Summary of Contents for Winnebago 2014 Adventurer

  • Page 1 Rev. 1421150527 Part No. 161500-14-022 Copyright 2013 Winnebago Industries, Inc. All rights reserved.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1 – INTRODUCTION About this Manual ..........................1-1 Safety Messages Used in this Manual ....................1-1 Pre-Delivery Inspection ........................1-2 Front Axle Tire Alignment ....................... 1-2 Service and Assistance ........................1-2 Reporting Safety Defects ........................1-2 Occupant and Cargo Carrying Capacity Label ................. 1-3 Vehicle Certification Label .......................
  • Page 4 Table Of Contents Fuel Pump Shut-Off Switch ......................3-7 Tow/Haul Transmission Mode ......................3-7 Hazard Warning Flashers ........................3-8 Map Light Switch ..........................3-8 Battery Boost Switch ........................3-8 Air Conditioner/Heater – Automotive (Dash) .................. 3-9 Heater – Rear Coach (Automotive) ....................3-9 Defrost Fans ............................
  • Page 5 Table Of Contents Power Cord – External ........................6-1 Inverter Unit – 1000W ........................6-3 Inverter/Charger Unit – 2000W ......................6-4 Power Center ............................. 6-5 Circuit Breakers – House 120-Volt AC .................... 6-6 Electrical Outlets – House 120-Volt AC ..................6-6 Ground Fault Circuit Interrupter .......................
  • Page 6 Table Of Contents Lounge Chair - Swivel ........................9-1 Buffet Table and Chairs ........................9-1 Sliding Buffet Table and Chairs ....................... 9-3 Sleeping Facilities ..........................9-5 Dinette/Bed Conversion - Dream Dinette™ ..................9-5 Dinette - Extendable Table and Chairs ..................... 9-6 U-Shaped Dinette/Bed Conversion ....................
  • Page 7 Table Of Contents Chassis Service and Maintenance ....................11-12 Chassis Fuses and Relays ......................11-12 Coach Maintenance Chart ......................11-13 12 – MISCELLANEOUS Loading the Vehicle ........................12-1 Weighing Your Loaded Vehicle ..................... 12-1 Car or Trailer Towing ........................12-3 Trailer Wiring Connector ........................

  • Page 9: Introduction

    DA NG E R The instructions included in this manual are intended as a guide, and in no way extend the responsibilities of Winnebago DANGER indicates a hazardous situation Industries beyond the standard written which, if not avoided, will result in death or warranty as presented in this manual.

  • Page 10: Pre-Delivery Inspection

    Your dealer is National Highway Traffic Safety Administration responsible for performing a complete pre- (NHTSA) in addition to notifying Winnebago delivery inspection of the chassis and all Industries, Inc. motorhome components.

  • Page 11: Occupant And Cargo Carrying Capacity Label

    SECTION 1 – INTRODUCTION or go to their website at http://www.safercar.gov or write to: Administrator, NHTSA 1200 New Jersey Avenue S.E. Washington, D.C. 20590 You can also obtain other information about motor vehicle safety from the NHTSA website at http://www.safercar.gov OCCUPANT AND CARGO CARRYING CAPACITY LABEL This label is affixed in the driver’s area next to...

  • Page 12: Vehicle Certification Label

    These pressure levels must be maintained to assure proper handling, safety, 2. Chassis manufacture date. and fuel economy. 3. Month and year of manufacture at Winnebago ® 9. Rear Axle Wheel Configuration: Single or Industries Dual as it relates to the inflation.

  • Page 13: Specifications And Capacities

    80 gal. Notes: All information is based upon the most recent data available. Visit the Winnebago Industries, Inc. web page – www.winnebagoind.com – for the most current product information. The height of each model is measured to the top of the tallest standard feature and is based on the curb weight of a typically equipped unit.

  • Page 14: Owner And Vehicle Information

    Motorhome Serial Number ___________________________________________________________ Chassis Vehicle Identification No. (VIN) ________________________________________________ Vehicle Mileage at Delivery __________________________________________________________ Selling Dealer Name ________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ ® YOUR WINNEBAGO INDUSTRIES DEALER /SERVICE CENTER Name ____________________________________________________________________________ Address __________________________________________________________________________ __________________________________________________________________________ Contact ____________________________________________Phone ________________________ CHASSIS SERVICE CENTER...

  • Page 15: Safety And Precautions

    SECTION 2 – SAFETY AND PRECAUTIONS GENERAL WARNINGS DRIVING SAFETY • Only seats equipped with seat belts are to be occupied while the vehicle is moving. WARNING • Make sure all passengers have seat belts fastened. Lap belts should fit low on the hips and upper thighs.

  • Page 16: Fuel And Propane Gas

    SECTION 2 – SAFETY AND PRECAUTIONS • Do not adjust tilt steering in a moving vehicle. • Do not operate the cruise control on icy or WARNING extremely wet roads, winding roads, in heavy traffic, or in any other traffic situation where a constant speed cannot be maintained.

  • Page 17: Propane Gas Leaks

    SECTION 2 – SAFETY AND PRECAUTIONS • Open doors and other ventilating openings. • Leave the area until odor clears. DANGER • Have the propane system checked and leakage source corrected before using again. Do not use gas cooking appliances for Failure to comply could result in death or comfort heating.

  • Page 18: Carbon Monoxide Warning

    ® fuel. It will detect CO gas from any combustion Winnebago Industries dealer. source such as the furnace, gas range/oven, water Further Information heater, refrigerator, chassis engine, and electric See the manufacturer’s user guide provided in...

  • Page 19: Smoke Alarm

    RV application. We that is also listed for RV application. We recommend obtaining a replacement from your recommend obtaining a replacement from your ® ® Winnebago Industries dealer. Winnebago Industries dealer. Further Information Further Information Please read the information provided by the See the manufacturer’s information in your...

  • Page 20: Electrical

    We recommend obtaining a replacement only from your Winnebago MAINTENANCE ® Industries dealer or a reliable RV parts supplier.

  • Page 21: Power Sofas And Beds

    SECTION 2 – SAFETY AND PRECAUTIONS POWER SOFAS AND BEDS WARNING Keep people away from operating mechanism and pinch hazard areas during use. Failure to do so could cause injury. Escape Window (Lift both red safety latch handles UP SLIDEOUT ROOMS and push window OUT) -Typical View WARNING...

  • Page 22: Formaldehyde Information

    Winnebago Industries ® throughout the outdoor and indoor air. Because If Winnebago Industries determines that mold of the nature of the use of a motorhome, it is ® ® is present in the Winnebago...

  • Page 23: Roof And Ladders

    Winnebago Industries within the limited the rungs are wet, or if your shoes are wet or warranty period, Winnebago will clean the carry mud or debris that could result in a loss affected area(s) and/or replace affected items as it of footing.

