INSTALLATION
9. After replacing the freezer door, screw
the middle hinge back onto the opposite
side of the unit.
Ensure the freezer door is aligned
horizontally and vertically, so that the
seals are closed on all sides before finally
tightening the hinge.
10. Remove and replace the pin on the
reverse side of the hinge.
11. Carefully set the upper door back into
place. Re-attach the re-assembled upper
door hinge on the opposite side of the
unit. Ensure the fridge door is aligned
horizontally and vertically so that the
seals are closed on all sides before finally
tightening the top hinge.
12. On the top panel move the blanking
plate to the side opposite the hinge.
10
Middle hinge
180˚
unscrew screw
