Power and Control Connections
DC 9V (Power)
Connect to the included 9 Volt DC power supply. The power supply must be regulated at 9 Volts
(direct current), able to source at least 180 mA (milliamps) of current, and the plug should have a tip-
negative, sleeve-positive polarity (the center tip is ground and the sleeve is power).
USB
Connect to your computer (Mac or Windows) to the Lunar's USB port (denoted by the
using a standard mini USB cable. The Lunar is a class compliant USB device, meaning that it should be
recognized by Mac and Windows computers automatically. For more information about the Lunar's
USB capabilities, refer to the
Control Input
The 3.5 mm Control Input port connects to external control devices such as the Dual Expression
Pedal, Reflex Universal Expression Pedal, Neuro Hub, and Hot Hand Motion Controller. For more
information, refer to the
User's Guide.
SA241
USB section of the User's Guide.
Expression Pedal Input,
Lunar Phaser User's Guide
Hot Hand Input, and Neuro Hub
icon)
sections of the
