MASTER TERMINATIONS
1 pair shielded
3 pair
+
1 pair
shielded
SINGLE CORE
*
-
+
SUPPLY
13.8VDC
OUTER SHIELD
RED
BLACK
OUTER SHIELD
RED SHIELDED
WHITE SHIELDED
WHITE
BLUE
GREEN
ORANGE
SINGLE CORE
*
IMPORTANT NOTE: ENSURE THE POLARITY (+VE AND -VE)
Single Core not required if Aux/Lock Board(s) not used
*
23
AUX R
AUX L
COM
TAPE L
TAPE R
RED - 13.8V
BLACK - 0V
SPARE
SHIELDS - 0V
GREY - TIMER CON
YELLOW - VOLTAGE CON
WHITE
BLUE
GREEN
ORANGE
AUXILIARY OUTPUT
OF THE POWER SUPPLY CONNECTION
IS CORRECT.
AM
FM
