INSTALLATION OF AUXILIARY INPUT JACK - TYPE A

(
For Systems With a Master
a) INSTALLATION AT FRAME STAGE PRIOR TO LINING OF WALLS
Secure wall mounting plate (PN155) to the stud wall adjacent to the power point
intended for operating your Tape Deck, CD player etc, and pull the shielded cable
through the opening of the plate.
After the walls have been lined, cut out the inside diameter of the plate, strip the
shielded cable and solder to the terminals of the RCA sockets as indicated on
the diagram. (See Page 21)
Screw the input jack to the mounting plate.
b) INSTALLATION WITH TIMBER FRAME WALLS ALREADY LINED
Ensure the shielded cable can be run to the location selected and that no noggins
are in the way.
Cut out the wall lining and insert the wall mounting plate (PN154) then pull the wire
through the opening.
Strip the shielded cable and solder to the terminals of the RCA sockets as
indicated on the diagram. (See Page 21)
Screw the input jack to the mounting plate.
c) INSTALLATION IN CAVITY BRICK WALLS
Drill through the brick work to the cavity.
Enlarge the hole slightly so as to allow the pins of the jack to recess into the
brick work.
Pull the shielded cable through the opening, strip the shielded cable and solder
to the terminals of the RCA sockets as indicated on the diagram. (See Page 21)
Drill and plug the brick work at the mounting points for the input jack and screw
the jack to the wall.
) (Special Order Only)
