Setup Menu Basics:
Highlighted selection
Selects highlighted option
Navigates through the menu
Exits option and menu
Cancels changes and exits the menu
A TRACK MUST BE ENABLED TO BE RECORDED
12)
Press the INPUT key to enter the Track Setup Window, where Tracks are enabled
for recording. An * (asterisk) next to a Track indicates that the track is record en-
abled. Navigate through the Tracks using the Multifunction Rotary Switch. To en-
able/disable the track, press in on the Multi Function Rotary Switch. Track Status is
indicated by the asterisk and by the blue Track Status LEDs on the 788T front panel.
When the LED and asterisk is solid the track is armed and will be recorded, if they
are fl ashing the track is enabled but no active input is routed to it and will not be
recorded, if the asterisk and LED are off the track is disabled.
Track Setup Menu Basics:
Selector Box
Track Status Indicator
Input Routing Window
Master Levels Window
Track-to-Media Window
VU1 / VU2 Toggle
VU1 / VU2 toggle selects the Tracks displayed on the right-hand column of Track Meter LEDs.
Tip: After Inputs are routed to Tracks and the Tracks are record enabled, simply click the Input Gain Pots on and
off to arm and disarm tracks respectively.
MENU
HDD
Turn the Multi-Function Rotary Switch to navigate
through the Setup Menu, push to select an option.
MENU
HDD
VU1 = Tracks C, D, E, F, G. VU2 = G, H, X1, X2.
788T/788T-SSD User Guide and Technical Information
.
788T
INPUT
PWR
ARM
ARM
R
C
L
D
A
E
B
F
0
0
d
BFS
d
BFS
REC
IN CF EX
7
