788T/788T-SSD User Guide and Technical Information
# Setup Name
41 Time Code: Frame Rate
42 Time Code: Mode
Time Code: Hold Off
43
44 Time Code: User Bits
45 Time Code: Jam Menu
46 Time Code: Display Mode
47 Output 1: Source
48 Output 2: Source
49 Output 3: Source
50 Output 4: Source
51 Output 5: Source
52 Output 6: Source
53 Output 1: Analog Gain
54 Output 2: Analog Gain
Output 3: Analog Gain
55
56 Output 4: Analog Gain
57 Output 5: Analog Gain
58 Output 6: Analog Gain
59 Digital Input: AES42 Power
132
v. 2.10 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
Description
Sets the time code frame rate. All
common time code frame rates are
available.
Sets the mode for the time code
generator
Sets the duration that a valid time
code signal has to be recognized by
the 788T before generating a new
take while in Ext TC-Auto Record and
Ext TC/cont-Auto Record modes.
Sets the time code user bits gener-
ated by the 788T.
mm – month
dd – day of week
yy – year
tt – take number
uu – user-defined
Allows the user to jam or edit the
internal time code generator and user
bits. (Also accessible by pressing
HDD and MENU keys simultane-
ously).
Selects the source of the large
numerical display.
Selects the signal source for the each
of the 6 analog and digital outputs.
Sets the attenuation level of each
analog output bus.
Provides +10 V of Digital Phantom
Power to each digital input. Never
apply digital phantom to unbalanced
digital inputs, as this can result in
damage to the hardware.
Options
• 23.976
• 24
• 25
• 29.97
• 29.97DF
• 30
• 30DF
• 30+
• Off
• Free Run
• Free Run - Jam Once
• Record Run
• 24 Hr Run
• Ext TC
• Ext TC/cont
• Ext TC-Auto Record
• Ext TC/cont-Auto Record
0.0 to 8.0 seconds adjustable in increments of
.1 seconds
• Not Used – user bits are not set or output
• mm:dd:yy.tt
• dd:mm:yy.tt
• uu:uu:tt:tt – user bits are set to 4 user defin-
able digits with 4 take digits
• uu:uu:uu:uu
• tt:tt:tt.tt – user bits are set to the take coun-
ter for all 8 digits
• mm:dd:yy:uu
• dd:mm:yy:uu
• Jam RX TC
• Jam Zeros
• Jam Value
• Edit Value
• Edit U-Bit
• Big A-time
• Big time code
• Input 1 • Track B
• Input 2 • Track C
• Input 3 • Track D
• Input 4 • Track E
• Input 5 • Track F
• Input 6 • Track G
• Input 7 • Track H
• Input 8 • Track X1
• Track L • Track X2
• Track R • HP Mix Left
• Track A • HP Mix Right
Selectable from -40 to 0 dB in 1 dB incre-
ments
• Disabled
• Enabled
Factory
Default
30
Free Run
2.0 sec
mm:dd:yy.tt
Big A-time
Output 1 = Track L
Output 2 = Track R
Output 3 = Track A
Output 4 = Track B
Output 5 = Track C
Output 6 = Track D
Output 1 = -4 dB
Output 2 = -4 dB
Output 3 = -4 dB
Output 4 = -4 dB
Output 5 = -4 dB
Output 6 = -4 dB
Disabled