  • Page 24: Jump Starting

    If you see or hear steam escaping from the ® Winnebago Industries does not assume engine compartment or have any other reason to responsibility for damage incurred while towing suspect an extreme engine overheating condition, this vehicle.
  • Page 25 SECTION 2 – SAFETY AND PRECAUTIONS NOTICE Operating a vehicle under a severe overheating condition can result in damage to the vehicle. For information on what to do in case of overheating, consult your chassis manual. 2-11...

  • Page 27: Driving Your Motorhome

    SECTION 3 – DRIVING YOUR MOTORHOME Front Seats The information in this section refers only to features installed or adapted to the dash and driver compartment area by Winnebago Lift to ® Industries . It also includes passenger seating in Recline the living area of the coach.

  • Page 28: Co-Pilot Footrest

    SECTION 3 – DRIVING YOUR MOTORHOME Armrest Adjustment -If Equipped The armrests may be swung upward out of the way for easy exit or access to the front seats. A roller on the underside of the front of the armrest also lets you adjust the resting angle for personal comfort, whether the seat is upright or reclined.

  • Page 29: Seat Belts

    SECTION 3 – DRIVING YOUR MOTORHOME Adjustment To lengthen belt, swivel the tab end at a right angle to belt and pull strap to desired length. To shorten, pull loose end of belt. To Fasten Be sure belt is not twisted. Grasp each part of the belt assembly and push tongue into buckle.

  • Page 30: Child Restraints

    SECTION 3 – DRIVING YOUR MOTORHOME The shoulder belt is designed to lock only 1. Look for the label certifying that it meets all during a sudden stop, sudden body movement or applicable safety standards. a collision. At all other times it will move freely 2.

  • Page 31: Keyone Lock System

    The key number for your coach is registered in our factory database, so if you ever lose your ® keys, any Winnebago Industries dealership can order a new key for you. Mirror Heat Switch (Located on driver side trim panel) MIRRORS –...

  • Page 32: Front Drop-Down Solar/Night Shade (12-Volt)

    SECTION 3 – DRIVING YOUR MOTORHOME FRONT DROP-DOWN SOLAR/ NIGHT SHADE (12-VOLT) Your coach is equipped with a 12V Front Drop-Down Solar/Night Shade that provides privacy and solar heat protection as well as a sunvisor feature. The power switches for the 12V Front Drop- Down Solar/Night Shade are located on the dash or driver side trim panel, depending on model.

  • Page 33: Brake-Shift Interlock

    Should the Automatic Safety Retraction pump in the event of collision. This switch must feature deploy, go to your nearest Winnebago be manually reset to resume the fuel supply to the ®...

  • Page 34: Hazard Warning Flashers

    SECTION 3 – DRIVING YOUR MOTORHOME Further Information See the chassis manual in your InfoCase for further operating instructions and cautions. HAZARD WARNING FLASHERS The hazard warning flashers provide additional safety when the vehicle must be stopped on the side of the roadway and presents a possible hazard to other motorists.

  • Page 35: Air Conditioner/Heater - Automotive (Dash)

    SECTION 3 – DRIVING YOUR MOTORHOME Further Information See the manufacturer’s user guide provided in your InfoCase for complete operating instructions. HEATER – REAR COACH (AUTOMOTIVE) –If Equipped To provide auxiliary automotive system heat to the rear of the vehicle while driving, turn the rear heater fan switch to the desired speed.

  • Page 36: Radio In-Dash/Rearview Monitor System

    SECTION 3 – DRIVING YOUR MOTORHOME Defrost Fan Switch (Located on dash) -Typical View Basic Operating Instructions • 1 - RESET - Press to reset the microprocessor. RADIO IN-DASH/REARVIEW MONITOR SYSTEM • 3 - +/- (Volume) - Press to set the volume. •...

  • Page 37: Infotainment Center/Gps

    SECTION 3 – DRIVING YOUR MOTORHOME See the manufacturer’s information in your InfoCase for operating instructions. Bluetooth -If Equipped Your coach may be equipped with a Bluetooth microphone cable for hands-free cell phone usage. The microphone cable is located on the dash beverage tray.

  • Page 38: Radio Power Switch

    SECTION 3 – DRIVING YOUR MOTORHOME NOTE: Ensure the Input Button on the GPS • Menu Display Panel is set to VIDEO 1 and the • Eject • CD/DVD • Navigation “Aux Zone” on the radio is set to NAV. card slot •...

  • Page 39: Cb Radio Power Wiring

    SECTION 3 – DRIVING YOUR MOTORHOME powered by house batteries. If the House/ FRONT SERVICE ACCESS Coach Battery Disconnect switch is OFF, the speakers will not emit sound. (HOOD) The Hood Panel can be opened for access to service items such as the engine oil dipstick, oil fill, radiator fill, power steering reservoir, and windshield washer fluid reservoir.

  • Page 40: Engine Access - Interior

    SECTION 3 – DRIVING YOUR MOTORHOME • Press top edge of Hood Panel in firmly with palms of hands to ensure proper latching. ENGINE ACCESS – INTERIOR Front Engine Cover (Located between cab seats) NOTE: Take precautions to protect carpet and interior furnishings when removing engine cover.

  • Page 41: Engine Cooling System

    SECTION 3 – DRIVING YOUR MOTORHOME • Reinstall the screws at the lower front corners on each side of the engine cover (if equipped). ENGINE COOLING SYSTEM Do not remove the radiator cap while engine and radiator are still hot. Always check coolant level visually at the see-through coolant reservoir.

  • Page 42: Lights

    SECTION 3 – DRIVING YOUR MOTORHOME Any excessive or abnormal tire wear may CIRCUIT BREAKERS AND indicate worn or misaligned suspension or FUSES – CHASSIS/DASH steering, unbalanced tire, or other tire/suspension AUTOMOTIVE 12-VOLT problem. Alignment can be affected by worn steering/ The 12-Volt Automotive Fuses and Circuit suspension parts or by incidents which happen Breakers are conveniently located beneath the...

  • Page 43: Appliances And Systems

    SECTION 4 – APPLIANCES AND SYSTEMS The appliances installed in your motorhome are manufactured by reputable RV appliance makers and have been tested by independent laboratories to meet all applicable standards and codes set for RV appliances. See Section 2 - Safety and Precautions of this manual for any safety and precautions you need to take regarding the operation of your appliances.

