Driving Safety ................................................................................................................................... 2-1

Fuel and Propane Gas ....................................................................................................................... 2-1

LP Gas Leaks .................................................................................................................................... 2-2

Propane Gas Leak Detector .............................................................................................................. 2-2

Carbon Monoxide Warning .............................................................................................................. 2-3

Carbon Monoxide Alarm .................................................................................................................. 2-3

Smoke Alarm .................................................................................................................................... 2-4

Fire Extinguisher ............................................................................................................................... 2-4

Electrical ........................................................................................................................................... 2-5

Loading ............................................................................................................................................. 2-5

Maintenance ...................................................................................................................................... 2-5

Emergency Exits ............................................................................................................................... 2-5

Power Sofas and Beds ....................................................................................................................... 2-6

Slideout Rooms ................................................................................................................................. 2-6

Formaldehyde Information ............................................................................................................... 2-7

Mold, Moisture, and Your Motor Home ........................................................................................... 2-7

Roof and Ladders .............................................................................................................................. 2-8

Roadside Emergency ........................................................................................................................ 2-8

Jump Starting .................................................................................................................................... 2-9

Engine Overheat ............................................................................................................................. 2-10

3 - DRIVING YOUR MOTOR HOME

Seats - Driver/Co-Pilot ..................................................................................................................... 3-1

Passenger Footrest ............................................................................................................................ 3-2

Seat Belts .......................................................................................................................................... 3-3

Child Restraints ................................................................................................................................. 3-4

Rev. 1018100830

Part No. 161500-10-033

Table of Contents

Need help?

Do you have a question about the 2010 Meridian V Class and is the answer not in the manual?

