Summary of Contents for Currys Essentials CIFF5012
- Page 1 BUILT- IN FRIDGE FREE ZER I NS T R UC T I O N MA NUA L C IF F 5 012 CIFF5012_IB_130114_Edits_Pauline.indd 1 18/01/2013 10:36 PM...
-
Page 2: Table Of Contents
Contents Unpacking ............................ 4 Installation ........................... 5 Location ..................................5 Reversing the Door Swing ........................... 5 Levelling the Unit ..............................9 Cleaning Before Use .............................. 9 Before Using Your Unit ............................9 Interior Accessories ..............................9 Product Overview ........................10 Operation ........................... -
Page 3: Unpacking
Thank you for purchasing your new Currys Essentials Fridge Freezer. We recommend that you spend some time reading this instruction manual in order that you fully understand all the operational features it offers. Read all the safety instructions carefully before use and keep this instruction manual for future reference. -
Page 4: Installation
Installation INSTALLATION Location When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated with an average room temperature of between 16°C and 32°C. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption. - Page 5 INSTALLATION 2. The side at which the door opens can be changed from the right side (as supplied) to the left side, if the installation site requires. Tilt the appliance slightly towards the rear and prop it securely. Unscrew the door hinge screws and remove the hinge pin bracket.
-
Page 6: Levelling The Unit
INSTALLATION Levelling the Unit To do this adjust the two levelling feet at the front of the unit. If the unit is not level, the doors and magnetic seal alignments will not be covered properly. Cleaning Before Use Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm water using a ‘wrung-out’... -
Page 7: Product Overview
Product Overview Thermostat and Bulb Fridge Glass Shelves Fridge Door Shelves Salad Bin Cover Shelf Salad Bin Freezer Drawers Adjustable Feet Egg Tray Ice Tray CIFF5012_IB_130114_Edits_Pauline.indd 7 18/01/2013 10:36 PM... -
Page 8: Operation
Operation Switching On Your Unit 1. Connect the mains cable to the mains socket. The internal temperature of your unit is controlled by a thermostat. There are seven settings, of which position 7 is the coldest and position 0 turns the unit off. -
Page 9: Shopping For Chilled Foods
Shopping for Chilled Foods • Take a quick look at the chilled food package and make sure it is in perfect condition. • Try to keep chilled food together whilst shopping and on the journey home as this will help to keep the food cold. -
Page 10: Preparations For Freezing
Preparations for Freezing • Use quality food and handle it as little as possible. Freeze food in small quantities as it freezes faster, takes less time to defrost and enables you to control the quantity you need better. • Leave cooked food to cool completely. Chill food before freezing if possible. • Consider how you will want to cook the food before freezing it. -
Page 11: Cleaning
Cleaning Defrosting The freezer compartment of this unit is frost-free. With proper use, there should not be any frost accumulated. However, in case of improper use of the freezer compartment, frost might build up in the freezer compartment after the unit has been used for a period of time. Scrape away the frost using a plastic scraper (not included). -
Page 12: Maintenance
Maintenance Changing the Internal Light 1. Before carrying out the bulb replacement always adjust the thermostat control dial to Position 0, then disconnect the mains supply. 2. Use a flat bladed screwdriver and gently prise off the light bulb cover. 3. -
Page 13: Specifications
Specifications Model CIFF5012 Appliance Category Category 7 (Refrigerator – Freezer) Overall Dimension (W x D x H) 540 x 555 x 1772 mm Fresh Food Storage Compartment 160L Volume Frozen Food Storage Volume Defrosting Type Frost Free (Freezer Compartment) Climate Class This appliance is intended to be used at an ambient temperature between 16°C and 32°C. -
Page 14: Safety Warnings
Safety Warnings For your continued safety and to reduce the risk of injury or electric shock, please follow all the safety precautions listed below. • Read all instructions carefully before using the unit and keep them for future reference. • Retain the manual. If you pass the unit onto a third party, make sure to include this manual. • Keep ventilation openings in the unit enclosure clear of obstructions. - Page 15 Normal energy consumption Increased energy consumption Installation site In a ventilated room. In an enclosed, unventilated room. Protected from direct sunlight. In direct sunlight. Not situated near to a heat source Situated near to a heat source (radiator, oven). (radiator, oven). Where the ideal ambient room Where there is a high ambient room temperature is approx 20°C.
- Page 16 NOTE: If you require a replacement for any of the items listed below, please quote their corresponding part numbers: Replacement Part Part Number Fridge Glass Shelf 1099040 Salad Bin Cover Shelf 1055227 Salad Bin 1401338 Small Freezer Drawer 1401339 Large Freezer Drawer 1401337 Egg Tray 1413713...
