- Page 1 User Guide English ( 2 – 4 ) Guía del usuario Español ( 5 – 7 ) Guide d'utilisation Français ( 8 – 10 ) Guida per l'uso Italiano ( 11 – 13 ) Benutzerhandbuch Deutsch ( 14 – 16 ) Appendix English ( 17 –...
-
Page 2: Box Contents
Quick Start / Connection Diagram Windows users: Before connecting M-Track Eight to your computer, install the drivers: 1. Go to m-audio.com/drivers and download the latest M-Track Eight driver for your operating system. 2. Open the file you downloaded and double-click the driver installer file. -
Page 3: Front Panel
Standby Mode draws only a small amount of power. Display: This display shows the signal level of the eight inputs. The edges of the display will light up when M-Track Eight is powered on. A leaf symbol will light up when M-Track Eight is in standby mode. -
Page 4: Rear Panel
USB Port: This connection will allow you to send audio to/from a computer. Use a USB cable to connect the M-Track Eight to a computer. The M-Track Eight requires a USB 2.0 connection. Inputs 3–8: Connect microphones or line-level devices to these inputs with an XLR or 1/4" TRS cable. - Page 5 Appendix (English) Signal Flow Diagram...
-
Page 6: Technical Specifications
Technical Specifications All specifications are measured at 20 kHz bandwidth. Mic Inputs 1–8 (balanced XLR) 20 Hz – 20 kHz (+0.1 dB) Frequency Response Dynamic Range 111 dB (A-weighted) Signal-to-Noise Ratio 111 dB (1 kHz, +4 dBu, A-weighted) 0.002% (1 kHz, +4 dBu, -1 dBFS) THD+N -132 dBu (max gain, 40 Ω... - Page 7 Specifications are subject to change without notice. Trademarks and Licenses M-Audio is a trademark of inMusic Brands, Inc., registered in the U.S. and other countries. All other product or company names are trademarks or registered trademarks of their respective owners.
- Page 8 Manual Version 1.1...
