Product End-of-Life Disassembly Instructions
Product Category: Data Storage System
Marketing Name / Model
SCS-4106
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic
instructions for the disassembly of Seagate products to remove components and materials requiring selective
treatment, as defined by EU directive 2012/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
Items listed below are classified as requiring selective treatment.
Item Description
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
Batteries
Mercury-containing components
Liquid Crystal Displays (LCD) with a surface
greater than 100 sq cm
Cathode Ray Tubes (CRT)
Capacitors / condensers (Containing PCB/PCT)
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
External electrical cables and cords
Gas Discharge Lamps
Plastics containing Brominated Flame
Retardants weighing > 25 grams (not including
PCBs or PCAs already listed as a separate item
above)
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and
toner
Components and waste containing asbestos
83-00007928-00-01 Rev A | March 2022
Notes
With a surface greater than 10 sq cm.
1 in each of 2 I/O modules (IOMs)
1 in each of 2 power cooling modules
1 in 24-HDD baseplane in each of 4 PCBAs
1 in 10-HDD baseplane
1 in each of 4 expander riser cards
1 in each of 8 expanders
1 in each of 2 passthrough cards
1 in EBOD PCBA
1 in midplane PCBA
For example, mercury in lamps, display
backlights, scanner lamps, switches, batteries
Includes background illuminated displays with
gas discharge lamps
1 capacitor in each of 2 power supplies.
1 power cord for each of 2 power supplies.
4 SAS expansion cables for each of 2 IOMs.
1 RJ45 cable for each of 2 IOMs.
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
Quantity
of items
included
in
product
25 max
0
0
0
0
0
2
12 max
0
0
0
0
Page 1