  • Page 44: Ice Maker

    SECTION 4 – APPLIANCES AND SYSTEMS ICE MAKER –If Equipped Some refrigerators are equipped with an automatic ice maker system. The ice maker unit is installed in the freezer compartment of the refrigerator. NOTE: A water shut-off valve for the ice maker -Typical View is located near the water faucet filter inside the galley cabinet beneath the...
  • Page 45 SECTION 4 – APPLIANCES AND SYSTEMS drain quickly if the refrigerator is powered from NOTE: Allow 24 hours for your refrigerator to the inverter when the engine is not running. Other cool completely before storing food. 120 volt appliances and other 120 volt devices Ice Maker are not intended to operate with inverter power •...

  • Page 46: Refrigerator Service Access Compartment

    SECTION 4 – APPLIANCES AND SYSTEMS Further Information See the manufacturer’s user guide provided in your InfoCase for further key features as well as operating, safety, maintenance, and troubleshooting information. REFRIGERATOR SERVICE ACCESS COMPARTMENT (Exterior) Refrigerator Access Compartment The exterior refrigerator service compartment -Typical View allows access to the rear of the refrigerator for inspection, maintenance, and service.

  • Page 47: Avoiding Asphyxiation

    SECTION 4 – APPLIANCES AND SYSTEMS Unlike homes, the amount of oxygen supply is limited due to the size of the recreational vehicle, and proper ventilation when using the cooking appliances avoids dangers of asphyxiation. It is especially important that cooking appliances not be used for comfort heating, as the danger of asphyxiation is greater when the appliance is used for long periods of time.

  • Page 48: Oneplace® Systems Monitor Panel

    SECTION 4 – APPLIANCES AND SYSTEMS Gen Start Gen Stop Hourmeter Microwave Oven/Range Hood (Brand, model, and appearance Typical - Your coach may or may not be shown may vary from your model) equipped with all of the features shown. -Typical View Water And Holding Tank Levels Further Information...

  • Page 49: Water Pump Switch

    SECTION 4 – APPLIANCES AND SYSTEMS • An interior light should be turned on to provide a small load which draws off the battery surface charge. Water Heater Switches Sensors See Water Heater information elsewhere in this section for operating instructions. Water Tank -Typical View Tank Capacities...

  • Page 50: Power Control System (Pcs)

    SECTION 4 – APPLIANCES AND SYSTEMS POWER CONTROL SYSTEM (PCS) –If Equipped The Power Control System (PCS) monitors the electrical usage of the appliances and equipment in the coach and allows you to use certain high energy appliances, such as the microwave or washer/dryer, without overloading the shoreline circuit breaker to help prevent nuisance tripping.

  • Page 51: Motoraid Water Heater

    SECTION 4 – APPLIANCES AND SYSTEMS See the Water Heater manufacturer’s operation manual provided in your InfoCase for complete operating instructions, safety warnings, and maintenance information before operating the Water Heater. Be sure the Water Heater is filled with water before starting either electric or propane gas operation.

  • Page 52: Pressure-Temperature Relief Valve

    SECTION 4 – APPLIANCES AND SYSTEMS CAUTION NOTICE Any leak in the heat exchanger or its Hot water can escape from tank causing supply or return lines could cause loss of injury. Operate this valve only when the coolant and subsequent engine failure. tank water is cold.

  • Page 53: Electronic Thermostat

    SECTION 4 – APPLIANCES AND SYSTEMS 4. Press the Mode Button and toggle between ELECTRONIC THERMOSTAT settings to select either “Gas Heat” (for Propane Furnace) or “Heat Elec” (for Heat (Heating and Cooling) Pump). The Electronic Thermostat (located near the 5.
  • Page 54 SECTION 4 – APPLIANCES AND SYSTEMS A Heat Pump can be thought of as an air NOTE: The temperature setpoint cannot be conditioner running in reverse. An air adjusted in the following situations: conditioner absorbs heat from the air on the When the Thermostat system is set to inside of the coach and moves it to the outside.

  • Page 55: Air Conditioner Filters

    “heat pump” mode. remove air vent) -Typical View ® See your Winnebago Industries dealer for service and proper cleaning of the drain lines. It is recommended to use mild soap and warm water to clean the air filters. When finished, allow filters to air dry.
  • Page 56 SECTION 4 – APPLIANCES AND SYSTEMS Model 35P Before using the Stackable Washer/Dryer, please spend a few moments reading the manufacturer’s user guide provided in your InfoCase for complete operating instructions, troubleshooting and maintenance tips, as well as safety precautions. CAUTION Open a window or vent while operating dryer.

  • Page 57: Washer/Dryer - Prep Package

    APPLIANCES AND SYSTEMS Model 38Q We recommend obtaining parts and service for the Washer/Dryer installation from your ® ® Winnebago or Itasca dealer. Water Supply Faucets (Located below access panel in wardrobe) * Model 38Q shown See “Winterizing Optional Appliances” in Plumbing - Section 7 for steps in winterizing your Stackable Washer/Dryer.

  • Page 59: Propane Gas

    SECTION 5 – PROPANE GAS PROPANE GAS SUPPLY Tank Gauge & Tank Fill Overflow Sender The propane gas system supplies fuel for the Valve Valve gas range/oven, water heater, furnace, and refrigerator (while in gas mode). When used and handled properly, this system is safe and economical and provides modern living conveniences wherever you travel.

  • Page 60: Propane Accessory Connection

    SECTION 5 – PROPANE GAS to the National Propane Gas Association, propane gas outlets in the United States do not WARNING offer any other type of liquefied petroleum gas than propane to the general public.) Check local phone directory yellow pages for locations of Do not fill propane container(s) to more local propane gas refilling stations or bulk than 80 percent of capacity.

  • Page 61: Safe Use Of The Propane Gas System

    SECTION 5 – PROPANE GAS “clockwise” to turn gas supply OFF. Rotate the shut-off valve “counter-clockwise” to turn gas CAUTION supply ON. See Section 2 - Safety and Precautions in this manual for other safety and precautions you need Turn valve off when not in use. to be aware of related to propane.

  • Page 62: Propane Gas Warnings And Precautions

    SECTION 5 – PROPANE GAS • Have the entire propane gas system inspected for possible leaks and missing or damaged DA NG E R parts at each tank filling. Also inspect before and after each trip, and any time trouble is suspected.

  • Page 63: Propane Gas Pressure Regulator

    SECTION 5 – PROPANE GAS • Never use an open flame to test for propane gas leaks. Replace all protective covers and caps on propane system after filling. Make sure valve is closed and door latched securely. • Portable fuel-burning equipment, including wood and charcoal grills and stoves, shall not be used inside the recreational vehicle.

  • Page 64: Propane Vaporization In Cold Weather

    SECTION 5 – PROPANE GAS tank control valve closed when not in use, even when tank is empty, to prevent moisture from collecting on the inside. If regulator freeze-up should occur, you may attempt to thaw the regulator using a light bulb. DO NOT USE AN OPEN FLAME OR HEAT LAMP.

