LST FC600/TMAX/78 Specification Sheet

Thermal Max Detector
FC600/TMAX/78
• Addressable conventional technology
• Individual detector identifi cation with
optional address module
• Alarm temperature 78°C
• Allows for connection of external
remote indicator
• Anti-tamper locking feature on
detector base
• Function check by means of test
magnet
Description
The Thermal Max Detector FC600/TMAX/78 recogni-
ses a temperature of 78°C as alarm threshold and is
compliant to EN 54 -5 (class BS) standards. It can be
used in rooms with a height of up to 6m. Any alarm
will be transmitted to the fi re detection panel in con-
ventional technology. An individual detector identifi ca-
tion can be obtained with the optional Address Module
NG58-1.
The detector is equipped with an LED indicator which
is visible from all sides at any angle and thus facilitates
Specifi cations
Operating voltage
Current consumption
Alarm temperature
Operating temperature
Ambient temperature
Relative humidity
Dimensions ø × h (without base)
Colour
Weight
Approvals
Order number
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
easy identifi cation of the alarming detector. In addition,
a remote indicator can also be connected.
Several types of detector bases are available to faci-
litate quick and easy installation. To prevent unautho-
rized removal of the detector, all detector bases are
equipped with an anti-tamper locking feature. A de-
tector function test can be conveniently conducted by
using a test magnet.
10 – 30VDC (supply through detector line voltage)
typ. 40µA (normal condition)
78°C
max. +60°C
-30°C to +70°C (continuous operation)
max. 95% (no condensation)
106 × 46 (mm)
white
80g
LPCB 603b/01
0832-CPD-0126
242071
Thermal Max Detector/Conv./FC600 FC600/TMAX/78
0832–CPD–0126
A
FC600-TMAX-78_DBL_LST_EN_0850.PDF • PAGE 1