Questions and answers

Summary of Contents for Winnebago 2010 Meridian V Class

Page 1: Table Of Contents
Engine Overheat ..........................2-10 3 – DRIVING YOUR MOTOR HOME Seats – Driver/Co-Pilot ........................3-1 Passenger Footrest ..........................3-2 Seat Belts ............................3-3 Child Restraints ..........................3-4 Rev. 1018100830 Part No. 161500-10-033 Copyright 2009 Winnebago Industries, Inc. All rights reserved.
Page 2 Table Of Contents KeyOne™ Lock System ........................3-5 Power Door Locks ..........................3-5 Mirrors – Power Electric ........................3-6 Rearview Monitor System ........................ 3-8 Rearview Monitor System ........................ 3-9 12-Volt Front Drop-Down Solar/Night Shade .................. 3-9 GPS Navigation System ........................3-10 Parking Brake ..........................
Page 3 Table Of Contents Energy Management System (EMS) ....................4-7 Water Heater - Gas/ Electric ......................4-7 Pressure-Temperature Relief Valve ....................4-8 MotorAid Water Heater ........................4-9 Propane Gas Furnace ........................4-9 Electronic Thermostat ........................4-10 Furnace-A/C Thermostat Operation Chart ..................4-12 Central Air Conditioner ........................
Page 4 Table Of Contents WaterLine and Tank Drain Valves ....................7-8 Water Heater Bypass Valve ......................7-9 Winterizing Procedures ........................7-9 Winterizing Optional Appliances ....................7-14 Water System Drain Valve Locations ..................... 7-16 8 – ENTERTAINMENT High Definition Video Selection System ..................8-1 Front TV/Buffet TV Ignition Switch Interlock .................
Page 5 Table Of Contents Leveling System ..........................10-9 Checking Hydraulic Oil Level ...................... 10-11 11 – MAINTENANCE AND STORAGE Sealants – Inspection and General Information ................11-1 Roof ..............................11-1 Undercarriage ..........................11-1 Exterior Automotive Paint Finish ....................11-2 Care of Appliques and Decals ......................11-4 Front End Masks and Paint Damage ....................
Page 7: Introduction
DANGER indicates a hazardous situation are intended as a guide, and in no way which, if not avoided, will result in death or extend the responsibilities of Winnebago serious personal injury. Industries beyond the standard written warranty as presented in this manual.
Page 8: Pre-Delivery Inspection
National Highway Traffic Safety Administration delivery inspection of the chassis and all motor (NHTSA) in addition to notifying Winnebago home components. Industries, Inc. As a part of the pre-delivery inspection...
Page 9: Occupant And Cargo Carrying Capacity Label
SECTION 1 – INTRODUCTION or go to their website at http://www.safercar.gov or write to: Administrator, NHTSA 1200 New Jersey Avenue S.E. Washington, D.C. 20590 You can also obtain other information about motor vehicle safety from the NHTSA website at http://www.safercar.gov OCCUPANT AND CARGO CARRYING CAPACITY LABEL This label is affixed in the driver’s area next to...
Page 10: Vehicle Certification Label
These pressure levels must be maintained to assure proper handling, safety, 2. Chassis manufacture date. and fuel economy. 3. Month and year of manufacture at Winnebago ® 9. Rear Axle Wheel Configuration: Single or Industries Dual as it relates to the inflation.
Page 11: Specifications And Capacities
SECTION 1 – INTRODUCTION SPECIFICATIONS AND CAPACITIES ® ® Freightliner Freightliner Itasca Meridian V Class 27,910 lb. 27,910 lb. Chassis Chassis Feature Number Length 34' 11" 39' 11" 12' 2" 12' 4" Exterior Height 8' 5" 8' 5" Exterior Width 113.1 cu.
Page 12: Owner And Vehicle Information
Motor Home Serial Number __________________________________________________________ Chassis Vehicle Identification No. (VIN) ________________________________________________ Vehicle Mileage at Delivery __________________________________________________________ Selling Dealer Name ________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ ® YOUR WINNEBAGO INDUSTRIES DEALER /SERVICE CENTER Name ____________________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ Contact ____________________________________________Phone ________________________ CHASSIS SERVICE CENTER...
Page 13: 2010 New Vehicle Limited Warranty
ITEMS NOT SUBJECT TO WARRANTY COVERAGE Winnebago Industries, Inc. of Forest City, Iowa, warrants each new Chassis, drivetrain and related components* Winnebago and Itasca motor home to the owner for recreational use Wheels* in the U.S.A. and Canada as follows:...
Page 14 If you are touring or have moved, contact any unresolved warranty disputes for recreational vehicles. This dispute Winnebago Industries motor home dealer in the United States or resolution program reviews eligible product and service related Canada for warranty service.
Page 15: Safety And Precautions
SECTION 2 – SAFETY AND PRECAUTIONS • Use care when accelerating or decelerating on GENERAL WARNINGS a slippery surface. Abrupt speed changes can cause skidding and loss of control. • Only seats equipped with seat belts are to be occupied while the vehicle is moving. •...
Page 16: Lp Gas Leaks
SECTION 2 – SAFETY AND PRECAUTIONS • All pilot lights must be extinguished and asphyxiation is greater when the appliance is appliances turned off while refilling the fuel used for long periods of time. Failure to comply tank or LP gas tank. could result in death or serious injury.
Page 17: Carbon Monoxide Warning
SECTION 2 – SAFETY AND PRECAUTIONS The best protection against carbon monoxide entry into the vehicle body is a properly WARNING maintained engine exhaust and ventilation system. It is recommended that the exhaust system and body be inspected by a qualified EXPLOSION HAZARD: DO NOT use an motor home service center: open flame to test for gas leaks.
Page 18: Smoke Alarm
InfoCase for further instructions. that is also listed for RV application. We Replacement recommend obtaining a replacement from your ® Winnebago Industries dealer. When replacing this alarm, we recommend replacing only with the same model, or with one Further Information that is also listed for RV application.
Page 19: Electrical
MAINTENANCE your coach. We recommend obtaining a replacement only from your Winnebago • Do not remove the radiator cap while engine ® Industries dealer or a reliable RV parts supplier.
Page 20: Power Sofas And Beds
SECTION 2 – SAFETY AND PRECAUTIONS POWER SOFAS AND BEDS WARNING Keep people away from operating mechanism and pinch hazard areas during use. Failure to do so could cause injury. SLIDEOUT ROOMS Escape Window - Lift latch handles upward to open WARNING Using Slider Windows As Emergency Exits...
Page 21: Formaldehyde Information
SECTION 2 – SAFETY AND PRECAUTIONS Mold is a plant and requires its own special FORMALDEHYDE environment to grow. That environment includes INFORMATION organic materials, nutrients, moisture, and proper temperature. Some of the materials used in this recreational vehicle emit formaldehyde. Eye, nose, and throat How Can I Avoid Mold? irritation, headache, nausea, and a variety of To reduce the ability for mold to grow, you...
Page 22: Roof And Ladders
® while in use. Never use the ladder when it is Winnebago Industries raining, snowing, or icy. The rungs can If Winnebago Industries determines that mold become slippery. Do not step onto the rungs if ® ® is present in the Winnebago...
Page 23: Jump Starting