  • Page 65: Electrical

    SECTION 6 – ELECTRICAL Your coach is equipped with an electrical the power converter automatically changes a system consisting of two separate voltages: portion of the 120-volt current to 12-volt DC current. All equipment in the motorhome that is • 12-volt DC system (battery current);...

  • Page 66: Connecting The Power Cord

    SECTION 6 – ELECTRICAL be used is designed to mate with the prongs of the power cord plug, the electrical connection can be WARNING expected to carry rated load. Connecting The Power Cord This connection is for 208Y/120-Volt or To connect to an external source, remove the 120/240 Volt AC, 3-pole, 4 wire, 60 Hz cord from the utility compartment and plug it into 50 Ampere supply.

  • Page 67: Inverter Unit - 1000W

    SECTION 6 – ELECTRICAL Inverter Unit (Located inside utility compartment) -Typical View WARNING NOTICE Service inlet access must be closed when utility connections are not in use. Do not store items too closely around the Park Fuses or Breakers inverter unit in the storage compartment. The inverter generates heat while Most campgrounds are equipped with a fuse operating and needs unrestricted airflow...

  • Page 68: Inverter/Charger Unit - 2000W

    SECTION 6 – ELECTRICAL The inverter/charger unit is located in the utility compartment or mid-passenger side compartment, depending on model. Inverter Control Panel (Located near monitor panel) -Typical View When the inverter is not being used, it should be shut off at the control panel. The inverter could drain the house batteries if the shoreline is not connected to external power and the House/ Coach Battery Disconnect switch is on.

  • Page 69: Power Center

    SECTION 6 – ELECTRICAL See the inverter/charger information included in house batteries through the inverter your InfoCase for more information on this when the shoreline is unplugged unless feature. the inverter is turned OFF. If the batteries do not charge as described Further Information above, it is possible the batteries are defective.

  • Page 70: Circuit Breakers - House 120-Volt Ac

    SECTION 6 – ELECTRICAL rate. The rate of charge will decrease as the NOTE: Breakers are labeled on panel. batteries reach “full charge”, then will continue Arrangement may vary according to “trickle” charging at a very low amperage rate. If appliance and equipment options.

  • Page 71: Automatic Power Transfer Switch

    SECTION 6 – ELECTRICAL • Push to Reset circuit after WARNING monthly testing or ground fault tripping. Do not plug the power cord into the generator receptacle while the generator is running. Electrical shock can cause personal injury. • Push to Test at Automatic Power Transfer Switch least monthly.

  • Page 72: Generator Operation

    SECTION 6 – ELECTRICAL See the AGS user guide for more information to help understand the AGS feature and its AGS Control Pad operation with your Generator. (Located near monitor panel) Generator Operation Generator Operation (Not available on coaches equipped with (if equipped with AGS) AGS) To Start the Generator...

  • Page 73: Operation Warnings And Cautions

    SECTION 6 – ELECTRICAL Generator Hourmeter • Park the vehicle so that the wind will carry the exhaust away from the vehicle. Also, note the The Generator hourmeter registers the total position of other vehicles to be sure their number of hours that the Generator has been exhaust will not enter your vehicle.

  • Page 74: House/Coach Battery Disconnect Switch

    SECTION 6 – ELECTRICAL the Battery drops to approximately 80% charge, See also “Battery Care” elsewhere in this and the other is being charged. If the batteries are section. not being charged, BIM isolates the two batteries to prevent an electrical draw in one system from depleting the other battery.

  • Page 75: Battery Care

    SECTION 6 – ELECTRICAL CAUTION Battery compartment must be closed and latched. Failure can cause injury. BATTERY CARE Lead-acid type batteries are electro-chemical House Chassis Batteries Battery devices for storing and releasing electrical charge. As such, they are simply an electrical -Typical View reservoir, not an electrical source.
  • Page 76 SECTION 6 – ELECTRICAL • Neutralize corrosion buildup or acid film on top of battery by washing with a baking soda/ NOTICE water solution. Rinse with clear water. NOTE: Make sure vent caps are on securely to prevent baking soda solution from Disconnect batteries before connecting external charging equipment to avoid entering the battery and contaminating...

  • Page 77: Circuit Breakers - House 12-Volt

    If your coach is going to be unoccupied for Battery Charge Meter ® two weeks or more, Winnebago Industries See related item under “Systems Monitor recommends disconnecting the chassis batteries Panel” in Section 4 - Appliances and Systems.
  • Page 78 SECTION 6 – ELECTRICAL Automotive Chassis and House 12-Volt Circuit Breaker Panel (Located inside passenger compartment) -Typical View 6-14...

  • Page 79: Plumbing

    SECTION 7 – PLUMBING FRESH WATER SYSTEM The Fresh Water System provides water to the galley sink, shower, bathroom lavatory, toilet, and water heater. Water may be supplied by either of two sources: • A fresh water tank and water pump located within the motorhome, or •...
  • Page 80 SECTION 7 – PLUMBING Fresh Water Valve Fresh Water Valve (Located in water service center) (Located in water service center) -Typical View -Typical View 4. Turn city water supply ON. Using City Water 5. Use the level display on the monitor panel to When connected to an outside source of water, oversee filling of the tank, or when the tank is the water bypasses the water pump and storage...

  • Page 81: Utility Light

    SECTION 7 – PLUMBING Using Tank Water (Gravity Fill) NOTE: Ensure the Fresh Water valve is in NORMAL position to use the water • Turn Water Pump switch ON. While the pump. If the valve is in Tank Fill position, switch is on, the water pump will the pump will run continuously without automatically supply tank water as needed.
  • Page 82 SECTION 7 – PLUMBING NOTE: We recommend that you check and clean We recommend that you turn the Water Pump the strainer after each tankful of water switch off whenever you will be away from the during the first few uses of the Water vehicle or not using the water system.

  • Page 83: Filtered Water Faucet

    SECTION 7 – PLUMBING Water Pump (Located in compartment behind rear passenger side tire) * Model 37F shown -Typical Installation Water Filter Assembly (Located below galley sink) FILTERED WATER FAUCET -Typical View Replacing the Water Filter –If Equipped Cartridge The Filtered Water Faucet is connected to a flow-through, activated carbon filter cartridge Replace the filter cartridge when water flow that removes chlorine and odors for taste-free...

  • Page 84: Cold Water Filter

    SECTION 7 – PLUMBING • Purge a new filter cartridge before using for drinking. Run a few gallons of water through the filter and discard the water to avoid ingesting carbon dust or particles that may have been present in the new filter cartridge. •...

