Fader Assignment

The CL-2 Fader controls the fader level of any 788T Input. Fader assignment is done in Setup Menu
option CL-2: FADER ASSIGN.
When connected, the 788T fader or CL-8 fader (if attached) of the selected input will be disabled and
replaced by the CL-2 fader.
Movement of the 788T or CL-8 fader will have no effect on an assigned input while the CL-2 is con-
nected. If the Setup Menu option INPUT: FRONT PANEL CONTROLS is set to Trim Controls and there
is no CL-8 attached, the input selected will be the only input with a fader control. When set to Trim
Controls all other input fader levels default to unity gain (0 dB).
CL-2 Switches
The CL-2 is equipped with two, two-position programmable toggle switches that can be assigned to
control select functions of the 788T. Switches 1 and 4 are momentary switches and Switches 2 and 3
are latching. The Switches can be assigned to control the following functions in the Setup Menu op-
tion KEYBOARD/LOGIC IN: ASSIGN. Please note that momentary switches can be assigned to have
momentary or toggle action, toggle switches can only be assigned to toggle action.
Function
Momentary
Record Button
Play Button
Stop Button
Fast Forward Button
Rewind Button
Menu Button
HDD Button
Tone Button
Brightness Button
Input Button
Power Button
Rotary Switch Push
Button

Switches 1, 4

Switches 2, 3
(Latching)
(Momentary)
Toggle Toggle Only
788T/788T-SSD User Guide and Technical Information
Sw 1,4 Momentary - Hold to record, release to stop.
Sw 1,4 Toggle - Press and release switch to record,
press and release again to stop.
Sw 2,3 Toggle - On enters record, Off stops the
recording.
Sw 1,4 Momentary - Hold to play, release to pause.
Sw 1,4 Toggle - Press and release switch to play,
press and release again to pause.
Sw 2,3 Toggle - On enters playback, Off pauses
playback.
Record Mode - Stops recording
Playback Mode - One press pauses, two presses
stops playback
Press and hold to fast forward playback, release to
resume playback
Press and hold to rewind playback, release to
resume playback
Sw 1,4 - Acts as Menu Button
Sw 2,3 - On enters Setup Menu, Off exits
Sw 1,4 - Acts as HDD Button
Sw 2,3 - On enters Take List, Off exits
Acts as the Tone Button (Generates Tone from Main
LCD display only)
Acts as the Brightness Button
Sw 1,4 - Toggles Track Setup Window / Exits
Sw 2,3 - On enters Track Setup Window, Off exits
Functions in the Main Display only
Powers down the 788T, does not initiate power up
Acts as Multi Function Rotary Switch Push Button
Performs action defined in Setup Menu option HP:
Rotary Push Function
Notes