We recommend that you ask for an underlift (wheel lift or frame lift) type towing assembly for safe towing. ® Winnebago Industries does not assume responsibility for damage incurred while towing this vehicle.
Page 24: Engine Overheat
SECTION 2 – SAFETY AND PRECAUTIONS ENGINE OVERHEAT If you see or hear steam escaping from the engine compartment or have any other reason to suspect an extreme engine overheating condition, pull the vehicle over to the roadside as soon as it is safe to do so, stop the engine, and get all passengers out of the vehicle.
Page 25: Driving Your Motor Home
SECTION 3 – DRIVING YOUR MOTOR HOME The information in this section refers only to Front Seats features installed or adapted to the dash and –Standard driver compartment area by Winnebago ® Industries . It also includes passenger seating in the living area of the coach.
Page 26: Passenger Footrest
SECTION 3 – DRIVING YOUR MOTOR HOME • Reverse the procedure to face the seat forward. Armrest Adjustment The armrests may be swung upward out of the way for easy exit or access to the front seats. A roller on the underside of the front of the armrest also lets you adjust the resting angle for personal comfort, whether the seat is upright or reclined.
Page 27: Seat Belts
SECTION 3 – DRIVING YOUR MOTOR HOME To Fasten Be sure belt is not twisted. Grasp each part of the belt assembly and push tongue into buckle. Adjust to a snug fit by pulling the loose end away from the tongue. To Release Press button in center of buckle and slide tongue out of buckle.
Page 28: Child Restraints
SECTION 3 – DRIVING YOUR MOTOR HOME 2. Make sure that it will attach to your vehicle and restrain your child securely and WARNING conveniently so that you are able to install it correctly each time it is used. 3. Be certain that it is appropriate for the child's Never wear the shoulder belt in any height, weight, and development.
Page 29: Keyone Lock System
The key number for your coach is registered in our factory database, so if you ever lose your ® keys, any Winnebago Industries dealership can order a new key for you. POWER DOOR LOCKS...
Page 30: Mirrors - Power Electric
SECTION 3 – DRIVING YOUR MOTOR HOME Reprogramming Remote When replacing batteries, the remote unit may need to be reprogrammed with a switch on the keyless entry system control box. The entry system control box is located behind the circuit breaker mounting panel in the 12-volt electrical compartment at the front left side of the coach.
Page 31 SECTION 3 – DRIVING YOUR MOTOR HOME Mirror Arm/Head Adjustment Mirror Arm Mounting Base If you cannot adjust a mirror properly using the control switch, the mirror may need a coarse adjustment by repositioning the mirror arm and/ or rotating the mirror head. Mirror Head Pivot Lock Unscrew protective caps and loosen Allen head set screws to pivot mirror arm.
Page 32: Rearview Monitor System
SECTION 3 – DRIVING YOUR MOTOR HOME Basic Operating Instructions Power • Turn ON to activate monitor for rear viewing while driving or parked. Key must be on. • In OFF (Standby) position the monitor is “asleep” and will “wake up” when the transmission is shifted into reverse.
Page 33: 12-Volt Front Drop-Down Solar/Night Shade
SECTION 3 – DRIVING YOUR MOTOR HOME Sideview Cameras* (if equipped) REARVIEW MONITOR SYSTEM The optional sideview cameras activate with the –If Equipped corresponding turn signals and replace the rear camera view on the monitor until the turn is completed or the signal lever is canceled manually.
Page 34: Gps Navigation System
SECTION 3 – DRIVING YOUR MOTOR HOME Dual range motors provide lowering of either NOTE: Be sure the Input Button on the GPS two shades to visor height restriction when the Display Panel is set to VIDEO 1. ignition is ON and lowers completely to cover the To operate GPS from the rearview monitor, entire windshield when the ignition is OFF.
Page 35: Parking Brake
SECTION 3 – DRIVING YOUR MOTOR HOME The increased back pressure would normally PARKING BRAKE stop the engine except the forward momentum of ® the vehicle keeps the drivetrain and the engine Freightliner Chassis turning. This controlled back pressure helps to regulate a vehicle’s downhill speed, such as on mountainous or hilly roads.
Page 36: Hazard Warning Flashers
SECTION 3 – DRIVING YOUR MOTOR HOME HAZARD WARNING FLASHERS SIGNAL LEVER/HEADLIGHT HI/LO BEAM The hazard warning flashers provide additional safety when the vehicle must be The signal lever controls the turn signals and stopped on the side of the roadway and presents a high/low beam changing.
Page 37: Steering Column Adjustment
SECTION 3 – DRIVING YOUR MOTOR HOME WARNING Do not adjust the steering column or tilt wheel while the vehicle is in motion. Doing so may cause loss of vehicle control resulting in death or personal injury. Further Information BATTERY BOOST SWITCH See your chassis manual in your InfoCase for further information on this switch.
Page 38: Defrost Fans
SECTION 3 – DRIVING YOUR MOTOR HOME Temp Mode Switch Control Selector NOTE: The dash air conditioner/heater is not Please refer to the manufacturer’s operating designed to heat and cool the entire guide in your InfoCase for detailed instructions interior of the coach, but is intended only on programming preset station buttons and using to provide heating and cooling for the this full-featured radio/audio system.
Page 39: Sirius Plug And Play Satellite Radio
SECTION 3 – DRIVING YOUR MOTOR HOME Radio Power Switch See the manufacturer’s information in your InfoCase for operating instructions. The radio power switch lets you connect the dash radio to the coach batteries with the ignition Radio Remote Controls switch turned off for listening while parked.
Page 40: Cb Radio Power Wiring
SECTION 3 – DRIVING YOUR MOTOR HOME To install the satellite unit, place your Sirius Look for a pair of wires - yellow (+) and white radio into the docking station, aligning the tabs at (-) with connectors and flag labels suspended the edges of the the radio adapter with the from the wiring harness.
Page 41: Filling The Fuel Tank - Diesel Engine
SECTION 3 – DRIVING YOUR MOTOR HOME Idling Diesel Engine “slushy.” If this happens, the only remedy is to have the vehicle towed into a heated facility to allow the fuel to warm up and become fully liquid again. NOTICE During winter time, most truck stops and reputable filling stations have winter blend diesel Do not operate engine at low idle for long...
Page 42: Front Service Access
SECTION 3 – DRIVING YOUR MOTOR HOME Hood Lock Key (Located on your key ring) Diesel Engine Heater Switch -Typical View REMEMBER! Turn the engine heater switch off after starting the engine. The heater will keep operating for as long as it is supplied with electricity.
Page 43: Engine Top Access Covers - Rear
SECTION 3 – DRIVING YOUR MOTOR HOME Rear Engine (Shown with grille panel open) With the grille panel open, you can access the Engine Oil Fill following service points: (Located top of engine) • Engine Oil Dipstick • Engine Oil Fill Cap •...
Page 44 SECTION 3 – DRIVING YOUR MOTOR HOME A falling bed board can injure. Assure the bed is properly supported. Refer to instructions for propping the bed board. • Unlatch the engine cover and remove for access. Unlatch engine cover(s) beneath Models with “East-West”...
Page 45: Fuel/Water Separator - Diesel Engine
SECTION 3 – DRIVING YOUR MOTOR HOME the bottom of the board is seated firmly against the steel frame on the floor for security. FUEL/WATER SEPARATOR – DIESEL ENGINE –If Equipped Detail of drain valve on bottom end Diesel fuel often contains small quantities of of fuel/water separator water which can damage the engine if not filtered •...
Page 46: Chassis Battery Disconnect Switch
