- Page 1 Scout PS-Series Thermal Imager Operator’s Manual Document Number: 431-PS00-00-10 Revision: 110 October 2011 ShopFLIR 1.877.766.5412 www. .com Shop for FLIR products online at:...
- Page 2 FLIR for proper disposal. This document is controlled to FLIR Technology Level EAR 1. The information contained in this document is proprietary and/or restricted and pertains to a dual use product controlled for export by the Export Administration Regulations (EAR).
-
Page 3: Table Of Contents
Introduction........... 1 Scout PS-Series Camera Features ......2 Getting Started . - Page 4 — Scout PS-Series Operator’s Manual October 2011 ShopFLIR 1.877.766.5412 www. .com Shop for FLIR products online at:...
-
Page 5: Introduction
See more—and see farther—than with low-light night vision goggles The Scout PS-Series camera makes images from heat, not light, a feat impossible for the naked eye or even image intensified (I night vision devices, which means you can see clearly even without any visible light at all. -
Page 6: Scout Ps-Series Camera Features
Be careful not to leave fingerprints on the camera’s infrared optics. Clean only with low pressure fresh water and a lens cloth. October 2011 ShopFLIR 1.877.766.5412 www. .com Shop for FLIR products online at:... -
Page 7: Getting Started
2 Getting Started The Scout PS-Series camera is available with the features, options, and accessories described in this manual. Refer to the packing list enclosed with your camera shipment to determine the actual contents of your camera package. • PS24 and PS32 Cameras In addition to the camera, Quick Start card, and Documentation/ Training CD or DVD;... - Page 8 Scout PS-Series Operator’s Manual • PS24 and PS32 Camera Options The following optional accessories are available for the Scout PS- Series camera Molle-Compatible Belt Holster Floating Lanyard Camera Carrying Pouch October 2011 ShopFLIR 1.877.766.5412 www. .com Shop for FLIR products online at:...
-
Page 9: Operating Your Scout Ps-Series Camera
3 Operating Your Scout PS-Series Camera 3–1 Camera Features and Controls Power Display Brightness/ × zoom/ (Tasklight On/Off Freeze Frame when Camera in off state) Eyepiece White hot/ Adjustable LED Tasklight USB/Charging Black hot/ diopter ±2 Plug Instalert Lanyard Clip... -
Page 10: Charging The Camera
3–2 Charging the Camera Caution! To assure proper charging, Scout PS-Series cameras should be turned OFF throughout the charging cycle. Charging MUST only be done when the camera is at room temperature; 0 to 40°C (32 to 104°F) or battery damage may occur. -
Page 11: Scout Ps-Series Power Management
When the camera is turned on from the Off state, it takes about four seconds to become operational. During the Bootup process, The FLIR splash screen is shown and then the software version is displayed briefly. Pressing the Power button will toggle the camera between On and Off. - Page 12 Lowest Highest Note When the Scout PS-Series camera is powered Off, the Display Brightness button, when held on, turns on the LED Tasklight. White Hot/Black Hot/Instalert™ Button Use this button to toggle between the two video and the four Instalert color palettes.
- Page 13 Scout PS-Series Operator’s Manual 3—Operating Your Scout PS-Series Zoom Button—PS32 models only Use this button to switch the camera between no zoom (full resolution) and 2× zoom. The central part of the image is magnified twice its normal size when 2× is selected.
-
Page 14: Battery
3–6 Auto Shutdown Operation Auto Shutdown is a feature of the Scout PS-Series camera that helps to guard against draining the battery prematurely by inadvertently leaving the camera on. Auto Shutdown turns the camera off if the following conditions are met: •... -
Page 15: Technical Data
4 Technical Data 4–1 Scout PS-Series Model Features The Scout PS-Series cameras are available with either NTSC or PAL video output format. Scout Model PS24 Scout PS-Series Handheld Thermal Camera with video resolution of 240 × 180 pixels PS32 Scout PS-Series Handheld Thermal Camera with video resolution of ×... -
Page 16: Environmental
Detect Man (1.8 m × 0.5 m) 350 yd. (320 m) PS24 500 yd. (450 m) PS32 1. Actual range may vary depending on camera set-up, environmental conditions, and user experience. October 2011 ShopFLIR 1.877.766.5412 www. .com Shop for FLIR products online at:... - Page 17 ShopFLIR 1.877.766.5412 www. .com Shop for FLIR products online at:...
- Page 18 FLIR Commercial Systems B.V. Charles Petitweg 21 4847 NW Teteringen - Breda The Netherlands PH: + 31 (0) 765 79 41 94 FX: + 31 (0) 765 79 41 99 flir@flir.com ShopFLIR 1.877.766.5412 www. .com Shop for FLIR products online at:...
