Vessel GT-3500GE Operator's Instruction Manual

Portable impact wrench
Hide thumbs Also See for GT-3500GE:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Enlarged version
Email:export@vessel.co.jp   URL http://www.vessel.co.jp/exp/
®
Copyright VESSEL CO., INC. 2001
C
99093030.02 Printed in Japan.
,
OPERATOR
S INSTRUCTION MANUAL
GT-3500GE NEW MODEL
2001 Edition
PORTABLE IMPACT WRENCH
・
SPEC TYPE (Documents Included)
・ USA GAS EMISSION CONTROL VERSION(EPA PHASE/CARB Tier 1)
・ INTERNATIONAL SPEC MODEL
R
T o o l s
s i n c e
1 9 1 6
Product of Japan