SECTION 3 – DRIVING YOUR MOTOR HOME CHASSIS BATTERY DISCONNECT SWITCH 12-Volt Automotive Fuse Panel The chassis battery disconnect switch disconnects most chassis electrical loads from the chassis (starting) batteries to avoid discharge by constant draws such as engine computers, radio clock, sensors, etc.
Page 47: Windshield Washers And Wipers
SECTION 3 – DRIVING YOUR MOTOR HOME TIRES Improper tire pressure can result in tire overloading and abnormal wear and also affects handling, ride characteristics, and fuel economy. WARNING Make sure all replacement tires are of the Fuse Diagram (inside of cover) same size and rating as those shown on your Vehicle Certification Label.
Page 48: Lights
SECTION 3 – DRIVING YOUR MOTOR HOME Further Information See the chassis manual in your InfoCase for further information. LIGHTS All exterior lights should be checked for proper operation each time the vehicle is prepared for a trip. Any bulbs which fail to light should be checked and replaced, when necessary, with a new bulb of the same size.
Page 49: Appliances And Systems
SECTION 4 – APPLIANCES AND SYSTEMS The appliances installed in your motor home are manufactured by reputable RV appliance makers and have been tested by independent laboratories to meet all applicable standards and codes set for RV appliances. See Section 2 of this manual for any safety and precautions you need to take regarding the operation of your appliances.
Page 50: Ice Maker
SECTION 4 – APPLIANCES AND SYSTEMS Further Information See the refrigerator manufacturer’s operation, care and maintenance information in your InfoCase. REFRIGERATOR SERVICE ACCESS COMPARTMENT • Press the MODE button to select energy source. There are three settings: (Exterior) LP (Gas Mode) - Refrigerator will operate on The exterior refrigerator service compartment gas from the propane tank if the main valve is allows access to the rear of the refrigerator for...
Page 51: Microwave Oven/Range Hood
SECTION 4 – APPLIANCES AND SYSTEMS MICROWAVE OVEN/RANGE HOOD The range hood vent is built into the microwave oven. The range hood fan carries cooking odors and gas fumes to the outside of the coach. A light on the underside of the hood provides illumination for food preparation.
Page 52: Oneplace® Systems Monitor Panel
SECTION 4 – APPLIANCES AND SYSTEMS ® your coach. It also includes the TrueAir climate ® control thermostat and the PowerLine Energy Management System status panel. Unlike homes, the amount of oxygen supply is limited due to the size of the recreational vehicle, and proper ventilation when using the cooking appliances avoids dangers of asphyxiation.
Page 53: Generator Hourmeter
SECTION 4 – APPLIANCES AND SYSTEMS Generator Hourmeter Gray Waste Tank Selector (Model 39N only) See Electrical Systems section for generator hourmeter information. This model has two gray water tanks. Because the monitor can display only one gray water tank Water and Holding Tank Levels at a time, a selector switch is provided.
Page 54: Solar Charger Panel
SECTION 4 – APPLIANCES AND SYSTEMS Battery Voltage Meter Press the “House Battery” switch position to check the level of charge (voltage) in the 12-volt house batteries. Press the “Engine Battery” position to check chassis battery charge. To get an accurate reading; 1.
Page 55: Energy Management System (Ems)
SECTION 4 – APPLIANCES AND SYSTEMS Read the Water Heater Operation Manual for ENERGY MANAGEMENT complete Safety Warnings, Operating SYSTEM (EMS) Instructions and Maintenance Information before operating the water heater. –If Equipped Be sure the water heater is filled with water The Energy Management System (EMS) before starting either electric or propane gas monitors the electrical usage of the appliances...
Page 56: Pressure-Temperature Relief Valve
SECTION 4 – APPLIANCES AND SYSTEMS Water Heater Exterior Service Access Electric Water Heater Switch Normally there is an air gap at the top of the (typically located near Systems water heater tank, which acts as a pressure buffer. Monitor Panel) In time, however, heated water may expand and For Quick Recovery Operation fill this air gap, causing a slight increase in water...
Page 57: Motoraid Water Heater
SECTION 4 – APPLIANCES AND SYSTEMS NOTICE Any leak in the heat exchanger or its supply or return lines could cause loss of coolant and subsequent engine failure. We recommend that you periodically inspect these connecting lines and the heater to insure that no leaks have developed.
Page 58: Electronic Thermostat
SECTION 4 – APPLIANCES AND SYSTEMS NOTE: If heat does not come out of the heat Temperature Selector ducts after a minute or so the burner is not lit. Turn thermostat off for 3-5 minutes, check to be sure propane gas tank valve is open and tank is not empty, then try steps 2-4 again.
Page 59 SECTION 4 – APPLIANCES AND SYSTEMS changing the temperature setpoint. A few seconds after you release the temperature selector button, the display will return to showing the current room temperature. Cooling (A/C) • Slide the thermostat switch to Cool position. •...
Page 60: Furnace-A/C Thermostat Operation Chart
SECTION 4 – APPLIANCES AND SYSTEMS FURNACE-A/C THERMOSTAT OPERATION CHART The following chart shows the system functions with the “Heat/Cool” thermostat. Disregard references to heat functions when using the “Cool Only” thermostat in the rear bedroom. X = Switch Position O = Switch position does not matter or is inactive for this feature FAN MODE FAN SPEED...
Page 61: Air Conditioner Filter
SECTION 4 – APPLIANCES AND SYSTEMS cleaning or service. Remove the screws under the NOTE:Do not block the filter in any way, such as lower edge of the panel and swing it upward for by setting packages or newspapers, etc. access to the condenser.
Page 62: Washer/Dryer - Prep Package
Typically, the plumbing is located inside the rear linen cabinet (remove shelving and panels to access). We recommend obtaining parts and service for the washer/dryer installation from your ® ® Winnebago or Itasca dealer. 4-14...
Page 63: Propane Gas
SECTION 5 – PROPANE GAS PROPANE GAS SUPPLY The propane gas system supplies fuel for the gas range/oven, water heater, furnace, and refrigerator (while in gas mode). When used and handled properly, this system is safe and economical and provides modern living conveniences wherever you travel.
Page 64: Propane Gas Supply (Remote Lp Fill)
SECTION 5 – PROPANE GAS phone directory yellow pages for locations of local propane gas refilling stations or bulk DAN GE R dealerships. NOTE: If you travel outside the U.S. with your DO NOT FILL CONTAINER TO MORE motor home, you may find butane or THAN 80 PERCENT OF CAPACITY.
Page 65 SECTION 5 – PROPANE GAS How Propane Gas Works Main Tank Overflow Propane is a type of LP (Liquefied Petroleum) Shutoff Valve gas compressed into liquid form for easy Switch transportation and storage. Propane gas may also be called tank gas, bottle gas, or simply LP. Propane is used by appliances in vapor form only, but is stored in the tank as a liquid under Tank Fill...
Page 66 SECTION 5 – PROPANE GAS DAN GE R DO NOT FILL CONTAINER TO MORE THAN 80 PERCENT OF CAPACITY. FAILURE TO COMPLY COULD RESULT IN A FIRE OR PERSONAL INJURY. Make sure the motor home is level when filling. It is possible to accidentally overfill the tank if the vehicle is not level, with the Main Tank Shutoff Switch fill valve on the uphill side.
Page 67: Safe Use Of The Propane Gas System
SECTION 5 – PROPANE GAS phone directory yellow pages for locations of • Exercise caution at all times. Be familiar with local propane gas refilling stations or bulk the distinctive odor of propane gas. If a leak is dealerships. suspected, turn off the supply valve immediately.
Page 68: Propane Gas Warnings And Precautions
