Service Manual
CCD Pin Assignment
14
PIN CONNECTIONS
1
OS3
2
SS
3
RS
4
CP
5
SS
6
NC
7
NC
8
02
9
01
10
SH3
11
SS
2556D
OS2
22
OS1
21
OD
20
SP
19
NC
18
SS
17
NC
16
02
15
01
14
SH1
13
SH2
12
