Summary of Contents for Vessel GT-3500GE
- Page 2 OPERATOR'S MANUAL & SPARE PARTS LISTS Exploded Diagram Drawing Handle Components - Exploded Diagram Drawing Damper Unit - Parts List...
- Page 3 Engine Type : Two Stroke, Forced, Air Cooled, Single Cylinder Displacement : 46.5cc, 43x32mm(Inner bore size x stroke) Fuel Tank Capacity : 1 liter Fuel Mixture Ratio : 25:1(gasoline : 2 cycle oil) Revolution(idling) : 2700 rpm Revolution(loaded, impact) : 7120 rpm Revolution(non loaded, max) : 9880 rpm Maximum Output...
- Page 9 SPARK PLUG CAP ASS'Y SPARK PLUG RUBBER COVER SPARK PLUG BPMR6A CYLINDER SET( INDEX NO.4, 6) HEX. HOLE BOLT 5x18/S CYLINDER GASKET PISTON RING PISTON PIN CIRCLIP PISTON SET( INDEX NO.7, 8, AND 9) NEEDLE BEARING, 1014125 CRANK SHAFT COMPLETE( INDEX NO. 11,12) SMALL NUT 10 STARTER PAWL STARTER PAWL SPRING...
- Page 10 without Damper Unit HEX. HOLE BOLT 5x12S VALVE, ADJUSTMENT BUTTON, ADJUSTMENT HEX. HOLE BUTTON SCREW 6x65 BRACKET, ADJUSTMENT WASHER 6 MUFFLER GASKET BALL, ADJUSTMENT 4 IN DIA. U NUT 4 SPRING, ADJUSTMENT S3.8X0.6 FIXED PIN SP 2.5X16 FOR ADJUST BUTTON TAIL PIPE COMPLETE HEX.
- Page 11 SET SCREW ADJUST SPRING PUMP BODY (Applicable for Non Emission Control Parts) LOW ADJUST SCREW PUMP GASKET HIGH ADJUST SCREW PUMP DIAPHRAGM NEEDLE VALVE INLET SCREEN VALVE SPRING SWIVEL CONTROL LEVER STOP RING HINGE PIN THROTTLE SHAFT COMPLETE HINGE PIN SET SCREW THROTTLE SPRING DIAPHRAGM GASKET THROTTLE VALVE...
- Page 13 with Damper Unit HANDLE COMPONENTS - EXPLODED DIAGRAM DRAWING...
- Page 14 Damper Unit - Parts List (Memorandum)