SECTION 5 – PROPANE GAS PROPANE GAS WARNINGS AND PRECAUTIONS WARNING It is illegal for vehicles equipped with propane tanks to travel on certain roadways or through Propane cylinders shall not be placed or certain tunnels in the U.S. To avoid stored inside the vehicle.
Page 69: Propane Vaporization In Cold Weather
SECTION 5 – PROPANE GAS WARNING Visually inspect the pressure regulator vent periodically for blockage by accumulated debris or insect nests, etc. Vent obstruction could result in excessive pressure causing fire or explosion, which could result in death or serious injury. If an obstruction exists, have the regulator serviced by a qualified service center.
Page 70 SECTION 5 – PROPANE GAS This means that in extremely cold weather when a large volume of gas is being used by the furnace for heating, it is possible to experience a loss of gas pressure. At first, this problem may appear to be caused by an empty tank or a regulator freeze-up, but is actually caused by failure of the liquid gas to vaporize as fast as it is needed by the furnace.
Page 71: Electrical
SECTION 6 – ELECTRICAL Your coach is equipped with an electrical the power converter automatically changes a system consisting of two separate voltages: portion of the 120-volt current to 12-volt DC current. All equipment in the motor home that is •...
Page 72: Connecting The Power Cord
SECTION 6 – ELECTRICAL be used is designed to mate with the prongs of the power cord plug, the electrical connection can be expected to carry rated load. Connecting The Power Cord To connect to an external source, remove the cord from the utility compartment and plug it into a suitable 50-amp power receptacle to provide external power to the coach and converter/...
Page 73: Inverter Unit - 1000W
SECTION 6 – ELECTRICAL Inverter Control Panel INVERTER UNIT – 1000W –If Equipped –If Equipped The inverter has a wall-mounted monitor/ The inverter unit is located on the wall of the control panel. It will also display warnings for utility compartment. overload conditions or other operating failure conditions.
Page 74: Circuit Breakers - House 120-Volt Ac
SECTION 6 – ELECTRICAL Current drawn from the house batteries passes The thermal overload will reset itself after a through the power converter unchanged, period of time, and the lights and motors will although it is routed through a series of protective again resume operation from the power converter fuses located on the power panel.
Page 75: Electrical Outlets - House 120-Volt Ac
SECTION 6 – ELECTRICAL ELECTRICAL OUTLETS – HOUSE 120-VOLT AC WARNING A number of standard household electrical outlets are provided throughout the coach for The GFCI will not completely eliminate connecting small appliances such as televisions, the risk of electrical shock. Infants and radios, toasters, etc.
Page 76 SECTION 6 – ELECTRICAL See the AGS user guide for more information to help understand the AGS feature and its operation with your generator. Generator Basic Operation To Start the Generator Press and hold the generator switch in START position until you hear the generator running smoothly, then release.
Page 77: Electrical System - House 12-Volt Dc
SECTION 6 – ELECTRICAL Operation Warnings and Cautions Converter See “Power Center.” Chassis Battery WARNING The chassis battery is used to operate the engine starter and automotive accessories and The exhaust of all internal combustion controls found on the instrument panel. The engines contains carbon monoxide (CO).
Page 78: House Battery Disconnect Switch
SECTION 6 – ELECTRICAL A label on the panel states the amperage rating See also “Battery Care” elsewhere in this and circuit protected for each fuse or breaker. section. House Breaker Panel The House 12-Volt Breaker Panel is located in the rear of the coach beneath the rear bed or in a cabinet above the washer/dryer area.
Page 79: Battery Care
SECTION 6 – ELECTRICAL 2. Check the battery and recharge as necessary at least once a month during long storage periods. Turn the House/Coach Batt Switch off to avoid electrical arcing when attaching or detaching charger clamps. WARNING California Proposition 65 Warning: Battery posts, terminals, and related House accessories contain lead and lead...
Page 80 SECTION 6 – ELECTRICAL WARNING WARNING Before removing any battery cables or To prevent wiring damage, it is essential battery, make sure all 12-volt equipment when replacing the cables on the battery, in the motor home is off and the power or when using a “booster”...
Page 81: Plumbing
SECTION 7 – PLUMBING FRESH WATER SYSTEM The fresh water system provides water to the galley sink, shower, bathroom lavatory, toilet, and water heater. Water may be supplied by either of two sources: • a fresh water tank and water pump located within the motor home;...
Page 82: Utility Light
SECTION 7 – PLUMBING 2. Turn Fresh Water Valve to Normal position Water pressure regulators are commonly and turn the water pump switches OFF. available at most RV dealerships and many large retail discount or home supply centers. UTILITY LIGHT A light is located up on the left sidewall to illuminate the utility hook-up area when needed.
Page 83: Full-Coach Water Filtration System
SECTION 7 – PLUMBING NOTE: We recommend that you check and clean slow leak in a faucet could drain the water tank, the strainer after each tankful of water fill the holding tank, and discharge the house during the first few uses of the water batteries.
Page 84 SECTION 7 – PLUMBING clear, odorless and taste-free clean water for drinking, cooking, and personal care. Full-Coach Water Filter System (Located in water service center) -Typical View Replacing the Full-Coach Water Filtration Cartridge Replace the filter cartridge after 1,000 gallons •...
Page 85: Disinfecting Your Fresh Water System
SECTION 7 – PLUMBING • Turn the Fresh Water Valve to Normal concentration of approximately 50 ppm in the position, next open a faucet inside the coach or water system. (If a 100 ppm concentration is the exterior shower, then turn city water on desired as discussed in step 6, use 3 cups of SLOWLY to allow the canister to fill with household bleach).
Page 86: Shower Hose Vacuum Breaker
SECTION 7 – PLUMBING 2. Remove the full-coach filter cartridge from SHOWER HOSE VACUUM the filter canister to avoid prematurely BREAKER “plugging up” the filter cartridge. Refit empty canister to filter head for procedure. After using the shower, you may notice water 3.
Page 87: Waste Water System
SECTION 7 – PLUMBING See Specifications in Section 1–Introduction for tank capacities for your model. Dumping Holding Tanks 1. Remove drain hose from water service center. 2. Remove dust cap from drain and connect sewer hose. Be sure it is firmly attached. Important “Don’ts”...
Page 88: Waterline And Tank Drain Valves
SECTION 7 – PLUMBING 5. Open the gray water valve (gray handle). Be 5. Disconnect hose from flushing system and sure there are no sags in the hose to ensure close dump valves. complete drainage. Close gray water valve as Using On-Site Sewer Hook-Ups soon as tank is empty.
Page 89: Water Heater Bypass Valve
SECTION 7 – PLUMBING Turn the Fresh Water Valve to TANK FILL WATER HEATER BYPASS position, then remove the caps from the ends of VALVE the drain hoses and turn the valves to drain waterlines. Your coach may be equipped with a water See the Water System Drain Valve Locations heater bypass valve for easier winterization of chart at the end of this section for locations on...
Page 90 SECTION 7 – PLUMBING 3. Drain Exterior Shower/Wash Station. 5. Remove Full-Coach Water Filter (if Open exterior shower knobs and lay shower equipped). Remove the filter canister from head on ground as shown to drain any water the full-coach water filtration system in the left in the shower line.
