1. Introduction

What's in this Chapter:
•
•

The Astra 1220U

The Astra 1220U Flatbed Scanner is a highly reliable, high quality product which is designed to give long
term service. However, like all opto-electronic products, occasional routine maintenance may be required
for certain scanner components. This service manual is provided so that qualified maintenance and repair
technicians can perform service as needed.

Scanner Specifications

Scanner Type: ..........................................
Preview Speed: ........................................
Maximum Scannable Area: .....................
Optical Resolution: ..................................
Maximum Resolution: .............................
Warm Up Time: .....................................
Color Scanning Method: .........................
Sample Depth
Color Mode: .....................................
Grayscale Mode: ..............................
Line-Art Mode: .................................
The Astra 1220U
Specifications
Flatbed
31.6 seconds/A4 size (Color Mode)
21.1 seconds/A4 size (Gray/Lineart Mode)
8.5 x 11.7 inches
600 x 1200 dpi
9600 x 9600 dpi
30 sec.
One pass with color CCD
30 Bits/Pixel Internal
10 Bits/Pixel Internal
1 Bit/Pixel