  • Page 85: Ice Maker Water Filter

    SECTION 7 – PLUMBING • Before using the water for drinking, run a few gallons of water through the filter and discard water to avoid consuming carbon dust or particles that may have been present in the new filter cartridge. Diverter Plug •...

  • Page 86: Disinfecting Your Fresh Water System

    SECTION 7 – PLUMBING • Insert a new filter cartridge up into the filter socket as far as possible and twist it clockwise (to the right) one-quarter turn until it stops. WARNING • Discard the first two batches of ice cubes to avoid consuming carbon dust or particles that Chlorine is poisonous.

  • Page 87: Exterior Shower/Wash Station

    SECTION 7 – PLUMBING Important “Don’ts” If items are placed into the shower tub before shower valve vacuum release is complete, they • Don't use facial tissue or regular toilet tissue in may become wet. the RV toilet. These will not disintegrate sufficiently and will often cling to the sides of EXTERIOR SHOWER/WASH the holding tank.

  • Page 88: Drainage System (P-Traps)

    SECTION 7 – PLUMBING Water Saver Flush Button Washer/Dryer • Press and release to flush liquids and small amounts -If Equipped of toilet paper. In addition to pouring water down sink and Normal Flush Button shower drains, also run a wash cycle to ensure there is an adequate amount of water in the •...
  • Page 89 SECTION 7 – PLUMBING NOTE: We recommend that you dump all Drain Outlet holding tanks before traveling to avoid carrying unnecessary weight. Flushing your Black Water Holding Tank The black water holding tank is equipped with an internal spray head that allows you to rinse the inside of the tank with a shower of clean water after dumping.

  • Page 90: Holding Tank Level Indicators

    SECTION 7 – PLUMBING NOTE: The drain outlet swivels downward for better hose alignment and drainage. D R A I N D R A I N C L O S E C L O S E WARNING L I N E - E N D V A L V E I N - L I N E V A L V E...

  • Page 91: Water Heater Bypass Valve

    SECTION 7 – PLUMBING Leave bypass valve handle in NORMAL FLOW position if draining water and blowing Water Tank Drain Valve out waterlines. Place in BYPASS position ONLY -Typical Installation when using antifreeze solution in waterlines. WINTERIZING PROCEDURES You can winterize the water and plumbing system of your coach using one of the following two methods –...
  • Page 92 SECTION 7 – PLUMBING Using Exterior Shower to drain waterline -Typical View Galley Cold Water Faucet/Ice Maker Filter Assembly 4. Remove the Water Filter Cartridge (if (Located below galley sink) equipped). Remove the filter cartridge from • Twist the filter cartridge “counter-clockwise” the filter assembly below the galley sink.
  • Page 93 NOTE: It is not necessary to add antifreeze to the system. A blow-out plug can be purchased the toilet since the flush valve will be ® ® at any Winnebago or Itasca dealer. closed. Do not add automotive antifreeze or...
  • Page 94 SECTION 7 – PLUMBING Dump and Clean Holding Tanks Leave bypass valve handle in NORMAL FLOW position if draining water and blowing 17. Completely drain the sewage and waste water out waterlines. Place in BYPASS position ONLY holding tanks at an approved waste disposal when using antifreeze solution in waterlines.
  • Page 95 SECTION 7 – PLUMBING Winterization Valve 2 (See the “Water System Drain Valve Locations” chart at the end of this section for location on your coach) Galley Cold Water Faucet/Ice Maker Filter Assembly 5. Remove and save the protective cap from the (Located below galley sink) end of the antifreeze siphon tube (which connects to Winterization Valve 2).
  • Page 96 SECTION 7 – PLUMBING Fill Lines • Also, open the Pressure-Temperature Relief valve at the top right portion of the tank to 6. Turn the Water Pump switch on. prevent air locking in the tank while 7. Open each hot and cold water faucet handle/ draining.

  • Page 97: Winterizing Optional Appliances

    SECTION 7 – PLUMBING 17. Close dump valves and refit the dust cap onto 4. Ensure water has drained from the Ice Maker the drain outlet. supply line, then reconnect to inlet valve. This will inhibit rust formation on valve shafts 5.
  • Page 98 SECTION 7 – PLUMBING Winterizing Washer/Dryer (Stackable) –If Equipped Method 1 – Drain Water If you have decided to completely drain the coach waterlines, follow these steps to winterize your Washer/Dryer: 1. With the Washer/Dryer power OFF, pour 1/2 quart of RV-type antifreeze into the Washer drum.

  • Page 99: Water System Drain Valve Locations

    SECTION 7 – PLUMBING 2. Press ON/OFF button, set water temperature NOTE: Check water inlet hoses and pump to WARM, then press START. Let machine periodically (see manufacturer’s user fill until the drum turns (this could take up to guide for further information). 1 to 2 minutes).

  • Page 101: Entertainment

    Secondary Source Selector Control (Located in front passenger overhead cabinet) (Located in your InfoCase Box) NOTE: There may be a slight delay when To Watch Satellite TV changing sources. Winnebago • Connect Satellite Receiver to the Accessory ® Industries recommends setting each Connection Cable (Satellite Receiver 1 or 2.)
  • Page 102 SECTION 8 – ENTERTAINMENT • Power “ON” TV, HDMI Video Selection All TV’s in the coach will now be connected System, and Satellite Receiver. to the roof antenna (via coax cable) and set TV to be viewed through antenna input. •...

  • Page 103: Front Tv Ignition Switch Interlock

    SECTION 8 – ENTERTAINMENT To Listen to FM Radio Through Home Theater • Power “ON” TV, HDMI Video Selection System, and Blu-ray/DVD Home Theater. • Determine which TV you want to view radio source from (e.g. EXTERIOR for Exterior Entertainment Center TV) and select “Blu- ray”...
  • Page 104 SECTION 8 – ENTERTAINMENT Home Theater System remote (or “Play” button on Home Theater System) to begin playing the feature. 8. Volume is adjusted with the 3. Set TV Input to HDMI1 by using the TV Home Theater System remote remote or the Controls on the TV.

  • Page 105: Tv (Dining Buffet) - Power Lift

    SECTION 8 – ENTERTAINMENT Further Information See the manufacturer’s user guide provided in your InfoCase for complete feature descriptions and operating instructions. TV (DINING BUFFET) - POWER LIFT -If Equipped (Typical View - your coach may vary in appearance) Your coach may be equipped with a TV power lift/lower mechanism built into the dining buffet 2.
  • Page 106 SECTION 8 – ENTERTAINMENT The digital antenna is equipped with a built-in amplifier for maximum VHF and UHF • Signal Meter • Attenuator Dial Power Switch programming. WARNING Never allow the antenna to touch electrical power lines or any other electrical wires.

