  • Page 1 User Manual S28-8CH MDVR GUI Mobile Digital Video Recorder Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved...
  • Page 2 Under copyright laws, the content of this manual may not be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine- readable form, in whole or in part, without prior written consent of Streamax Technology Co., Ltd Copyright 2012-2014. More information www.streamaxtech.com...

  • Page 3: Table Of Contents

    3.2.2.8 IP CAMERA SETTINGS ......................33 3.2.2.9 OTHER SETTINGS ........................33 3.2.3 NETWORK ..........................34 3.2.3.1 LOCAL ........................... 35 More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.
  • Page 4 3.3.1 SYSTEM ............................47 3.3.2 HISTORY ............................. 48 3.3.3 MODULES ..........................49 3.3.4 SMART ............................50 3.3.5 VER INFO ............................ 50 More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 5: Production Chracteristics And Overview

    Support CMS (Central Management System) for remote monitoring via built-in 3G module (HSPA or EVDO), Ceiba (Playback Analysis Software) for video playback, meta-data analysis. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 6: Remote Control

    Each MDVR includes a handheld Infra-Red (IR) controller that allows the user to transmit commands to More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.
  • Page 7 Quick search mode when you playback the record file in MDVR. Press GOTO  button and input the desired time, and the select SURE to jump to the specific time More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.
  • Page 8 Brush the glass screen BRUSH Please put the battery into the remote control as no battery in the standard package More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 9: Gui (Graphic User Interface) Tree

    Manual-S28-GUI-16CH-2013_Q3 1.3 GUI (GRAPHIC USER INTERFACE) TREE More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 10: System Start Up

    More information www.streamaxtech.com SUPER PASSWORD indicates full access to MDVR under the circumstance of losing the password and  Copyright 2012-2014, Streamax Technology Co., Ltd modifies the MAC address. All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 11: Gui Configuration

    You can search all the video files including normal files, alarm files by record date and file type and storage More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.
  • Page 12 START TIME and END TIME: The MDVR device can support the video clip function. This time schedule is for both More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.
  • Page 13 Or you can export the file during certain period to thumb driver or any external storage device and backup to computer for playback (exe file). This exported .exe file can be playback easily by Streamax MINI player or Ceiba as following: By Mini player:...
  • Page 14 NO.: The file number which is being copied to external thumb drive. After successful backup, then the following screen will pop up. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 15: Event Search

    EVENT TYPE: The type of the alarm file including I&O ALARM/ACCELERATION/SPPED/TEMP ALARM/VL ALARM. You can please select different alarm type to search the log and playback the More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 16: Setup

    Move arrow key to select and press ENTER. The MDVR setup screen will show the menu as below: More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 17: System

    GPS must can receive the signal. When the system time arrives the sync time, MDVR unit will synchronize with GPS time once. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 18: General

    MDVR will shut down after 5 minutes after the ignition is off. B) TIMER: MDVR will boot up or shut down automatically at certain time configured every day. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.
  • Page 19 OUTPUT MODE: This is the output mode for monitor. There are 4:3 and 9:6 two options, TRANSPARENCY: Setup the brightness for the screen display as you want. Scroll to【SAVE】to make the setting valid More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 20: Register Info

    Scroll to【SAVE】to make the setting valid. 3.2.1.4 FORMAT Select the devices to format: HDD, SD card or external storage device. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 21: Upgrade

    After format success, MDVR unit will restart automatically. 3.2.1.5 UPGRADE Upgrade to new firmware or MCU. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.
  • Page 22 4. During the firmware upgrade, then following screen will pop up. 5. After upgrade success, the MDVR system will restart automatically, as follow: More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 23: User Security

    If the FLASH is damaged or firmware crashes (The MDVR can boot up to System Initializing interface only and the POWER LED on the MDVR is ON. It cannot boot up to quad view interface). For this situation, please contact Streamax technical support trying to upgrade the firmware by TFTP upgrade 3.2.1.6 USER SECURITY Setup the password for user and admin.

  • Page 24: Config

    Remark: The user log mainly include: start recording and end recording time, event time, GPS module status, power on and power off time and so on. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 25: Geo-Fencing

    To finish the setting for GEO-FENSE, you need to setup the CMS software as well. For more details, More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 26: Record

    RECORD MODE: Record mode, three modes as following: When MDVR is power supplied and starts up, the MDVR will start to record automatically. GENERAL: More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.
  • Page 27 MDVR device and you just need to insert the SD card in the slot on the MDVR device and ENABLE the switch for mirror recording on the MDVR GUI menu. External symbolize that you need to buy the fireproof box (SD card inside) from Streamax in case the vehicle is on fire. More information www.streamaxtech.com...

