 V, 0.58 Amps, 60 Hz. Route power cord away from appliance.
  • Page 36 Royal Guardian, Blaze King, Model RGT-3001 OWNER'S INSTALLATION AND OPERATION MANUAL INDEX OF TOPICS, TABLES & ILLUSTRATIONS Page: Topic: Introductory Letter Clearance Kits and Optional Accessories Warranty Definitions Safety Specifications Installation Preparation Reduced Wall Clearances General Installation Instructions Minimum Clearances to Combustible Surfaces Residential Standard/Reduced Roof Exit Installation Residential Reduced Clearance Wall Exit Inst.