  • Page 107: Tv Signal Amplifier

    A second connection may be included inside a cabinet in the bedroom for the rear TV (if equipped). SATELLITE DISH AND CABLE ® See your authorized Winnebago Industries TV CONNECTIONS dealer for proper installation and sealing of roof (Input) mounted components.

  • Page 108: Tv Digital Satellite System (Automatic/In-Motion)

    SECTION 8 – ENTERTAINMENT NOTE: Your coach is pre-wired with two satellite dish coaxial cables from the roof-mounted satellite dish. Both cables are located near the front TV entertainment center cabinet (satellite prep area). If you desire a satellite receiver in the bedroom area, a third coaxial cable is provided from the front satellite prep area to the bedroom satellite prep area (a...

  • Page 109: Tv Digital Satellite System - Automatic

    SECTION 8 – ENTERTAINMENT 3. To turn off the power after it has locked onto TV DIGITAL SATELLITE satellites, press the “POWER” and SYSTEM – AUTOMATIC “SELECT” buttons at the same time. –If Equipped Note: The Automatic Multi-Satellite antenna is The Automatic Multi-Satellite Television not meant for use while traveling.
  • Page 110 SECTION 8 – ENTERTAINMENT To Swivel TV 1. Pull the black strap (located on back side of TV) straight down to release the TV from the mounting bracket. 2. Pull the TV out and pivot to desired position. 3. Rotate TV back to center position and press straight back.

  • Page 111: Furniture And Softgoods

    SECTION 9 – FURNITURE AND SOFTGOODS LOUNGE CHAIR - SWIVEL –If Equipped (Typical View – Your coach may differ in appearance) This chair is not equipped with a seat belt and is not intended for seating while the vehicle is in motion.
  • Page 112 SECTION 9 – FURNITURE AND SOFTGOODS 3. Latch strap and tighten as necessary for security. WARNING Properly secure all free-standing chairs, furniture, and loose items prior to driving. Moving items can cause driver distraction, possibly resulting in an accident that can result in death or serious injury.

  • Page 113: Sliding Buffet Table And Chairs

    SECTION 9 – FURNITURE AND SOFTGOODS 3. Push edge of buffet table in to adjoin with the table extension. WARNING Properly secure all free-standing chairs, furniture, and loose items prior to driving. Moving items can cause driver distraction, possibly resulting in an accident that can result in death or serious injury.
  • Page 114 SECTION 9 – FURNITURE AND SOFTGOODS 3. Latch strap and tighten as necessary for security. 4. Push edge of buffet table in until it locks into place. Buffet Table Extension 1. Grasp the edge of the buffet table and pull all the way out.

  • Page 115: Sleeping Facilities

    SECTION 9 – FURNITURE AND SOFTGOODS Dinette to Bed 1. Remove both dinette back cushions and set aside. Sliding Mechanism SLEEPING FACILITIES 2. Lift both dinette seat cushions upward. WARNING Sleeping facilities are not intended for use while vehicle is in motion. For safety, passengers must use safety belted seating positions while vehicle is in motion.

  • Page 116: Dinette - Extendable Table And Chairs

    SECTION 9 – FURNITURE AND SOFTGOODS WARNING Failure to engage the lock rod when the table is raised may result in injury. DINETTE - EXTENDABLE TABLE AND CHAIRS –If Equipped (Typical View – Your coach may differ in 5. Rotate lock rod up to secure table in the appearance) lowered position.

  • Page 117: U-Shaped Dinette/Bed Conversion

    SECTION 9 – FURNITURE AND SOFTGOODS Dinette Table Leg Adjustment 3. Release the catch on the table leg brace (located on the bottom side of dinette table) It may be necessary to adjust the height of the and lower table leg for support. dinette table leg(s).

  • Page 118: Sofa/Bed Conversion

    SECTION 9 – FURNITURE AND SOFTGOODS 2. Lift edges of the dinette cushions up and push the dinette table straight down. Make sure the table is lowered as far as it will go so when arranging the cushions to cover the bed area, they are even with the other dinette cushions.

  • Page 119: Extendable Sectional Sofa

    SECTION 9 – FURNITURE AND SOFTGOODS WARNING Stow sectional sofa extension before retracting slide rooms. Failure to observe can cause injury and will cause equipment damage. Extending Sectional Sofa 1. Release and Hold the black lever (located on the arm of the sectional) to release the sectional extension.

  • Page 120: Rest Easy Multi-Position Lounge

    SECTION 9 – FURNITURE AND SOFTGOODS 3. Grasp the pull strap (located on the front side of the sectional extension seat cushion) and pull UP and OUT. Reverse steps to store the sectional extension. 4. Push front of seat cushion down, and then REST EASY MULTI-POSITION push rearward to secure the seat cushion into...
  • Page 121 SECTION 9 – FURNITURE AND SOFTGOODS NOTICE • Press to return upright Do not recline the lounge completely flat • Press to unless the footrest trundle section is recline extended. Do not occupy the lounge when elevating the seat back from the flat bed position to upright lounge position.

  • Page 122: Digital Sleep Air Bed

    SECTION 9 – FURNITURE AND SOFTGOODS may unlatch the footrest and push it against the lounge seat. The footrest will lock when in the fully extended position. You must squeeze the release latch to retract the footrest. DIGITAL SLEEP AIR BED ®...

  • Page 123: Bed - Power Lift

    SECTION 9 – FURNITURE AND SOFTGOODS elevating the bed into the fully upright position. This will help prolong the life of your air mattress. WARNING Further Information For complete operating instructions and Keep people away from operating cautions, see the Innomax air bed user guide mechanism and pinch hazard areas during use.

  • Page 124: Wood Furniture And Cabinetry

    No matter which species you choose for your new Winnebago Industries motorhome cabinetry, please keep in mind that no two pieces -Typical View of wood are exactly the same.

  • Page 125: Slideout Rooms And Leveling

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING SLIDEOUT ROOM KEYLOCK A Master Slideout Room Keylock is located near the interior slideout control switch(es). This keylock must be turned ON to operate slideout room(s). Slideout Room Travel Lock (Your coach may be equipped with one or more types) -Typical View NOTICE...

  • Page 126: Slideout Room Retraction (With Power Lift Bed)

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING Slideout Lock Drain Line SLIDEOUT ROOM If your coach is equipped with electric RETRACTION (WITH POWER Slideout Room Travel Locks, it is recommended LIFT BED) to periodically inspect the slideout lock drain line (located near the top of the exterior slideout -If Equipped room).