  • Page 28: Osd Overlay

    30min, when alarm is triggered at 10:30, then the record file start from 10:00 to 10:30 will pack as alarm record. 3.2.2.2 OSD OVERLAY More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.
  • Page 29 But the precondition for this OSD is you must setup the OSD overlay menu to select which information you want to display. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 30: Camera Settings

    LIVE AUDIO: enable or disable the live audio settings switch. 3.2.2.4 RECORD SETTING Make the configurations for resolution, frame rate, image quality parameter setting for each channel. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 31: Mirror Record Settings

    Sub-stream is the settings for 3G wireless transmission; you can setup the bandwidth and enable the channels. Otherwise, it can’t transmit the live video to PC software center server. The setup interface as follow: More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 32: Schedule

    Type: Press ENTER to change the type of the recording mode:  Con: Continuous recording  Alarm: Alarm recording More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 33: Ip Camera Settings

    Ending at 23:59 of one day and beginning with 00:00 of the next day will provide continuous recording without interruption (factory default setting) 3.2.2.8 IP CAMERA SETTINGS 3.2.2.9 OTHER SETTINGS More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 34: Network

    INITIALIZE INTERFACE: This means after MDVR starts up, which default interface you prefer to show: CP3 menu interface or quad image interface. Quad Image is for the regular monitor output display. CP3 is the Streamax designed Control Panel which can support one LED to display the image and realize the station announcement...

  • Page 35: Local

    MAC Address: MAC address is uniquely and cannot change it. 3.2.3.2 SERVER NETWORK The sever IP and port setting for PC software. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 36: Mobile Network

    MDVR started up, the wireless module will always dial up and connect to message ALWAYS: server. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.
  • Page 37 DIAL PARAMETER settings for SIM Card please check the setup as follow form. INTERCOM SETTINGS: it's a switch for interphone function, which can realize speak to center via SIM card. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 38: Ftp Settings

    If the local IP of MDVR is 192.168.3.233, you can log in the MDVR FTP server as follow: ftp://192.168.3.233 and the recorded file save path is : ftp://192.168.3.233/stm/disk/0/p1/2012-11-23/ More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 39: Event

    The default login username is admin, password is: 88888888, if you can’t login at the first time, please try again. 3.2.4 EVENT 3.2.4.1 SENSOR More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.
  • Page 40 3G ACT: means you can define a sensor to active the 3G module, as there is an active mode in 3G setup interface, they are corresponding options. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 41: Sensor Output

    Manual-S28-GUI-16CH-2013_Q3 3.2.4.2 SENSOR OUTPUT Streamax S28 MDVR supports 2 sensor outputs. All the alarm inputs can trigger the two sensor outputs, such as sensor1~8, over speed, temperature, video loss and so on, please access the menu (GUI>>>>SETUP>>>EVENT>>>SENSOR OUTPUT), as follow:...

  • Page 42: Speed

    (HZ) set as first area data (80); SPEED UNIT: MPH or KPH, MILEAGE is the total mileage that the MDVR has run. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 43: Acceleration

    If the MDVR working temperature is higher than the setting for HIGH TEMP, MDVR will trigger alarm. If the MDVR working temperature is lower than the setting for LOW TEMP, MDVR trigger will alarm More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 44: Camera

    M.D.AREA: this option is for user to setup the detect area, as follow, blank square means the area is selected, please exits to the setup interface to save the settings. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 45: Voltage

    SHUTDOWN DELAY: means when MDVR in low voltage for so long time, device will shutdown automatically. 3.2.5 PERIPHERAL More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 46: Ptz

    Bus mode: COM1 can only be used for station announcement, COM2 can only be used for amplifier board, they are unchangeable. COM3 and COM4 is changeable. And 485BUS is switch for smart battery connection. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 47: Information

    2, NO FORMAT means HDD installed but not formatted. All the new hard disk must be formatted after installation 3, showing the detailed information for HDD means HDD works fine. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 48: History

    MDVR (like image quality, resolution, frame rate) with the free space. 3.3.2 HISTORY The data for history information More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 49: Modules

    Manual-S28-GUI-16CH-2013_Q3 Press 【CLEAR】to delete all the current data. 3.3.3 MODULES Display the GPS module information. More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.

  • Page 50: Smart

    Manual-S28-GUI-16CH-2013_Q3 3.3.4 SMART 3.3.5 VER INFO More information www.streamaxtech.com  Copyright 2012-2014, Streamax Technology Co., Ltd All Rights Reserved All specifications are therefore subject to change without notice.
