Community Wet II Operation And Installation Manual page 5

TABLE OF FIGURES
FIGURE 1 - PHYSICAL FEATURES OF A TYPICAL LARGE WET II ENCLOSURE
FIGURE 2 - WIRING DIAGRAMS FOR W2-218T
FIGURE 3 - WIRING DIAGRAMS FOR W2-228T, W2-2W8T AND W2-312-HT
FIGURE 4 - W2-218 YOKE DIMENSIONS
FIGURE 5 - W2-218 YOKE ASSEMBLY
FIGURE 6 - W2-228 AND W2-2W8 YOKE DIMENSIONS
FIGURE 7 - W2-228 AND W2-2W8 YOKE ASSEMBLY
FIGURE 8 - SSY25KIT DIMENSIONS
FIGURE 9 - SSY25KIT ASSEMBLY
FIND THE LATEST ONLINE
Every effort has been made to ensure that the information contained in this manual was complete and accurate at
the time of printing. However, due to ongoing technical advances, changes or modifications may have occurred
that are not covered in this publication. The latest version of this manual and the most recent product
information published by Communtiy is always available at http://www.communitypro.com. The publication date
can be found on the rear cover or last page.
Community WET II - Operation and Installation Manual - Page 5