Page 91 A blow-out plug can be purchased the coach during storage. ® ® at any Winnebago or Itasca dealer. NOTE: It is not necessary to add antifreeze to the toilet since the flush valve will be closed.
Page 92 SECTION 7 – PLUMBING 21. Close dump valves and refit the dust cap onto the drain outlet. WARNING This will inhibit rust formation on valve shafts and prevent entry and contamination by airborne debris, insects, and rodents. Never use automotive antifreeze/coolant Your drainage and fresh water systems are now in your RV water system.
Page 93 SECTION 7 – PLUMBING coach water filtration system, proceed to the next numbered step.) After removing filter, remount the empty canister onto the filter assembly and continue the antifreeze fill procedure. Set Up Winterization Valves 3. Turn Winterization Valve 1 to “Water Heater Bypass”...
Page 94: Winterizing Optional Appliances
SECTION 7 – PLUMBING 15. Pour about one cup of RV antifreeze down each drain for the galley sink, lavatory sink, and shower/tub. This fills the drain trap pipes to prevent holding tank odors from entering the coach during storage. Dump and Clean Holding Tanks 16.
Page 95 SECTION 7 – PLUMBING 2. Close door. Advance Cycle Selector to SPIN. 3. Press ON/OFF button, then press START. Let the Washer/Dryer run for 1 to 2 minutes. 4. Press ON/OFF button to turn power OFF. 5. Unplug Washer/Dryer from electrical outlet (or disconnect power).
Page 96: Water System Drain Valve Locations
SECTION 7 – PLUMBING 7. After letting antifreeze drain completely from 2. Plug Washer/Dryer into electrical outlet or drum, press the ON/OFF button to turn power reconnect power supply. OFF. Finished. 3. With Washer/Dryer power OFF, pour 1/2 TBSP. of powder detergent (or liquid To use Washer/Dryer again after seasonal equivalent) into “Compartment 2”...
Page 97: Entertainment
SECTION 8 – ENTERTAINMENT • On TV remote control, press INPUT or HIGH DEFINITION VIDEO SOURCE button and select either SELECTION SYSTEM COMPOSITE (for standard definition) or COMPONENT (for high definition). -If Equipped The TV will display the DVD logo when the correct input is selected.
Page 98: Front Tv/Buffet Tv Ignition Switch Interlock
SECTION 8 – ENTERTAINMENT AUDIO-VIDEO SYSTEM BASIC OPERATION NOTE: For your convenience, we have also included a handy, tear-out version of this “A/V System Basic Operation” guide in Section 8 of your Operator’s Manual Supplement. See your InfoCase for specific operating guides for audio and video components.
Page 99: Cd/Dvd Player - Bedroom
SECTION 8 – ENTERTAINMENT Play DVD with Theater Sound NOTE: Turn the volume level up significantly on the DVD player when using the home • Insert DVD into player. DVD will begin to theater as an amp for the TV through the load automatically.
Page 100: Cd/Dvd Player
SECTION 8 – ENTERTAINMENT Play DVD The TV operates from 120-volt AC household current only, so you must have either the • Insert DVD into player. DVD will begin to shoreline connected, the generator running, or the load automatically. TV screen will typically inverter turned on (if equipped).
Page 101: Flip-Down Screen Video Players
SECTION 8 – ENTERTAINMENT Video Programming from the Video The Video Players operate independently so the occupant of one bunk may watch a DVD Selection Box while the other watches a different DVD. The -If Equipped same DVD can be watched on both players at the •...
Page 102: Tv (Dining Buffet) - Power Lift
SECTION 8 – ENTERTAINMENT • Push the open button (located on the front of • Press button on Video Player to your screen) and lower the monitor to the select. VIDEO 1 or VIDEO 2 input. desired level. You may also adjust the swivel (The component logo or other angle.
Page 103: Tv Antenna
SECTION 8 – ENTERTAINMENT 3. To lower the TV back into stored position, press the control switch DOWN. The power lift/lower mechanism will stop automatically when the TV is all the way seated into stored position. NOTE: Be sure that the buffet counter is clear before raising/lowering the TV to protect NOTE: The buffet TV is plugged into a special the TV, lift/lower mechanism, and...
Page 104: Tv Signal Amplifier
SECTION 8 – ENTERTAINMENT Rotating Antenna for Best Picture Make sure antenna is in the “UP” position. Pull down on directional handle using both hands until it disengages ceiling plate and rotate for best Push On-Off picture and sound on TV set. Lowering Antenna to Travel Position Rotate antenna until pointer on directional handle aligns with pointer on ceiling plate.
Page 105: Tv Digital Satellite System Wiring
TV manual thoroughly to understand the system (if equipped.) completely before attempting any setups or ® See your authorized Winnebago Industries adjustments. dealer for proper installation and sealing of roof • The coach must be parked and level before mounted components.
Page 106: Tv Digital Satellite Dish - In-Motion
SECTION 8 – ENTERTAINMENT • Press the SAT switch on the HD Video Selection System to view the satellite signal. See HD Video Selection System for additional information. • Satellite seeking time can be reduced by setting the region code for your current location.
Page 107 SECTION 8 – ENTERTAINMENT Further Information Please read the manufacturer’s user guide in your InfoCase for complete operating instructions. 8-11...
Page 109: Furniture And Softgoods
SECTION 9 – FURNITURE AND SOFTGOODS LOUNGE CHAIR BASE CLAMP TABLE AND CHAIRS –If Equipped While the vehicle is in motion, the base of the lounge chair must be fastened into position with Dinette Chairs a clamp on the floor as shown. The dinette chairs are free-standing to allow greater freedom of movement than typical booth style dinettes or pedestal seats.
Page 110 SECTION 9 – FURNITURE AND SOFTGOODS Buffet Chairs 2. Hook the strap to the brackets (located on each 1. Push Buffet Table chairs against opposite side of the lounge cabinet) for security. sides of table. 2. Bind Chairs together with the provided strap in the circular pattern shown above, ensuring the strap goes through the ring located in the bottom side of the table.
Page 111: Sleeping Facilities
SECTION 9 – FURNITURE AND SOFTGOODS 2. Lift the dinette cushions upward and push table straight down. WARNING Be sure all free-standing chairs and furniture items, and all other loose items are secured or stored properly while the vehicle is in motion. Possible overlooked items such as canned goods or small appliances on the countertop, cooking pans on the range can also become...
Page 112: Sofa/Bed Conversion
SECTION 9 – FURNITURE AND SOFTGOODS NOTICE Do not recline the lounge completely flat unless the footrest section is extended. To Recline 1. Press the switch on the front of the armrest. Press “down” to recline; “up” to return upright. Reverse steps to convert back into dinette NOTE: Be sure house batteries contain adequate seating.
Page 113 SECTION 9 – FURNITURE AND SOFTGOODS To Convert to Bed 1. Extend footrest section and push together with lounge seat cushion, 2. then press recline button until entire lounge lies flat. 3. Reverse steps to return to lounge seating. Pull Strap 3.
Page 114: Theater Seating/Bed Conversion
SECTION 9 – FURNITURE AND SOFTGOODS To Extend Pull-Out Footrest THEATER SEATING/BED Section CONVERSION 1. Squeeze latch behind opening at top of lounge –If Equipped face panel and pull footrest trundle section out until it locks in the fully extended position. NOTICE 2.
Page 115: Sleep Number® Bed
