LOCATION OF EQUIPMENT

Master Station (Optional, Special Order Only)
Where a master has been purchased as part of the system, it is generally located
above the breakfast bar in the kitchen/family room at a suggested height of 55"
from the floor to the center of the unit. As all wiring from other stations
is generally terminated at the rear of the master, the walls should be no less than
2 ¾" in depth. A timber wall box should be inserted so as to allow for
correct support of the master station.
IMPORTANT
The master station should be installed in a cavity wall and not a single
brick wall in order to facilitate the wiring behind it.
Where there is wall tiling around or near to the master station, ensure the master
station is mounted either completely within or completely clear of the tiled area
as failure to do so will result in the master being affixed to an uneven surface.
