Summary of Contents for Valet SmartCentre

  • Page 1: Table Of Contents

    Valet SmartCentre Video Intercom System Contents Installation Manual Welcome to Valet Inside front cover Contents Installation Guide Section Component breakdown Cable confi guration chart Wiring diagrams and schematics 5-10 System power supply Voltage Chart Installation 13-14 Operating Guide User Guide Section...
  • Page 2: Installation Guide Section

    Valet SmartCentre Video Intercom System...
  • Page 3: Component Breakdown

    Monitor 11 12 13 1. LCD Screen 2. On/Off Button Monitor/Answer Button 4. Intercom Button 5. Adjustment: Left/Right 6. Image Capture (if fi tted) 7. Door Release (if fi tted) 8. Speaker 9. Power Indicator 10. Intercom Busy Indicator 11. Talk Volume Indicator 12.
  • Page 4: Cable Confi Guration Chart

    We recommend the Valet 8 cable. This cable has 8 cores, 2 of which are shielded and should be used for Audio / Video signals to protect both clarity of image and quality of audio. The other cores give much greater fl...
  • Page 5: Wiring Diagrams And Schematics

    Valet SmartCentre Video Intercom System Wiring Diagrams and Schematics • Cable and Connections for Doorbell/Camera • 1R+ 12V power supply positive for Doorbell/camera. • 2W: GND power supply ground for Doorbell/camera. • 3Y: VIDEO image signal transmitting line. • 4B: AUDIO audio and control lines.
  • Page 6 Valet SmartCentre Video Intercom System SINGLE CAMERA SINGLE MONITOR WITH DOOR LATCH 2 CAMERAS SINGLE MONITOR...
  • Page 7 Valet SmartCentre Video Intercom System 2 CAMERAS MULTIPLE MONITORS 2 CAMERAS, 2 LATCHES MULTIPLE MONITORS...
  • Page 8 Valet SmartCentre Video Intercom System SINGLE CAMERA SINGLE MONITOR 2 CAMERAS, 2 LATCHES SINGLE MONITOR...
  • Page 9 Valet SmartCentre Video Intercom System...
  • Page 10 Valet SmartCentre Video Intercom System...
  • Page 11: System Power Supply

    • Please see the recommended Valet Cable to ensure to optimise your cable network • When fi tting Electronic Door Releases or Latches please ensure you chose a model with it own power supply.
  • Page 12: Voltage Chart

    Failure to do this could result in loss of quality and poor performance. Valet will not be responsible if this information is not strictly adhered too. Permissable Cable Length to Voltage drop...
  • Page 13: Installation

    Single Camera to Single Monitor Installations: 1.1 Determine both SmartCentre Monitor and Doorbell/Camera operating positions and heights. ( Average height 1.5 to 1.6 Metres ). 1.2 Run the appropriate cable between the two positions allowing at least 350mm excess at each location.
  • Page 14 2.1 Please take a moment to select the most suitable Doorbell/Camera position. 2.2 Please consider both daytime, night time and likely weather condition impact. Direct sunlight on the camera and direct contact with rain should be avoided. Your Valet Dealer can assist you with Weathershields for exposed positions.
  • Page 15: User Guide Section

    Valet SmartCentre Video Intercom System...
  • Page 16: System Operating Guide

    Valet SmartCentre Video Intercom System System Operating Guide Please Note: The system must be set for the correct combination of monitors. Each monitor is set as default to “MAIN”. Using system settings, set-up multiple monitor systems as one “MAIN” monitor and the additional monitors as “SUB”.
  • Page 17 Valet SmartCentre Video Intercom System 1 Date and Time Set Up The curser fl ashes at the fi rst character of Day, press “ ” (BUTTON 5) to change value, press BUTTON 6 to move to the next value until both day/mth/yr and 24 hour clock is set.
  • Page 18 Valet SmartCentre Video Intercom System 5 Brightness/Contrast/Colour In standby mode press BUTTON 3 to display an image, press either adjustment ” “ button to adjust the Brightness/Contrast/Color for the image. In monitoring mode, keep pressing ” “ button back or forwards to adjust Brightness.
  • Page 19 Valet SmartCentre Video Intercom System Photo function if fi tted Description: If after 10 seconds, there is no answer from the Monitor/Monitors the photo function will take an image of the visitor and store it for later viewing. The date / time is also stored. Up to 8 images can be stored.
  • Page 20: Operation, Care Instruction

    The Valet Smart Centre Video Intercom may work with cable and products not recommended or known to Valet. However, Valet warrants its product to work as per its specifi cation if the recommended cable is used and the wiring instructions are followed.
