Component Replacement Kits for UTA-3A

Component kits are listed in the tables below with component kit drawings provided on the following
pages. When ordering replacement kits, be sure to include associated part numbers with your purchase
order(s).
Replacement Kits
Part No Description
030032-14 KIT,MOTOR,12V,M42SP-4,SUN
030072-47 KIT,CARTON,UTA-3A
030088-21 KIT,LAMP A'SSY,COLD-CATHODE,UTA-3A
030104-25 KIT,FLAT CABLE,UL2896,8P,420mm,SUN
030113-08 KIT,CABLE,9P,230mm
030146-04 KIT,GLASS WINDOW,UTA-3A
030202-18 KIT,UP HOUSING,UTA-3A
030203-08 KIT,MOTOR A'SSY,12V,M42SP-4
030205-06 KIT,INV,9V,2.6¢x250x1,Sun,COTEK
030212-01 KIT,HINGE A'SSY,UTA-3A
030690-00 KIT,PCBA,M/B,UTA-3A
030691-00 KIT,MANUAL,OP,UTA-3A