SECTION 9 – FURNITURE AND SOFTGOODS NOTICE Do not recline the lounge completely flat unless the footrest trundle section is extended. Do not occupy the lounge when elevating the seat back from the flat bed position to upright lounge position. If house battery voltage is low, the mechanism may require assistance by lifting the seat back while returning...
Page 116: Bed - Power Lift
SECTION 9 – FURNITURE AND SOFTGOODS NOTE: The Sleep Number bed operates on 120- volt AC household current only, so you WARNING must have the shoreline plugged in or the generator running to adjust the air pressure settings in this bed. Keep people away from operating mechanism and pinch hazard areas Further Information...
Page 117: Day/Night Pleated Blinds
SECTION 9 – FURNITURE AND SOFTGOODS 5. Reverse steps to turn wardrobe back into bunk beds. DAY/NIGHT PLEATED BLINDS –If Equipped Your coach may feature two-stage pleated window blinds that can be used for light filtering, daytime room darkening, or nighttime privacy. They are raised or lowered by grasping the bottom edge of the desired blind section and Wall Bracket...
Page 118: Wood Furniture And Cabinetry
CABINETRY –If Equipped People are drawn to the natural beauty of ® wood. At Winnebago Industries , our craftsmen work with the art found in each piece of wood to create cabinets of superior quality, backed by the Winnebago Industries warranty.
Page 119 SECTION 9 – FURNITURE AND SOFTGOODS light. Color differences or changes in wood can also be caused by exposure to harsh chemicals, extreme heat, or other contributing external conditions. Any color change that occurs in both the finish and the wood is considered part of the natural aging process and is not to be considered defect or damage.
Page 121: Slideout Rooms And Leveling
SECTION 10 – SLIDEOUT ROOMS AND LEVELING To Release SLIDEOUT ROOM TRAVEL • Press and Hold the UNLOCK side of the LOCKS - ELECTRIC Slideout Room Lock switch for about 7 –If Equipped seconds. (You may be able to hear the lock motor sound stop).
Page 122: Slideout Room Keylock
SECTION 10 – SLIDEOUT ROOMS AND LEVELING SLIDEOUT ROOM OPERATION – ELECTRIC WARNING Your motor home may have more than one slideout room. Understand which switch operates which slideout room prior to operation. Make sure all slideout rooms are clear of people who could be harmed or obstacles that could cause damage Slideout Lock Drain Line prior to operating any slideout rooms.
Page 123 SECTION 10 – SLIDEOUT ROOMS AND LEVELING Extend Procedure: SLIDEOUT ROOMS so the engine alternator can provide maximum power See “Before Extending!” before proceeding. for proper operation of the slideout • Start the engine so the alternator can provide mechanisms. maximum power for proper operation of slideout mechanisms.
Page 124: Slideout Room - Extreme Weather Precaution
SECTION 10 – SLIDEOUT ROOMS AND LEVELING If it has rained recently before you retract the slideout room cover-awning (if equipped) or slideout room, we recommend using the reduce effectiveness of the slideout room weather hydraulic leveling system (if equipped) to lean seals.
Page 125 SECTION 10 – SLIDEOUT ROOMS AND LEVELING Problems Retracting the Room Before operating the room after an error has been detected, check for obvious faults such as • Set the Park Brake if the Engage Park Brake obstructions prior to trying to operate the room light flashes while pressing the Retract (IN) again.
Page 126: Slideout Emergency Retraction - Electric
SECTION 10 – SLIDEOUT ROOMS AND LEVELING Further Information In the event of a total system failure where Manual Mode cannot be used, two crank handles See the slideout room operating guide may be used to retract or extend the room. See included in your InfoCase for further instructions Slideout Emergency Retraction - Electric and troubleshooting information.
Page 127: Slideout Emergency Retraction - Bedroom
SECTION 10 – SLIDEOUT ROOMS AND LEVELING Further Information 1) Lift tab inside See the Slideout Room operating guide protrusion on boot to included in your InfoCase for further instructions disengage motor brake and troubleshooting information. SLIDEOUT EMERGENCY RETRACTION - BEDROOM -If Equipped If the slideout mechanism is malfunctioning and the room will not retract using the interior...
Page 128: General Slideout Care
SECTION 10 – SLIDEOUT ROOMS AND LEVELING GENERAL SLIDEOUT CARE 1) Lift tab inside protrusion on boot to • Wipe outer seals occasionally with talc or 303 disengage motor brake brand protectant for smooth quiet operation. • Clean the floors inside before retracting the room to avoid vinyl flooring scratches or carpet pile snags.
Page 129: Leveling System
SECTION 10 – SLIDEOUT ROOMS AND LEVELING LEVELING SYSTEM –If Equipped The hydraulic leveling system makes selecting a parking site easier and faster by reducing the effect of uneven ground. Hydraulic jacks raise the affected low corners of the coach to make leveling “set up” faster and easier for you.
Page 130 (Located on dash) brake in order to retract the jacks, it is -Typical View recommended that you take your RV into an ® authorized Winnebago Industries dealership for a complete leveling system inspection before using again. In The Event Of Accidental Jack Extension 1.
Page 131: Checking Hydraulic Oil Level
SECTION 10 – SLIDEOUT ROOMS AND LEVELING 4. See the Leveling System Operator’s Manual supplied in your InfoCase for troubleshooting instructions or operating the leveling system if jacks fail to retract or any other functions fail. CHECKING HYDRAULIC OIL LEVEL See the Leveling System Operator’s Manual in your InfoCase for complete maintenance instructions and information.
Page 133: Maintenance And Storage
• Have the sealant replaced if you notice any of attention. Delaying these repairs may allow water the above. Your local Winnebago Industries leakage and result in damage to interior ceiling dealer has the correct and necessary parts and and body panels, upholstery, etc., which is not experience to help you maintain your sealants.
Page 134: Exterior Automotive Paint Finish
SECTION 11 – MAINTENANCE AND STORAGE weight to the vehicle. This, in effect, reduces the initial 60-day cure stage, a coat of wax or amount of cargo you can carry and remain within polish can help protect the surface from these GVWR and GAWR limits.
Page 135 SECTION 11 – MAINTENANCE AND STORAGE Bug Removal to clean heavy road films on semi trailers and are often dirty. They are not • Rinse the loose debris off with water and designed for custom painted RV’s and allow the remaining residues to soak and they will scratch the clearcoat finish.
Page 136: Care Of Appliques And Decals
SECTION 11 – MAINTENANCE AND STORAGE is subjected to various twisting and flexing forces • Fuel or antifreeze spilled on appliques or caused by routine cornering and turning, and by decals should be rinsed off immediately with uneven road surfaces, such as bumps, potholes, water.
Page 137: Exterior Lights
SECTION 11 – MAINTENANCE AND STORAGE EXTERIOR LIGHTS ® Most Winnebago Industries vehicles have NOTICE polycarbonate lenses on exterior lamps, which are very sensitive to a variety of chemical Do not use citrus-based cleaners on solvents and cleaners. polycarbonate finishes. Citric compounds...
Page 138: Cabinetry - Cleaning
SECTION 11 – MAINTENANCE AND STORAGE shades should be closed when the motor home is parked for an extended period of UltraLeather Cleaning Chart time. Detergent/ Cleaner/ Type of Stain Water Degreaser Coffee, Tea WARNING Red Wine, Liquor Cola, Soft Drinks Milk When cleaning upholstery and fabric, do not use lacquer thinner, nail polish...
Page 139: Solid Surface Countertop - Corian
SECTION 11 – MAINTENANCE AND STORAGE NOTE: Many cabinetry and furniture items surface using the same cleaning material and throughout this motor home are scrubbing method to maintain a uniform constructed either partially or appearance. completely of real hardwoods. Because If you prefer a glossier look, follow up with of natural variations in woodgrain a good quality furniture polish or a liquid...
