INSTALLATION

Figure 6-4: USB Series "B" Receptacle Interface

6.2.1.2.3

Series "A" and Series "B" Plugs

Electrical and mechanical interface configuration data for Series "A" and Series "B" plugs are shown in
Figure 6-5 and Figure 6-6.

Figure 6-5: USB Series "B" Plug Interface

Spinpoint M8U-Internal Product Manual REV 3.4
36