  • Page 127: Slideout Room Operation - Electric

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING SLIDEOUT ROOM OPERATION – ELECTRIC CAUTION WARNING Never drive the vehicle with a slideout room extended! Your motorhome may have more than The slideout room system uses 12-volt DC one slideout room. Understand which motorized mechanisms with an electronic control switch operates which slideout room prior system to provide smooth operation and positive...
  • Page 128 SECTION 10 – SLIDEOUT ROOMS AND LEVELING • If the slideout room has a couch or other • Remove all items from the coach living room furniture, make sure no people or pets are floor and close cabinet doors and drawers. Be seated on them until the room has been fully sure there are no items at the end of the bed, extended.

  • Page 129: Slideout Room - Extreme Weather Precaution

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING • Insert the Safety Lock key and turn to activate SLIDEOUT ROOM slideout room control switch. TROUBLESHOOTING (POWER • Press the Slideout Room “RETRACT/IN” GEAR ® switch and hold until the room is fully retracted, then release the switch.
  • Page 130 SECTION 10 – SLIDEOUT ROOMS AND LEVELING Manual Mode • Light will flash if Manual Mode lets you individually move the • Light will flash fault park brake not set code if system two room arms by pressing the IN and OUT malfunctions buttons on the touchpad.

  • Page 131: Slideout Room Troubleshooting (Lippert)

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING SLIDEOUT ROOM • Light will flash if • Light will flash fault TROUBLESHOOTING code if system park brake not set malfunctions (LIPPERT) -If Equipped Battery Voltage or Circuit Breaker Problems If the slideout room will not work: •...

  • Page 132: Slideout Emergency Retraction (Power Gear )

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING • (9) - HALL POWER SHORT TO • Motor • Mode GROUND. Power to encoder has been • Status Direction Button LED’s shorted to ground. This is usually a wiring problem. NOTE: When an error code is present, the slideout control panel needs to be reset.

  • Page 133: Slideout Emergency Retraction (Lippert)

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING Your coach may be equipped with one or two 4. Crank the room(s) until it is just “snugged up.” motor/gearbox units (depending on model), Do not over-crank or you could damage the which is located beneath the slideout room rail gear assembly.
  • Page 134 SECTION 10 – SLIDEOUT ROOMS AND LEVELING 2. Using a flat-head screwdriver, push it up 5. Using a flat-head screwdriver, push bottom of underneath the screw cover and pull up to slideout motor UP to disengage release the cover. Remove the rest of the cover (approximately 1/2”...

  • Page 135: General Slideout Care

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING Slideout Travel Support -Typical installation shown • Place support item (e.g. 2x4 wood • Ensure slideout motor is disengaged board) above interior slideout room as approximately 1/2” from base. shown. 6. Push slideout room in to travel position, 8.

  • Page 136: Leveling System

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING In addition, certain caulks and sealers may include chemicals that may adversely effect the performance of the seals. See your authorized dealer for caulks and sealers recommended for your coach. LEVELING SYSTEM The Hydraulic Leveling System makes selecting a parking site easier and faster by reducing the effect of uneven ground.
  • Page 137 SECTION 10 – SLIDEOUT ROOMS AND LEVELING The Auto Level Remote switches are located just inside the entrance door and in the exterior service center. “Jacks Down” Light (Located on dash) -Typical View Auto Level Remote Switch (Located near entrance door) NOTICE -Typical View •...

  • Page 138: Checking Hydraulic Oil Level

    SECTION 10 – SLIDEOUT ROOMS AND LEVELING 4. See the Leveling System Operation Guide Breather/Fill Cap supplied in your InfoCase for troubleshooting instructions or operating the Leveling System if jacks fail to retract or any other functions fail. Further Information See the manufacturer’s operation guide provided in your InfoCase for complete operating instructions, safety precautions, and...

  • Page 139: Maintenance And Storage

    • Have the sealant replaced if you notice any of seams, etc., should also receive immediate the above. Your local Winnebago Industries attention. Delaying these repairs may allow water dealer has the correct and necessary parts and leakage and result in damage to interior ceiling experience to help you maintain your sealants.

  • Page 140: Undercarriage

    SECTION 11 – MAINTENANCE AND STORAGE Rinsing and washing the surface helps remove UNDERCARRIAGE the fallout and neutralize the acid. After the initial 60-day cure stage, a coat of wax or Buildup of mud and dirt under the body of the polish can help protect the surface from these vehicle can cause damaging rust or corrosion on types of contaminates.
  • Page 141 SECTION 11 – MAINTENANCE AND STORAGE NOTE: When driving in wintry conditions, the • With area to be washed still wet from the rinse, road surface may be covered with heavy use the recommended soapy mixture to clean salts or small rocks to improve road the area.

  • Page 142: Exterior Graphic Care

    SECTION 11 – MAINTENANCE AND STORAGE Protective Film higher than 60 degrees for 60 days. Failure to observe this precaution could -If Equipped void your paint warranty. Your coach may be equipped with a protective • We recommend a silicone-free polish with an film to defend against everyday road hazards.

  • Page 143: Front End Masks And Paint Damage

    LIGHTS cleaning products to use on plastic parts. Exterior Light Lenses ® Most Winnebago Industries vehicles have NOTICE polycarbonate lenses on exterior lamps, which are very sensitive to a variety of chemical solvents and cleaners.

  • Page 144: Interior Soft Goods

    SECTION 11 – MAINTENANCE AND STORAGE • Contact with certain chemicals can cause areas. For best results, fabric cleaning should be etching, “crazing”, or cracking of the lens, referred to a professional carpet and upholstery which can significantly reduce the lens clarity cleaner.

  • Page 145: Cabinetry - Cleaning

    SECTION 11 – MAINTENANCE AND STORAGE Vinyl simulated wood panels may be cleaned with a mild, water-based cleaner and a soft cloth. UltraLeather Cleaning Chart Do not use solvents on vinyl wood panels. Detergent/ Cleaner/ Type of Stain Water Degreaser NOTE: Many cabinetry and furniture items ...

  • Page 146: Care And Maintenance

    SECTION 11 – MAINTENANCE AND STORAGE To remove cuts and scratches, use a more Stainless steel does not deteriorate due to ® aggressive cleaning powder such as Comet frequent cleaning, so proper cleaning can be moistened steel wool soap pad, or green scouring performed whenever necessary.

  • Page 147: Galley Sink

    SECTION 11 – MAINTENANCE AND STORAGE Important “Don’ts” RANGE AND REFRIGERATOR • Do not use hydrochloric acid or any other For care and appearance maintenance of the detergents containing chlorides on stainless range and refrigerator, refer to the appliance steel. manufacturer’s operation and maintenance •...

  • Page 148: Doors And Windows

    SECTION 11 – MAINTENANCE AND STORAGE General Cleaning. Rinse all food, beverage, or VEHICLE STORAGE – cosmetic residue from the sink as soon as PREPARATION possible. Some residues, if left to sit in the sink, may require the use of detergent or a mild liquid Properly preparing your vehicle for storage or gel abrasive cleaner.