Page 140: Range And Refrigerator
SECTION 11 – MAINTENANCE AND STORAGE Lavatory Sink - ABS Plastic • For stubborn stains, use a mild abrasive ® ® cleanser like Soft Scrub , Comet , etc. Work General Cleaning. Clean often with hot water in the direction of the “grain” of the brushed and soap.
Page 141: Vehicle Storage - Removal
SECTION 11 – MAINTENANCE AND STORAGE Clean and Prep Coach for Storage 9. Inspect all seams and seals around doors, windows, vents, and any other joints. Replace 1. Turn off the propane gas tank. or repair any that are damaged. Sealing 2.
Page 142: Chassis Service And Maintenance
SECTION 11 – MAINTENANCE AND STORAGE NOTE: Always purge a new filter with clean 5. Let the ice maker cycle and dump the first running water before using. See filter batch of ice. manufacturer’s directions included with the filter cartridge. CHASSIS SERVICE AND MAINTENANCE 10.
Page 143: Chassis Diagnostic Connectors
SECTION 11 – MAINTENANCE AND STORAGE Fuse Diagram (inside of cover) Diagnostic Plug (Located on steering column support See the chassis manufacturer’s fuse allocation beneath left side of dash) chart on the inside of the fuse block cover. -Typical View Towing Fuses The fuses for the chassis supplied towing package are located inside the driver side rear...
Page 144: Coach Maintenance Chart
SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Propane Gas System Have propane gas system checked for leaks Pressure Regulator - inspect and adjust if needed Check propane tank condition, mounting, and fittings...
Page 145 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Safety Equipment Check operation of the following items: Headlights, Taillights, and Marker Lights Turn Signals...
Page 146: Miscellaneous
SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Sealants Inspect (see “Sealants”...
Page 147: Loading The Vehicle
SECTION 12 – MISCELLANEOUS NOTE: We recommend that you dump all LOADING THE VEHICLE holding tanks before traveling to avoid carrying unnecessary weight. NOTE: Your motor home’s load capacity is designated by weight, not by volume, so you cannot necessarily use all available space when loading your motor home.
Page 148 SECTION 12 – MISCELLANEOUS Corner Weighing (Side-to-Side) You will first drive only your front wheels onto the scale pad, then drive ahead so that the The most accurate method of weighing a whole vehicle is on the scale, then finally pull off motor home is to weigh each “corner”...
Page 149: Car Or Trailer Towing
SECTION 12 – MISCELLANEOUS axle is 12,000 lbs., then the load on each rear dual Because of individual vehicle use and loading set (left rear duals or right rear duals) should not habits, we recommend weighing the vehicle exceed 6,000 lbs. while fully loaded to avoid exceeding any of the listed Gross Weight Ratings.
Page 150: Trailer Wiring Connector
SECTION 12 – MISCELLANEOUS Before descending a steep or long grade when TRAILER WIRING towing a trailer, reduce speed and shift into a CONNECTOR lower gear to control vehicle speed. Avoid prolonged or frequent application of brakes Your coach is pre-wired for trailer or car which could cause overheating and brake failure.
Page 151: Entry Step - Electric
350 vehicle drive train: engine and cooling systems, lbs. All Winnebago Industries models transmission, drive line, drive axle, and others. equipped with a Class IV hitch have a...
Page 152 SECTION 12 – MISCELLANEOUS Red Activation Lever Entry Step Switch • The red Activation Lever located on the entry (Located near the entrance door) step switch must be depressed in order to put -Typical View the step switch in the ON position. The step has several automatic extend/retract Stationary Extended Mode - Step functions that are controlled by the position of a...
Page 153: Tool And Ladder Storage
SECTION 12 – MISCELLANEOUS Further Information • Never ignore warning labels or weight limits defined on your ladder. The following For additional information on the step, see the warning label is located on or near the ladder: manufacturer’s operators manual included in your InfoCase.
Page 154: Manual Awning
SECTION 12 – MISCELLANEOUS Power OFF - The Off position shuts down the MANUAL AWNING system. The awning cannot be extended or retracted in this mode. The Auto-Retract system –If Equipped is also disabled. Wind Sensor Auto-Retract Feature Further Information If the Wind Sensor is activated, the system For complete operating instructions, refer to will automatically retract the porch awning...
Page 155: Stepwell Cover
SECTION 12 – MISCELLANEOUS TO USE: Turn system power On at the control panel. CAUTION NOTE: Power On/Off and the Auto-Retract sensitivity can only be operated at the control panel. The Auto-Retract feature provides protection against adverse elements, but • Extend - Press and release.
Page 156 SECTION 12 – MISCELLANEOUS Emergency Retract Feature The step cover is equipped with an Emergency Retract function in event of an emergency exit situation and/or the step cover fails to retract while in the extended position. Do not use Emergency Retract feature unless necessary for emergency.
Page 157: Windows
SECTION 12 – MISCELLANEOUS • To close, crank the window in snugly (by turning the crank-out handle clockwise), then back off 1/4 turn to help avoid glass warping, which can result in wind noise. • Push the lever back in on the crank-out handle and lay back in the horizontal position.
Page 158: Power Roof Ventilator
SECTION 12 – MISCELLANEOUS from the roof ventilator. The fan speed POWER ROOF VENTILATOR selector allows you to control the amount of circulation you need at any time. Lounge, Galley, or Bath Area –If Equipped 5. If you want the vent dome raised without the fan running, turn the Fan Speed knob to 0-Off .
Page 159 SECTION 12 – MISCELLANEOUS Minimize moisture released inside the coach Run the range hood fan while cooking and open a bath vent while bathing or showering to carry water vapor out of the coach. Avoid making steam from boiling water excessively or letting hot water run.
Page 161 INDEX 12-Volt Front Drop-Down Solar/ Doors and Windows ........11-8 Night Shade ..........3-9 Driving Safety ..........2-1 2010 New Vehicle Limited Warranty ..1-7 DVD Home Theater System ......8-2 About this Manual ........1-1 Effects of Prolonged Occupancy ..... 12-12 Air Conditioner Filter ........
Page 162 Index Furnace-A/C Thermostat Operation Chart . 4-12 Propane Gas Furnace ........4-9 Galley Sink ..........11-7 Propane Gas Leak Detector ......2-2 General Slideout Care ........ 10-8 Propane Gas Pressure Regulator ....5-6 General Warnings ........2-1 Propane Gas Supply ........5-1 GPS Navigation System ......
Page 163 Index Sofa/Bed Conversion ........9-4 Solar Charger Panel ........4-6 Solid Surface Countertop – Corian® ..11-7 specifications and Capacities ....... 1-5 Starting and Stopping Diesel Engine ..3-17 Steering Column Adjustment ..... 3-13 Stepwell Cover ........... 12-9 Storage Compartment Doors ..... 12-7 Suspension Alignment and Tire Balance ...

Winnebago 2010 Meridian V Class Operator's Manual

1 Introduction

2 Safety and Precautions

3 Driving Your Motor Home

4 Appliances and Systems

5 Propane Gas

6 Electrical

7 Plumbing

8 Entertainment

9 Furniture and Softgoods

10 Slideout Rooms and Leveling

11 Maintenance and Storage

12 Miscellaneous

Quick Links

TABLE OF CONTENTS

Need help?

Questions and answers

Related Manuals for Winnebago 2010 Meridian V Class

Summary of Contents for Winnebago 2010 Meridian V Class

Table of Contents
