Important Note – Mounting/Rigging Provisions
The mounting/rigging points found on the sides and back of the enclosure must either be used for mounting
hardware or "plugged" with the bolts and washers provided. The rubber washer provides the water seal and
must be used. The reason for this is that if all these holes are not plugged up, they created leaks in the
enclosure that will compromise its weather-resistance.
frequency performance with reduced output and/or distortion.
DANGER: All rigging fittings must be fitted with either optional mounting hardware or they must remain
sealed with the Stainless Steel hex-head bolts that come installed in the enclosure, in order to maintain
weather resistance. Additionally, if the rigging fittings are not sealed, air leaks could occur in the
enclosure that will compromise the low frequency performance with added distortion and reduced output.
WARNING: WET II rigging fittings are rated at a Working Load Limit of 150 lbs (68 kg) per point. No
single rigging fitting should ever be subjected to a load that is greater than 150 lbs. Failure to heed this
warning could result in injury or death!

WET II FEATURES AND TECHNOLOGY

In addition to extreme weather-resistance, WET II loudspeakers offer numerous features and advances in
technology that provide unprecedented sonic quality and installation flexibility. Some of these include:

Finely tuned internal crossover networks for reduced off-axis lobing, consistent coverage
throughout the crossover region, and greater acoustic linearity.

Uniform-voicing filters minimize sonic variations among the different models.

Geometrically correct large-format hand-laid fiberglass mid and high frequency horns. A wide
selection of dispersion patterns is available.

Aesthetically pleasing, uniquely shaped curved fiberglass enclosures.
composition and the enclosure geometry work together to reduce internal reflections and
standing waves, resulting in superior sound quality.
minimizes water buildup.

Envirotech coating seals crossovers against moisture.

Stainless steel mounting points.

Powder-coated stainless steel yoke brackets included with the four smaller models (W2-218,
W2-228 and W2-2W8); available as an optional accessory kit for the W2-312 and W2-112.

Optional internal 70V/100V autoformer available for the W2-218, W2-228, W2-2W8 and W2-312
for constant voltage distributed systems.

All models are available in black or white finish at no additional charge. Custom colors are
available at a nominal fee.
Community WET II - Operation and Installation Manual - Page 10
Open holes will also be detrimental to low
Externally, the lack of flat surfaces
The enclosure