  • Page 149: Vehicle Storage - Removal

    SECTION 11 – MAINTENANCE AND STORAGE 9. Inspect all seams and seals around doors, system (if equipped). See appropriate filter windows, vents, and any other joints. Replace installation instructions in Section 7 - or repair any that are damaged. Sealing Plumbing.

  • Page 150: Chassis Service And Maintenance

    SECTION 11 – MAINTENANCE AND STORAGE NOTE: Before turning the water supply on, assure that the water faucet filter is in place and that the water shut-off valve (typically located inside galley cabinet beneath sink) is OPEN. 3. Be sure the ice bin is in place and the automatic shutoff arm is down.

  • Page 151: Coach Maintenance Chart

    SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Propane Gas System ...
  • Page 152 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Safety Equipment Check operation of the following items: ...
  • Page 153 SECTION 11 – MAINTENANCE AND STORAGE COACH MAINTENANCE CHART These recommendations apply for normal recreational use. Heavy duty or full-time use may require more frequent maintenance intervals. Always use specified sections or manufacturer’s guide for further information and instructions. Sealants ...

  • Page 155: Miscellaneous

    SECTION 12 – MISCELLANEOUS NOTE: We recommend that you dump all LOADING THE VEHICLE holding tanks before traveling to avoid carrying unnecessary weight. NOTE: Your motorhome’s load capacity is designated by weight, not by volume, so you cannot necessarily use all available WARNING space when loading your motorhome.
  • Page 156 SECTION 12 – MISCELLANEOUS Corner Weighing (Side-to-Side) You will first drive only your front wheels onto the scale pad, then drive ahead so that the The most accurate method of weighing a whole vehicle is on the scale, then finally pull off motorhome is to weigh each “corner”...

  • Page 157: Car Or Trailer Towing

    SECTION 12 – MISCELLANEOUS axle is 12,000 lbs., then the load on each rear dual listed Gross Weight Ratings. See “Vehicle set (left rear duals or right rear duals) should not Certification Label” in the Introduction section exceed 6,000 lbs. for information on gross weight ratings.

  • Page 158: Trailer Wiring Connector

    SECTION 12 – MISCELLANEOUS Before descending a steep or long grade when TRAILER WIRING towing a trailer, reduce speed and shift into a CONNECTOR lower gear to control vehicle speed. Avoid prolonged or frequent application of brakes Your coach is pre-wired for trailer or car which could cause overheating and brake failure.

  • Page 159: Fireplace

    350 The tow vehicle brakes may be rated for lbs. All Winnebago Industries models operation at GVWR, not GCWR. equipped with a Class IV hitch have a...

  • Page 160: Entry Step - Electric

    SECTION 12 – MISCELLANEOUS Remote Operation Further Information Refer to the Fireplace user guide provided in your InfoCase for complete operating and maintenance instructions, as well as safety • ON-I/II precautions. • TIMER • FIRE ENTRY STEP – ELECTRIC • OFF WARNING Do not use step unless fully extended.

  • Page 161: Tool And Ladder Storage

    SECTION 12 – MISCELLANEOUS Automatic Mode - Entry Step This feature is intended to prevent injury or damage by an extended step while the vehicle is Switch ON moving. (Step Operates with Door) With the Step switch in the ON position, the Further Information step is in Automatic Mode.

  • Page 162: Storage Compartment Doors

    SECTION 12 – MISCELLANEOUS • Keep the rungs of the ladder clean and dry doors with the palms of your hands. If the door is while in use. Never use the ladder when it is ajar you will hear and feel a loud “click” when raining, snowing, or icy.

  • Page 163: Windows

    SECTION 12 – MISCELLANEOUS WINDOWS • Awning Control • Awning Light Switch Switch Crank-Out Windows • To open, pull out the lever on the window handle and begin cranking the window out “counter-clockwise” to desired position. Awning Control Switch and Awning Light Switch (Located near entrance door) -Typical View...

  • Page 164: Power Roof Ventilator

    SECTION 12 – MISCELLANEOUS POWER ROOF VENTILATOR Lounge, Galley, or Bath Area –If Equipped The 3-speed turbine vent is controlled by a switch on the wall to raise or lower the dome. The turbine fan will start automatically as the vent is raised, and stop as the vent is lowered.

  • Page 165: Effects Of Prolonged Occupancy

    SECTION 12 – MISCELLANEOUS Minimize moisture released inside the from the roof ventilator. The fan speed coach selector allows you to control the amount of circulation you need at any time. Run the range hood fan while cooking and open a bath vent while bathing or showering to 5.
  • Page 167 INDEX About this Manual ..........................1-1 Air Conditioner Filters .......................... 4-13 Air Conditioner/Heater – Automotive (Dash) ..................3-9 Audio-Video System Basic Operation ....................8-3 Bathroom .............................. 11-9 Battery Access ............................6-10 Battery Boost Switch ..........................3-8 Battery Care ............................6-11 Bed - Power Lift ...........................

  • Page 168: Exterior Automotive Paint Finish

    Index Electrical System – House 120-Volt AC ....................6-1 Electrical System – House 12-Volt DC ....................6-9 Electronic Thermostat ........................... 4-11 Emergency Exits ............................. 2-6 Engine Access – Interior ........................3-14 Engine Cooling System ........................3-15 Engine Overheat ............................ 2-10 Entry Step –...
  • Page 169 Index Loading the Vehicle ..........................12-1 Lounge Chair - Swivel ..........................9-1 Maintenance ............................2-6 Map Light Switch ........................... 3-8 Microwave Oven/Range Hood ....................... 4-5 Mirrors – Power Electric ......................... 3-5 Mold, Moisture, and Your Motorhome ....................2-8 MotorAid Water Heater .......................... 4-9 Occupant and Cargo Carrying Capacity Label ..................
  • Page 170 Index Seat Belts ..............................3-3 Seats – Driver/Co-Pilot ........................... 3-1 Service and Assistance ..........................1-2 Shower Hose Vacuum Breaker ....................... 7-8 Sleeping Facilities ........................... 9-5 Slideout Emergency Retraction (Lippert) ..................... 10-9 Slideout Emergency Retraction (Power Gear®) ................... 10-8 Slideout Room – Extreme Weather Precaution ..................10-5 Slideout Room Keylock ........................
  • Page 171 Index Washer/Dryer - Stackable ........................4-13 Waste Water System ..........................7-10 Water Heater - Gas/ Electric ........................4-8 Water Heater Bypass Valve ........................7-13 Water Pump ............................7-3 Water System Drain Valve Locations ....................7-21 WaterLine & Tank Drain Valves ......................7-12 Weighing Your Loaded Vehicle ......................

Table of Contents
